Product Overview
The TRICONEX 3624 is a high-performance digital input module designed by TRICONEX, a leading provider of safety instrumented systems (SIS) and industrial automation solutions. As a critical component within the TRICONEX Tricon safety system, the TRICONEX 3624 is engineered to process and monitor digital input signals from field devices, ensuring reliable data acquisition in safety-critical industrial environments. This module plays a pivotal role in enabling the Tricon system to make real-time decisions, as it converts physical signals (such as limit switch statuses or valve positions) into digital data that the system’s controller can interpret.
The TRICONEX 3624 is part of TRICONEX’s renowned family of redundant safety modules, which are widely recognized for their compliance with international safety standards, including IEC 61508 (SIL 3) and TÜV certification. Its integration into automation systems enhances operational safety by providing accurate, high-speed signal processing, reducing the risk of false alarms or missed critical events. Whether deployed in complex process control loops or standalone safety applications, the TRICONEX 3624 delivers consistent performance, making it a trusted choice for industries where downtime or safety failures could have severe consequences.
Technical Specifications
| Product model | TRICONEX 3624 |
|---|---|
| Manufacturer | TRICONEX |
| Product type | Digital input module |
| Input channels | 16 isolated channels |
| Input voltage range | 24 V DC (nominal); 18-32 V DC (operating range) |
| Isolation | Channel-to-channel: 500 V AC (rms); Channel-to-backplane: 1500 V AC (rms) |
| Physical dimensions | 101.6 mm (length) × 152.4 mm (width) × 38.1 mm (height) |
| Weight | 227 grams (8 ounces) |
| Operating temperature range | 0°C to 60°C (32°F to 140°F) |
| Storage temperature range | -40°C to 85°C (-40°F to 185°F) |
| Communication interface | Tricon backplane bus |
| Humidity tolerance | 5% to 95% relative humidity, non-condensing |
| Origin | United States |
3624
Related products
- TRICONEX 3625: A digital output module in the same series as the TRICONEX 3624, designed to send control signals to field devices (e.g., solenoid valves or alarms). It complements the TRICONEX 3624 by enabling the system to act on the input data it collects.
- TRICONEX 3503: A power supply module that provides stable 24 V DC power to TRICONEX modules, including the TRICONEX 3624. It ensures consistent operation by maintaining voltage stability even in fluctuating industrial power environments.
- TRICONEX 2651: A communication module that facilitates data exchange between the Tricon system (including the TRICONEX 3624) and external systems (e.g., SCADA or DCS). It expands the module’s connectivity for broader system integration.
- TRICONEX 4351B: The main processor module of the Tricon system, which processes data from input modules like the TRICONEX 3624. It acts as the “brain” of the system, using input data to execute safety logic.
- TRICONEX 3700A: An analog input module that handles continuous signals (e.g., pressure or temperature), differing from the TRICONEX 3624’s focus on discrete signals. It is used alongside the TRICONEX 3624 in systems requiring both discrete and analog monitoring.
- TRICONEX 3805E: A relay output module with higher current handling capabilities than the 3625, suitable for controlling heavy-duty equipment. It is an alternative to the 3625 when higher power outputs are needed, working with the TRICONEX 3624 in demanding applications.
- TRICONEX 3008: A legacy digital input module that precedes the TRICONEX 3624. While less advanced, it is still used in older systems and can be replaced by the TRICONEX 3624 for improved performance and compatibility.
Main features and advantages
The TRICONEX 3624 stands out for its robust design, tailored to meet the stringent demands of safety-critical industrial environments. One of its core strengths is its compliance with global safety standards, including SIL 3 certification under IEC 61508 and TÜV approval, ensuring it can be trusted in applications where failure could lead to catastrophic consequences, such as in chemical plants or oil refineries.
The module’s 16 isolated channels provide exceptional signal integrity, with channel-to-channel and channel-to-backplane isolation preventing electrical interference from affecting data accuracy. This isolation is crucial in industrial settings with high electromagnetic noise, where even small signal disruptions could lead to incorrect system responses. The TRICONEX 3624 processes signals at high speed, ensuring that critical input changes (e.g., a sudden pressure spike) are detected and relayed to the system controller without delay, enabling rapid safety actions.
