Product Overview
The Honeywell CC-PUIO31 is a high-performance universal input/output (I/O) module designed for industrial automation systems, specifically engineered for integration with Honeywell’s Experion Series C control platforms, including the C300 controller. As a core component of the Experion architecture, this module serves as a versatile interface between field devices and the control system, enabling seamless data acquisition and command execution across a wide range of industrial processes.
The Honeywell CC-PUIO31 stands out for its ability to handle diverse signal types, including analog inputs/outputs (4-20 mA, HART), digital inputs/outputs, and pulse signals, with 32 configurable channels that can be individually assigned to meet specific application needs . This flexibility eliminates the need for multiple specialized modules, streamlining system design and reducing inventory complexity. The module supports advanced features such as open-wire detection, short-circuit protection, and configurable fail-safe states, ensuring robust performance in critical environments like oil refineries, power plants, and manufacturing facilities.Whatsapp:+86 18859254943.
Part of Honeywell’s commitment to industrial resilience, the CC-PUIO31 is built to withstand harsh conditions, with an extended operating temperature range of -40°C to +70°C and resistance to electromagnetic interference (EMI) . Its modular design allows for hot-swappable replacement, minimizing downtime during maintenance, while its compatibility with Honeywell’s Experion software suite ensures easy integration with higher-level systems for centralized monitoring and control. By combining precision signal processing with scalable connectivity, the CC-PUIO31 empowers industries to achieve operational efficiency, reliability, and compliance with safety standards.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | CC-PUIO31 |
| Manufacturer | Honeywell |
| Product Type | Universal Input/Output (I/O) Module |
| Series Compatibility | Experion Series C (C300 controller) |
| Channel Configuration | 32 configurable channels (analog/digital input/output, HART-enabled) |
| Input Voltage | 24 V DC (±10%) |
| Power Consumption | ≤10 W (typical) |
| Communication Protocols | Modbus RTU, Honeywell DE Protocol, PROFIBUS (via gateway) |
| Signal Types | Analog: 4-20 mA, HART 7; Digital: 24 V DC dry contact; Pulse: 0-5 V, 0-20 mA |
| Accuracy | ±0.1% (analog inputs/outputs) |
| Isolation | 500 V DC between field and system |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5%–95% non-condensing |
| Physical Dimensions | 220 mm (W) × 150 mm (H) × 100 mm (D) |
| Mounting Method | DIN-rail (35 mm) or panel mount |
| Protection Class | IP20 (front panel), IP54 with optional enclosure |
| Diagnostic Features | LED indicators for power, communication, and channel status; open-wire detection; short-circuit protection |
CC-PUIO31
Main Features and Advantages
Universal Signal Handling
The Honeywell CC-PUIO31 offers unparalleled flexibility with 32 channels that can be individually configured as analog inputs (4-20 mA, HART), analog outputs, digital inputs/outputs, or pulse inputs . This versatility allows it to interface with a broad range of field devices, including pressure transmitters, flow meters, solenoid valves, and proximity sensors, without requiring specialized modules. For example, in a chemical plant, the module can simultaneously monitor temperature readings from analog sensors and control motor starters via digital outputs, all within a single unit.
HART Protocol Integration
With native HART 7 support on analog channels, the CC-PUIO31 enables bidirectional communication with intelligent field devices, providing access to diagnostic data, calibration information, and device status . This capability enhances predictive maintenance by allowing engineers to remotely monitor device health and detect potential failures before they escalate. In a refinery setting, this feature can reduce unplanned downtime by up to 20% by identifying faulty transmitters early.
Robust Industrial Design
Engineered for reliability in extreme environments, the module operates seamlessly across a wide temperature range (-40°C to +70°C) and resists vibrations, shocks, and EMI . Its rugged enclosure and conformal coating protect against dust and moisture, making it suitable for outdoor installations or harsh industrial environments like mining or offshore platforms. The hot-swappable design further ensures continuous operation during module replacement, critical for maintaining production uptime.
