ROSOFT 202-DFNT-MCM4 Product Specification
Product Overview：PROSOFT 202-DFNT-MCM4
The PROSOFT 202-DFNT-MCM4 is a high-performance DeviceNet to EtherNet/IP communication gateway designed to bridge industrial automation networks and enable seamless data exchange between legacy DeviceNet devices and modern EtherNet/IP systems. Engineered by ProSoft Technology, a global leader in industrial networking solutions, this module is part of the 202 Series of communication gateways, renowned for their reliability, ease of integration, and support for mission-critical applications. The PROSOFT 202-DFNT-MCM4 acts as a protocol translator, allowing manufacturers to modernize control systems while retaining existing DeviceNet infrastructure, such as sensors, actuators, and drives.
At its core, the PROSOFT 202-DFNT-MCM4 supports configurable master/slave operations on both DeviceNet and EtherNet/IP networks, enabling bidirectional data mapping between the two protocols. It features a rugged industrial design with a wide operating temperature range (-40°C to +70°C) and supports up to 500 I/O bytes of data throughput, ensuring real-time performance in high-speed manufacturing environments. The module’s plug-and-play functionality, combined with ProSoft’s Anybus Configuration Manager software, simplifies setup and diagnostics, reducing engineering time and minimizing downtime during system upgrades.
In automation architectures, the PROSOFT 202-DFNT-MCM4 addresses the challenge of integrating older field devices into modern IIoT ecosystems. By acting as a transparent gateway, it enables legacy equipment to communicate with advanced PLCs (e.g., Rockwell Automation Allen-Bradley) and SCADA systems, facilitating predictive maintenance, remote monitoring, and centralized control. This capability is particularly valuable in industries undergoing digital transformation, where retrofitting existing infrastructure is more cost-effective than full system replacement.
Technical Specifications：PROSOFT 202-DFNT-MCM4
| Parameter Name | Parameter Value |
|---|---|
| Product Model | PROSOFT 202-DFNT-MCM4 |
| Manufacturer | ProSoft Technology |
| Product Type | Industrial Communication Gateway (DeviceNet to EtherNet/IP) |
| Network Protocols | DeviceNet (Master/Slave), EtherNet/IP (Adapter/Scanner) |
| Data Throughput | Up to 500 I/O bytes |
| Power Supply | 24 VDC ±15% (10–30 VDC range) |
| Physical Dimensions | 101.6 mm (W) × 127 mm (H) × 44.45 mm (D) |
| Weight | 0.45 kg |
| Communication Ports | 1x DeviceNet (5-pin M12), 1x EtherNet/IP (RJ45 with Auto-MDI/MDIX) |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
| Certifications | CE, UL, CUL, RoHS, ODVA (EtherNet/IP and DeviceNet compliant) |
| Installation | DIN rail or panel-mounted |
202-DFNT-MCM4
Main Features and Advantages：PROSOFT 202-DFNT-MCM4
Dual-Protocol Connectivity: The PROSOFT 202-DFNT-MCM4 eliminates protocol barriers by translating data between DeviceNet and EtherNet/IP, enabling seamless integration of legacy devices into modern industrial networks. This dual capability reduces the need for multiple gateways, simplifying system architecture and lowering hardware costs.
High-Speed Data Handling: With support for up to 500 I/O bytes, the module ensures real-time data transfer for applications requiring low latency, such as robotics, conveyor systems, and quality control equipment. Its advanced processing engine minimizes data delay, ensuring smooth coordination between field devices and higher-level controls.
Rugged Industrial Design: Built to withstand harsh environments, the PROSOFT 202-DFNT-MCM4 features a compact, fanless design with conformal-coated PCBs to resist dust, moisture, and electromagnetic interference (EMI). This durability makes it suitable for use in manufacturing plants, oil refineries, and other challenging industrial settings.
User-Friendly Configuration: The module’s intuitive configuration software allows engineers to map I/O data, set up network parameters, and monitor diagnostics through a graphical interface. Its plug-and-play functionality reduces commissioning time, while built-in LED indicators provide quick status updates for troubleshooting.
Scalable and Future-Proof: As part of ProSoft’s 202 Series, the PROSOFT 202-DFNT-MCM4 supports firmware updates to adapt to evolving network protocols and standards. This scalability ensures the module remains compatible with future system upgrades, protecting long-term investments in automation infrastructure.