Durability is another key advantage. The TRICONEX 3624 operates reliably across a wide temperature range (0°C to 60°C) and tolerates high humidity levels, making it suitable for harsh environments, including outdoor installations or facilities with variable climate conditions. Its compact size and lightweight design (227 grams) simplify integration into existing Tricon system racks, reducing installation complexity and space requirements.
Additionally, the TRICONEX 3624 offers seamless compatibility with other TRICONEX modules and the Tricon backplane bus, ensuring easy integration into both new systems and upgrades of legacy setups. This compatibility minimizes downtime during installation or replacement, a critical factor for industries where production interruptions are costly. Overall, the TRICONEX 3624 combines safety, reliability, and performance to deliver a digital input solution that enhances the integrity of industrial safety systems.
3624
Installation and maintenance
Pre-installation preparations: Before installing the TRICONEX 3624, verify that the Tricon system rack is powered off and that all wiring to the rack is disconnected to prevent electrical hazards. Check the module for physical damage, such as bent pins or cracks, which could affect performance. Ensure the rack is compatible with the TRICONEX 3624 (typically Tricon 3000 or 4000 series racks) and that the backplane connectors are clean and free of debris. Review the wiring diagram to confirm that field devices (e.g., limit switches) are correctly wired to the module’s terminal block, with proper 24 V DC power supply connections.
Maintenance suggestions: Regular maintenance of the TRICONEX 3624 is essential to ensure long-term reliability. Perform quarterly visual inspections to check for loose connections, corrosion on terminals, or signs of overheating (e.g., discoloration). Test each channel periodically using a signal generator to confirm accurate input detection, ensuring no channels are unresponsive or producing false signals. Keep the module and surrounding rack area clean, using compressed air to remove dust that could interfere with cooling or electrical contacts. Avoid exposing the TRICONEX 3624 to extreme temperatures or moisture beyond its specified range, as this can degrade internal components over time. If firmware updates are available for the Tricon system, ensure they are applied to maintain compatibility and optimize the module’s performance.
Application fields
The TRICONEX 3624 is widely utilized in industries where safety and reliability are paramount, serving as a critical component in safety instrumented systems (SIS) and emergency shutdown systems (ESD). In the oil and gas sector, it monitors critical signals such as pipeline pressure, valve positions, and pump statuses. For example, in offshore drilling platforms, the TRICONEX 3624 detects if a blowout preventer (BOP) is properly closed, relaying this data to the SIS to trigger an emergency shutdown if a malfunction is detected, preventing oil spills or equipment damage.
In chemical processing plants, the TRICONEX 3624 plays a key role in monitoring hazardous material storage and processing units. It tracks signals from level sensors in chemical tanks, flow switches in pipelines, and emergency stop buttons, ensuring that any deviation from safe operating conditions is immediately communicated to the system controller. This allows for rapid responses, such as shutting down a reactor if a leak is detected, protecting workers and preventing environmental contamination.
Power generation facilities, including nuclear, coal, and renewable energy plants, also rely on the TRICONEX 3624. In nuclear power plants, it monitors coolant flow rates and turbine vibration, contributing to systems that prevent overheating or equipment failure. In coal-fired plants, it tracks conveyor belt statuses and boiler pressure, ensuring safe and efficient operation.
Pharmaceutical manufacturing is another key application area, where the TRICONEX 3624 monitors cleanroom conditions, equipment sterilization cycles, and material handling systems. Its high accuracy ensures that critical processes adhere to strict regulatory standards, maintaining product quality and safety. Across all these fields, the TRICONEX 3624’s ability to reliably process digital inputs makes it indispensable for maintaining safe and efficient industrial operations.
3624
Product guarantee
Our company offers a one-year quality warranty service for the TRICONEX 3624, covering hardware malfunctions not caused by human factors. During the warranty period, if the TRICONEX 3624 shows abnormal performance or functional failure, we will provide replacement services to ensure minimal downtime for your operations. In addition, for discontinued models or urgent demands, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts like the TRICONEX 3624, and provide reliable services to support the continuous and stable operation of industrial systems. Our team of technical experts is available to assist with installation guidance, troubleshooting, and compatibility checks, ensuring that you get the most out of your TRICONEX 3624 module. As a leading import and export trade distribution company with 17 years of experience, we are committed to delivering high-quality industrial control parts and exceptional after-sales support to meet your needs.
