Product Overview: TRICONEX 3636R
The TRICONEX 3636R is a high-performance relay output module engineered for mission-critical applications within safety instrumented systems (SIS). As a core component of the TRICONEX Tricon V9 platform, this module delivers unmatched reliability and precision in industrial environments where failure is not an option. Designed to interface between logic solvers and field devices, the TRICONEX 3636R ensures seamless control and monitoring of safety-critical processes across industries such as oil and gas, chemical production, and power generation.
Featuring 32 independent dry-contact outputs, the TRICONEX 3636R supports a wide voltage range (125V AC/DC) and a maximum current load of 2A per channel, making it suitable for driving solenoids, valves, and other high-power devices. Its non-triplicated architecture simplifies integration into non-critical control loops while maintaining compliance with rigorous safety standards like IEC 61508 (SIL 3) and IEEE 1188. The module’s robust design includes built-in diagnostics and fault detection mechanisms, ensuring continuous operability even in harsh conditions, with an operating temperature range of -40°C to +70°C and immunity to electromagnetic interference (EMC).
In automation systems, the TRICONEX 3636R serves as a vital link between the control logic and physical actuators, enabling precise activation and deactivation of equipment during normal operations and emergency shutdowns. Its modular design facilitates easy installation and maintenance, while hot-swap capabilities minimize downtime. By combining advanced hardware redundancy with real-time diagnostics, the TRICONEX 3636R enhances system availability and reduces lifecycle costs, making it an ideal choice for retrofitting legacy systems or building new high-integrity control solutions.
Technical Specifications: TRICONEX 3636R
| Parameter | Value |
|---|---|
| Manufacturer | TRICONEX |
| Product Type | Relay Output Module |
| Physical Dimensions | 263 mm × 58 mm × 28 mm (10.35″ × 2.28″ × 1.10″) |
| Weight | 2.42 kg (5.33 lbs) [net]; 4 kg (8.82 lbs) [shipping] |
| Voltage Range | 125V AC/DC |
| Current Load | 3A maximum per contact (250V AC), 2A maximum per channel |
| Response Time | <20 ms |
| Operating Temperature | -40°C to +70°C |
| Certifications | IEC 61508 (SIL 3), IEEE 1188, EMC compliance (IEC 61000-4-2/3/6) |
3636R
Related Products: TRICONEX 3636R
- TRICONEX 3635R: A non-triplicated relay output module with normally closed contacts, ideal for fail-safe applications requiring immediate deactivation of equipment.
- TRICONEX 3625: A digital output module supporting 24V DC signals, designed for low-power applications in distributed control systems (DCS).
- TRICONEX 3700: An analog input module with differential signal processing, used for precise measurement of pressure, temperature, and flow in process control.
- TRICONEX 8310: A high-density power supply module providing 120V AC/DC power to Tricon systems, ensuring stable operation under varying loads.
- TRICONEX 4351B: A communication module enabling connectivity with Modbus, Foxboro DCS, and other industrial networks for seamless system integration.
- TRICONEX 3636T: A variant of the 3636R with high-isolation contacts, suitable for applications requiring enhanced electrical separation.
- TRICONEX 3623: A digital input module supporting 120V DC signals, used for monitoring switches, sensors, and other discrete inputs.
- TRICONEX 9566-710: An external termination panel (ETP) for the 3636R, providing secure field wiring connections and surge protection.
Main Features and Advantages: TRICONEX 3636R
The TRICONEX 3636R stands out for its fault-tolerant design and comprehensive diagnostic capabilities. Each relay channel includes a loopback circuit that independently verifies contact operation, while continuous self-tests monitor module health and detect faults in real-time. In the event of a failure, the module triggers an alarm and isolates the affected channel, preventing cascading system failures. This proactive approach to reliability reduces mean time to repair (MTTR) and ensures compliance with safety integrity requirements.
Another key strength is its versatility in harsh environments. Withstanding extreme temperatures, vibration (0.05g RMS, 10–500 Hz), and shock (15g, 20 ms), the TRICONEX 3636R excels in offshore platforms, refineries, and other challenging industrial settings. Its modular construction allows for easy replacement without disrupting adjacent modules, simplifying maintenance and minimizing downtime.
The TRICONEX 3636R also supports hot-swappable operation, enabling online module replacement while the system remains active. This feature is critical for industries where continuous production is essential, such as pharmaceuticals and water treatment. Additionally, its compatibility with the Tricon V9 platform ensures seamless integration with existing control systems, leveraging TRICONEX’s proven triple modular redundancy (TMR) architecture for high availability.
3636R
Installation and Maintenance: TRICONEX 3636R
Pre-installation Preparations:
Before installing the TRICONEX 3636R, verify the system’s power supply meets the module’s voltage requirements (125V AC/DC). Ensure the chassis is properly grounded and free of debris. Use the recommended termination panel (e.g., TRICONEX 9566-710) to connect field wiring, following the wiring diagrams provided in the installation manual. Confirm that the module’s firmware is updated to the latest version to support compatibility with the control system.
Before installing the TRICONEX 3636R, verify the system’s power supply meets the module’s voltage requirements (125V AC/DC). Ensure the chassis is properly grounded and free of debris. Use the recommended termination panel (e.g., TRICONEX 9566-710) to connect field wiring, following the wiring diagrams provided in the installation manual. Confirm that the module’s firmware is updated to the latest version to support compatibility with the control system.
Maintenance Suggestions:
Regular maintenance of the TRICONEX 3636R includes visual inspections for physical damage, corrosion, or loose connections. Use diagnostic tools to monitor module health and review event logs for anomalies. Clean the module periodically to prevent dust accumulation, which can affect thermal performance. For long-term storage, ensure the module is kept in a dry, static-free environment. Replace worn or faulty relays promptly to maintain system integrity.
Regular maintenance of the TRICONEX 3636R includes visual inspections for physical damage, corrosion, or loose connections. Use diagnostic tools to monitor module health and review event logs for anomalies. Clean the module periodically to prevent dust accumulation, which can affect thermal performance. For long-term storage, ensure the module is kept in a dry, static-free environment. Replace worn or faulty relays promptly to maintain system integrity.
Application Fields: TRICONEX 3636R
The TRICONEX 3636R finds extensive use in industries where safety and reliability are paramount. In oil and gas, it controls emergency shutdown (ESD) valves and blowout preventers, ensuring rapid isolation of hazardous processes. In chemical plants, it manages reactor shutdown systems and material handling equipment, safeguarding personnel and assets from 失控 reactions. Power generation facilities rely on the module to protect turbines and generators by activating protective relays during 异常 conditions.
The module’s adaptability extends to water treatment plants, where it operates pumps and valves in wastewater treatment systems, and pharmaceutical manufacturing, where it ensures sterile environments by controlling cleanroom airflow systems. Its high-contact rating and robust design also make it suitable for mining and metallurgy, where it manages heavy machinery and conveyor systems.
3636R
Product Guarantee: TRICONEX 3636R
Our company offers a one-year quality warranty for the TRICONEX 3636R, covering hardware malfunctions unrelated to misuse or environmental damage. During the warranty period, we provide prompt replacement services for defective modules. For discontinued models or urgent requirements, our global supply chain network ensures rapid procurement of scarce spare parts, minimizing downtime. We also offer technical support to assist with installation, troubleshooting, and system integration. With 17 years of industry experience, we are committed to delivering reliable solutions that keep industrial systems operational and compliant.
