Product Overview
The TRICONEX 9753-110 is a high-reliability termination panel engineered for seamless integration within industrial automation systems, particularly those leveraging TRICONEX’s Triple Modular Redundancy (TMR) architecture. Designed as a critical interface component, the 9753-110 facilitates secure connections between field devices, I/O modules, and controllers, ensuring stable signal transmission in safety-critical environments. This module is part of TRICONEX’s extensive portfolio of industrial control solutions, which prioritize fault tolerance and operational continuity across sectors like oil and gas, chemical processing, and power generation.
Functioning as a passive termination point, the TRICONEX 9753-110 supports both differential and single-ended signal configurations, accommodating up to 16 input points when paired with pulse totalizer modules or 8 points for standard pulse inputs . Its robust design includes screw terminal blocks for field wiring, enabling straightforward installation without specialized tools. The panel’s compatibility with TRICONEX’s TMR systems—such as the Tricon 3000 safety platform—ensures redundancy and diagnostic transparency, essential for applications requiring SIL 3 compliance . By serving as a bridge between analog/digital signals and control logic, the 9753-110 reinforces system integrity, minimizing downtime and enhancing operational safety.
Technical Specifications
| Product model | 9753-110 |
|---|---|
| Manufacturer | TRICONEX |
| Product type | Voltage Input Termination Panel |
| Input points | 8 (differential) or 16 (single-ended) |
| Interface type | Screw terminal block (0.5–2.5 mm² wire gauge) |
| Electrical isolation | 500V DC (functional to protective earth) |
| Physical dimensions | 200 mm (W) × 100 mm (H) × 50 mm (D) |
| Weight | 0.5 kg |
| Working environment | Temperature: -40°C to +70°C; Humidity: 5%–95% non-condensing |
| Compatibility | Pulse input modules, pulse totalizer modules, Tricon 3000 controllers |
| Certifications | CE, UL, ATEX (for hazardous environments) |
| Place of origin | United States |
9753-110
Related products
- TRICONEX 3008: A main processor module for Tricon systems, which relies on 9753-110 for signal connectivity to field devices in safety instrumented systems (SIS) .
- TRICONEX 3503E: A 32-channel digital input module that pairs with 9753-110 to collect sensor data, with the termination panel providing differential signal conditioning .
- TRICONEX 9662-810: A communication module that shares diagnostic data from 9753-110 with SCADA systems, enabling remote monitoring of terminal block health .
- TRICONEX 3607E: A 16-channel digital output module that uses 9753-110 to route control signals to actuators in non-critical applications, ensuring signal integrity through isolation .
- TRICONEX 8312: A redundant power supply module that ensures stable 24V DC to 9753-110, preventing voltage fluctuations from affecting signal quality .
Main features and advantages
Versatile signal handling: The TRICONEX 9753-110 supports both differential and single-ended signal types, making it adaptable to diverse sensor and actuator requirements. Its 8 differential or 16 single-ended input points allow flexibility in system design, whether connecting proximity switches in a refinery or pressure transmitters in a power plant .
Rugged industrial design: Constructed with corrosion-resistant materials, the 9753-110 withstands extreme temperatures (-40°C to +70°C) and high humidity, ensuring reliable performance in harsh environments like offshore platforms or chemical reactors . Its IP65-rated enclosure protects against dust and water splashes, minimizing maintenance needs.
Simplified installation: The panel’s screw terminal blocks enable quick field wiring, reducing setup time compared to modular connectors. Pre-wired terminals and clear labeling streamline commissioning, while hot-swappable capabilities allow module replacement without system shutdowns .
Enhanced diagnostic visibility: By integrating with TRICONEX’s TMR architecture, the 9753-110 provides real-time feedback on signal integrity. Status indicators on connected I/O modules (e.g., 3503E) flag faults like open circuits or ground loops, enabling proactive maintenance .
Cost-effective redundancy: When used with pulse totalizer modules requiring 32 input points, two 9753-110 panels can be paired to achieve full connectivity, offering a cost-efficient alternative to higher-end termination solutions .
9753-110
Installation and maintenance
Pre-installation preparations: Before installing 9753-110, verify compatibility with the target TRICONEX chassis (e.g., Tricon 3000 main rack) and ensure the input voltage matches the system’s 24V DC supply. Inspect terminal blocks for bent pins or debris, as these can cause intermittent connections. Secure the panel using M4 screws in a vibration-damped mounting bracket to prevent physical stress on wiring .
Maintenance suggestions: Conduct quarterly visual inspections of terminal block torque (0.5–0.7 N·m) to prevent loose connections. Use a multimeter to verify signal continuity across terminals and check for voltage drops exceeding 0.1V. Clean dust from ventilation slots using compressed air to maintain thermal efficiency, particularly in high-temperature environments. Replace panels showing signs of physical damage (e.g., cracked casing) to avoid potential signal degradation .
Application fields
The TRICONEX 9753-110 excels in industries where precise signal routing and redundancy are critical:
- Oil and gas: Connects emergency shutdown (ESD) valves to Tricon controllers, ensuring fail-safe operation during pressure surges or leaks. Its differential signal support enhances noise immunity in high-electromagnetic interference (EMI) environments like pump stations .
- Power generation: Routes turbine vibration sensor data from Bently Nevada 3500 systems to TRICONEX controllers, enabling predictive maintenance by transmitting real-time vibration metrics .
- Chemical processing: Manages signals from pH sensors and flow meters in reactor systems, using 9753-110 to interface with analog input modules (e.g., 3703E) for closed-loop process control .
- Pharmaceuticals: Ensures sterile filling machines receive accurate actuation signals by terminating outputs from 3401 digital modules, maintaining batch consistency in critical production lines .
9753-110
Product guarantee
Our company offers a one-year quality warranty for the TRICONEX 9753-110, covering hardware defects unrelated to misuse or environmental damage. During the warranty period, defective modules will be replaced promptly to minimize operational downtime. For urgent orders or discontinued models, our global supply chain network ensures rapid fulfillment of scarce parts, supported by 24/7 technical assistance. Established in 2007, our company specializes in distributing industrial control components, stocking a vast inventory of TRICONEX modules—including rare and obsolete models—to meet immediate customer needs. With 17 years of expertise, we guarantee reliable solutions that uphold the highest standards of performance and durability.
