TRICONEX 2401S2 Product Specification
Product Overview
The TRICONEX 2401S2 is a high-reliability digital output module designed for TRICONEX’s Triple Modular Redundant (TMR) safety instrumented systems (SIS). Engineered to deliver fail-safe control in critical industrial processes, this module translates digital signals from the system’s logic solver into precise actuation commands for valves, motors, and other field devices. As part of TRICONEX’s TMR platform, the TRICONEX 2401S2 ensures continuous operation even in harsh environments, making it essential for applications where downtime risks catastrophic consequences, such as oil refineries, chemical plants, and nuclear power facilities.
Featuring 24 individually configurable output channels, the TRICONEX 2401S2 supports both sinking and sourcing logic, allowing seamless integration with a wide range of industrial actuators. Each channel is rated for 24 VDC and 2 A, ensuring robust performance in high-demand scenarios. The module’s TMR architecture—three independent processing paths—guarantees redundancy, with automatic fault isolation and graceful degradation to maintain system integrity during single-channel failures. This redundancy is critical for safety-critical applications like emergency shutdown (ESD) systems, where a single point of failure could compromise personnel safety or equipment .
Built to withstand extreme conditions, the TRICONEX 2401S2 operates reliably between -40°C and +70°C and supports humidity levels up to 95% non-condensing. Its compact design (259 mm × 160 mm × 79 mm) and lightweight construction (1.0 kg) facilitate easy installation in standard 19-inch racks, while its hot-swappable design enables maintenance without system downtime. Certified to IEC 61508 SIL 3, the TRICONEX 2401S2 meets the highest safety standards, ensuring compliance with global regulations for risk mitigation in process industries .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | TRICONEX 2401S2 |
| Manufacturer | TRICONEX |
| Product Type | Digital Output Module (TMR Architecture) |
| Compatible Systems | TRICONEX TMR Safety Instrumented Systems (SIS), including Trident and Tri-GP platforms |
| Output Channels | 24 (individually configurable) |
| Output Voltage/Current | 24 VDC, 2 A per channel |
| Physical Dimensions | 259 mm (L) × 160 mm (W) × 79 mm (H) [10.2″ × 6.3″ × 3.1″] |
| Weight | 1.0 kg (2.2 lb) |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing, no frost |
| Redundancy | Triple Modular Redundant (TMR) with automatic fault detection and isolation |
| Certifications | SIL 3 (IEC 61508), CE, UL 508, Nuclear 1E (optional) |
| Communication Protocol | Proprietary TMR backplane communication (compatible with TRICONEX’s Tristation software) |
| Installation | Hot-swappable in 19-inch racks; requires TRICONEX backplane connectivity |
