YOKOGAWA AAI141-H50 S2 | Analog Input Module | AAI141-H00/S2

Description

Product Overview：YOKOGAWA AAI141-H50 S2

Technical Specifications：YOKOGAWA AAI141-H50 S2

Parameter Name	Parameter Value
Product Model	AAI141-H50 S2
Manufacturer	YOKOGAWA
Product Type	Analog Input Module
Channels	8 channels (isolated)
Signal Types	4–20 mA DC, 1–5 V DC
Resolution	16-bit A/D conversion
Accuracy	±0.1% of full scale
Power Supply	24V DC ±10%
Power Consumption	5W
Physical Dimensions	100 mm (W) × 160 mm (H) × 80 mm (D)
Weight	0.8 kg
Operating Temperature	0°C to 55°C
Humidity	5–95% non-condensing
Mounting Type	DIN rail (35 mm standard)
Country of Origin	Japan

YOKOGAWA AAI141-H50 S2

Main Features and Advantages：YOKOGAWA AAI141-H50 S2

Flexible Signal Configuration: Users can configure each channel independently for different signal types (current or voltage) through YOKOGAWA’s ProSafe-RS software, eliminating the need for hardware reconfiguration. This flexibility simplifies setup for diverse process requirements, from basic monitoring to complex control applications.

YOKOGAWA AAI141-H50 S2

Application Areas：YOKOGAWA AAI141-H50 S2

• Chemical Processing: Used to monitor reactor temperatures, pressure levels, and flow rates in chemical plants. The module’s high accuracy ensures consistent product quality and compliance with safety standards.
• Oil & Gas: Installed in refineries and offshore platforms to acquire data from pressure transmitters, level sensors, and analytical instruments, enabling real-time process optimization and leak detection.
• Power Generation: Integrates with turbine control systems to measure steam pressure, fuel flow, and generator load, supporting efficient energy production and grid stability.
• Water and Wastewater Treatment: Monitors pH levels, dissolved oxygen, and flow rates in treatment plants, ensuring regulatory compliance and optimal resource management.
• Food and Beverage: Used in production lines to control mixing processes, monitor ingredient levels, and maintain hygienic conditions through precise analog signal management.


  YOKOGAWA AAI141-H50 S2

Related Products：YOKOGAWA AAI141-H50 S2

1. AAI143-H00: A 16-channel analog input module with similar functionality to the AAI141-H50 S2, offering double the channel capacity for larger-scale systems.
2. AAI541-S00: A high-speed analog input module designed for applications requiring fast signal acquisition, such as high-frequency vibration monitoring.
3. ADV151-S00: A digital input/output module that complements the AAI141-H50 S2 in hybrid control systems, providing combined analog and digital signal processing.
4. AAI345-H00: A temperature input module specialized in acquiring signals from RTDs and thermocouples, expanding the system’s capability to handle thermal measurements.
5. SPG210-01: A power supply module for the CENTUM series, ensuring stable power delivery to the AAI141-H50 S2 and other I/O modules.
6. FCU711-S2: A field control unit that serves as the central processor for the CENTUM system, integrating data from the AAI141-H50 S2 for advanced control strategies.
7. ANB10-11: A terminal board for analog input modules, providing secure wiring connections and signal conditioning for the AAI141-H50 S2.

Installation and Maintenance：YOKOGAWA AAI141-H50 S2

• Routine Inspections: Monthly checks should include visual inspection of the module’s status LEDs to confirm normal operation and verification of signal readings against field instruments. Clean the module’s surface with a dry cloth to prevent dust accumulation.
• Calibration: Perform annual calibration using YOKOGAWA’s Calibration Tool to ensure measurement accuracy. Compare module readings with a certified calibration source and adjust as necessary.
• Firmware Updates: Periodically update the module’s firmware through the DCS interface to access new features and security patches, ensuring compatibility with the latest system upgrades.
• Spare Parts Management: Keep a spare AAI141-H50 S2 module in stock for quick replacement in case of failure. Ensure the spare module is pre-configured with the same settings to minimize downtime.


  YOKOGAWA AAI141-H50 S2
