TRICONEX 3723X
High-Precision Analog Input Module for Safety-Critical Industrial Automation
High-Precision Analog Input Module for Safety-Critical Industrial Automation
Product Overview
The TRICONEX 3723X is a high-performance analog input module engineered for industrial automation systems requiring precision, reliability, and safety. As a core component of the TRICONEX Tricon CX platform, this module delivers advanced signal conditioning and measurement capabilities, making it ideal for applications in oil & gas, chemical processing, and power generation. Designed to interface with analog sensors and transmitters, the TRICONEX 3723X converts real-world signals (e.g., temperature, pressure, flow) into digital data for processing by the Tricon CX controller, ensuring seamless integration into safety instrumented systems (SIS) certified to Safety Integrity Level 3 (SIL 3).
With 32 isolated input channels supporting 0–20 mA and 5 VDC signals, the TRICONEX 3723X offers flexibility for diverse sensor types. Its robust design includes built-in diagnostics to detect signal anomalies (e.g., out-of-range values, wire breaks) and hot-swap functionality for maintenance without system downtime. By combining high-accuracy signal processing with TRICONEX’s triple modular redundancy (TMR) architecture, the TRICONEX 3723X minimizes single points of failure, ensuring continuous operation in harsh industrial environments. This module plays a critical role in monitoring critical processes, enabling timely corrective actions to prevent safety incidents and equipment damage.
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | TRICONEX 3723X |
| Manufacturer | TRICONEX |
| Product Type | Analog Input Module for Tricon CX System |
| Input Channels | 32 isolated channels |
| Input Signal Range | 0–20 mA, 5 VDC |
| Accuracy | ±0.1% of full scale |
| Resolution | 16 bits |
| Diagnostics | Built-in signal fault detection (e.g., open circuit, over-range) |
| Compatibility | Tricon CX controller, TBE-D 5016-TRI-011 termination board |
| Power Supply | 24 VDC ±10% |
| Operating Temperature | -40°C to 70°C |
| Humidity | 5–95% non-condensing |
| Physical Dimensions | 165 mm (L) × 100 mm (W) × 220 mm (H) [standard Tricon CX module size] |
| Weight | 1.2 kg |
| Certifications | SIL 3 (IEC 61508), CE |