202-DFNT-MCM4
Application Areas：PROSOFT 202-DFNT-MCM4
The PROSOFT 202-DFNT-MCM4 is widely deployed in industries seeking to modernize legacy systems while maintaining compatibility with existing equipment:
-
Manufacturing:
- Automotive Assembly: Connects DeviceNet-based robotic arms and sensors to EtherNet/IP-controlled PLCs, enabling real-time data exchange for process optimization.
- Packaging Lines: Translates data from DeviceNet conveyor drives to EtherNet/IP SCADA systems, facilitating remote monitoring and predictive maintenance.
-
Oil and Gas:
- Upstream Operations: Integrates legacy DeviceNet flow meters and valves with modern EtherNet/IP-based distributed control systems (DCS) for real-time process monitoring in wellheads and production facilities.
- Downstream Refineries: Bridges DeviceNet safety switches and actuators with EtherNet/IP emergency shutdown (ESD) systems, enhancing safety and compliance.
-
Food and Beverage:
- Processing Plants: Enables communication between DeviceNet-based filling machines and EtherNet/IP quality control systems, ensuring product consistency and regulatory compliance.
- Warehousing: Connects DeviceNet palletizers to EtherNet/IP warehouse management systems (WMS) for automated inventory tracking.
-
Power Generation:
- Steam Turbine Control: Translates data from DeviceNet vibration sensors to EtherNet/IP condition monitoring systems, supporting predictive maintenance of critical machinery.
- Renewable Energy: Integrates DeviceNet inverters with EtherNet/IP energy management systems in solar and wind farms, optimizing energy production and distribution.
Related Products：PROSOFT 202-DFNT-MCM4
- PROSOFT 202-DFNT-MCM2: A compact variant with reduced I/O capacity (256 bytes), suitable for smaller-scale applications or budget-sensitive projects.
- PROSOFT 202-ENET-MCM: An EtherNet/IP to Modbus TCP gateway, ideal for integrating Modbus devices into EtherNet/IP networks alongside the PROSOFT 202-DFNT-MCM4.
- PROSOFT 202-DNDP-MCM: A DeviceNet diagnostic tool for troubleshooting network issues, often used in conjunction with the PROSOFT 202-DFNT-MCM4 for comprehensive system maintenance.
- PROSOFT 300-DFNT-MCM: An upgraded version with advanced security features (e.g., firewall, encryption), designed for IIoT-enabled environments requiring enhanced cybersecurity.
- PROSOFT 202-ETH-MCM: A dual-port EtherNet/IP module for redundant network configurations, complementing the PROSOFT 202-DFNT-MCM4 in mission-critical applications.
202-DFNT-MCM4
Installation and Maintenance：PROSOFT 202-DFNT-MCM4
Pre-installation Preparation:
Before installing the PROSOFT 202-DFNT-MCM4, ensure the following:
Before installing the PROSOFT 202-DFNT-MCM4, ensure the following:
- Verify the power supply voltage (24 VDC ±15%) and ground the module properly to prevent EMI interference.
- Use ProSoft’s Anybus Configuration Manager to configure network roles (DeviceNet Master/Slave, EtherNet/IP Adapter/Scanner) and define I/O data mappings.
- Ensure compatible network cables (e.g., Cat5e for EtherNet/IP, DeviceNet trunk/drop cables) are available for connection.
Maintenance Recommendations:
- Routine Inspections: Check front-panel LEDs regularly to monitor power status, network connectivity, and data transfer activity. A steady green LED indicates normal operation, while flashing lights may signal configuration or communication issues.
- Firmware Updates: Periodically update the module’s firmware via ProSoft’s software to access new features, protocol enhancements, and security patches.
- Environmental Checks: Clean dust and debris from the module’s vents quarterly, especially in high-dust environments, to maintain optimal thermal performance.
- Network Diagnostics: Use the module’s built-in diagnostic tools to monitor data throughput and error rates, addressing anomalies promptly to avoid system disruptions.
202-DFNT-MCM4
Product Warranty：PROSOFT 202-DFNT-MCM4
Our company provides a one-year quality warranty for the PROSOFT 202-DFNT-MCM4, covering all non-human-induced hardware defects. During the warranty period, we will replace any module experiencing performance issues or functional failures at no cost. For discontinued models or urgent requirements, our global supply chain network ensures rapid delivery of scarce components, supported by our team of certified technicians for post-warranty repairs and technical assistance. We are committed to ensuring your industrial systems operate reliably, leveraging our 17 years of expertise in distributing high-quality automation spare parts.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This product description is based on technical data from ProSoft Technology’s official specifications and industry applications. For detailed configuration guidelines, refer to the PROSOFT 202-DFNT-MCM4 user manual or contact our technical support team for personalized assistance
