Product Overview
The TRICONEX DI3301S2 is a high-performance digital input module designed for critical safety and control systems, developed by TRICONEX, a leader in industrial automation and safety instrumentation. As a key component of the TRICONEX Tricon safety system, the TRICONEX DI3301S2 is engineered to reliably collect and process digital input signals from field devices such as sensors, switches, and valves, converting them into actionable data for the system’s central processor. This module plays a pivotal role in ensuring the accuracy and timeliness of signal transmission, which is essential for maintaining the integrity of safety instrumented systems (SIS) and process control applications.
The TRICONEX DI3301S2 is part of TRICONEX’s extensive lineup of safety-related modules, renowned for their compliance with international safety standards, including IEC 61508, which certifies them for use in SIL 3 applications. Its design focuses on minimizing signal interference and maximizing operational stability, making the TRICONEX DI3301S2 an ideal choice for environments where even minor signal errors could lead to costly downtime or safety hazards. Whether integrated into new systems or retrofitted into existing TRICONEX setups, this module ensures seamless compatibility and consistent performance, reinforcing its value as a trusted component in industrial automation.
Technical Specifications
| Product models | Digital Input Module |
|---|---|
| Manufacturer | TRICONEX |
| Product type | Digital Input Module |
| Number of channels | 16 channels |
| Input voltage | 24V DC (nominal) |
| Isolation | Galvanic isolation (channel-to-channel and channel-to-backplane) |
| Communication interface | Tricon bus protocol |
| Physical dimensions | 102 mm (length) x 158 mm (width) x 28 mm (height) |
| Weight | 250 grams (approximate) |
| Operating temperature range | -40°C to 70°C |
| Storage temperature range | -55°C to 85°C |
| Humidity tolerance | 5% to 95% RH, non-condensing |
| Origin | United States |
DI3301S2
Related products
- TRICONEX DI3302: A digital input module with 32 channels, offering higher input capacity than the TRICONEX DI3301S2 for applications requiring more signal inputs.
- TRICONEX DI3303: Features enhanced diagnostic capabilities compared to the TRICONEX DI3301S2, including real-time channel health monitoring, suitable for mission-critical environments.
- TRICONEX AI3301: An analog input module, complementary to the TRICONEX DI3301S2, designed to process continuous analog signals (e.g., 4-20 mA) in safety systems.
- TRICONEX DO3301: A digital output module that works alongside the TRICONEX DI3301S2 to execute control actions based on the input signals received, such as activating alarms or shutdown mechanisms.
- TRICONEX AO3301: An analog output module, used in conjunction with the TRICONEX DI3301S2 in systems requiring variable output signals to control valves or pumps.
- TRICONEX T8401: A processor module that serves as the core of the Tricon system, coordinating data from modules like the TRICONEX DI3301S2 to execute safety logic and control strategies.
- TRICONEX PS3301: A redundant power supply module, essential for ensuring uninterrupted power to the TRICONEX DI3301S2 and other system components, enhancing overall system reliability.
- TRICONEX IC3600SSIA1: A signal isolator module that can be paired with the TRICONEX DI3301S2 to reduce electrical noise in environments with high electromagnetic interference, improving signal integrity.
Main features and advantages
The TRICONEX DI3301S2 stands out in industrial safety systems due to its robust design and focus on reliability. One of its key advantages is its compliance with SIL 3 certification, a critical requirement for safety instrumented systems in high-risk industries, ensuring that it meets the strictest standards for fault tolerance and failure prevention. This certification underscores the module’s ability to operate safely even in the presence of potential faults, making it a trusted choice for applications where human safety and process continuity are paramount.
Another notable feature of the TRICONEX DI3301S2 is its 16-channel configuration, which provides a balanced mix of input capacity and space efficiency. Each channel is equipped with galvanic isolation, preventing electrical interference between channels and protecting the module from voltage spikes or ground loops that could corrupt signals. This isolation not only enhances signal accuracy but also extends the module’s lifespan by reducing wear from electrical stress.
The TRICONEX DI3301S2 also integrates advanced diagnostic functions, including continuous self-checks and fault reporting. These diagnostics allow system operators to identify issues such as open circuits or short circuits in real time, enabling proactive maintenance and minimizing unplanned downtime. Additionally, the module is fully compatible with TRICONEX’s Tricon and Tricon CX systems, ensuring seamless integration into existing setups without the need for extensive reconfiguration, which saves time and reduces installation costs.
Ruggedness is another strength of the TRICONEX DI3301S2. Its ability to operate in extreme temperatures (-40 to 70°C) and high humidity (5-95% RH) makes it suitable for harsh industrial environments, from chemical plants to offshore oil rigs. This durability ensures consistent performance even under challenging conditions, reducing the need for frequent replacements and lowering long-term operational costs.
DI3301S2