CC-PUIO31
Advanced Diagnostic Capabilities
Built-in diagnostics, including open-wire detection and short-circuit protection, enable real-time monitoring of channel integrity . Fault conditions are immediately flagged via LED indicators and network alerts, allowing rapid troubleshooting. For instance, if a sensor cable becomes disconnected, the module automatically triggers an alarm, prompting maintenance teams to address the issue before process deviations occur.
Scalable System Integration
The CC-PUIO31 integrates seamlessly with Honeywell’s Experion Series C control systems, supporting high-speed data exchange via Modbus RTU or Honeywell DE Protocol . It can be combined with other Experion I/O modules (e.g., CC-PUIO01, CC-PMIO01) to create scalable solutions for small-scale machinery or large industrial complexes. This modularity reduces upfront costs and simplifies system expansion as operational needs grow.
Application Areas
Oil and Gas Processing
In upstream and downstream oil and gas facilities, the Honeywell CC-PUIO31 monitors pressure, temperature, and flow rates in pipelines and refinery units. It controls valves and pumps to maintain optimal process conditions, ensuring compliance with safety and environmental standards. For example, in a liquefied natural gas (LNG) plant, the module can manage cryogenic pump operations while monitoring gas composition via HART-enabled analyzers.
Power Generation
In thermal and renewable energy plants, the module interfaces with turbines, generators, and grid systems. It regulates steam pressure in boilers, monitors generator voltage, and controls switchgear for grid synchronization. In a wind farm, the CC-PUIO31 can manage pitch control systems and monitor blade health through vibration sensors, enhancing energy production efficiency.Whatsapp:+86 18859254943.
Water and Wastewater Treatment
For water purification and wastewater treatment plants, the module controls chemical dosing systems, monitors pH levels, and manages pump stations. It ensures consistent water quality by adjusting treatment processes in real-time based on sensor feedback. In a wastewater treatment facility, it can automate sludge dewatering processes while alerting operators to conditions like clogged filters.
CC-PUIO31
Manufacturing and Packaging
In automotive and consumer goods manufacturing, the CC-PUIO31 coordinates conveyor systems, robotic arms, and quality control sensors. It ensures precise motion control in assembly lines and tracks production metrics for OEE (Overall Equipment Effectiveness) optimization. For example, in a food packaging plant, the module can synchronize labeling machines with product flow while detecting faulty seals via vision systems.
Pharmaceutical and Biotechnology
In pharmaceutical production, the module maintains sterile environments by controlling HVAC systems, monitoring cleanroom pressures, and managing batch processes. Its HART compatibility enables integration with analytical instruments for real-time quality assurance. In a biotech lab, it can automate fermentation processes while ensuring compliance with FDA and EU GMP standards.
Related Products
- Honeywell CC-PUIO01: A predecessor model with 16 configurable channels, ideal for smaller-scale applications requiring basic I/O functionality.
- Honeywell CC-PMIO01: A mixed-signal I/O module supporting analog and digital channels, complementary to the CC-PUIO31 for hybrid control systems.
- Honeywell C300 Controller: The primary control platform for the Experion Series C, providing real-time processing and communication with the CC-PUIO31.
- Honeywell CC-SDRX01: A fiber optic converter that extends I/O capabilities for remote installations, enhancing the CC-PUIO31’s connectivity in distributed systems.
- Honeywell HMI 500: A touchscreen interface for programming and monitoring the CC-PUIO31, offering intuitive system diagnostics and configuration.
- Honeywell PM864AK01 3BSE01816R1: A high-performance processor module from ABB, compatible with the CC-PUIO31 in hybrid automation setups requiring multi-vendor integration.
- Honeywell VT-HNC100-1-23M-08-P-0: A hydraulic control module that pairs with the CC-PUIO31 for applications combining digital control with hydraulic actuation.
Installation and Maintenance
Installation Preparations:
Before installing the Honeywell CC-PUIO31, ensure the control system is powered off and the DIN rail is securely mounted. Verify the 24 V DC power supply meets the module’s requirements (18–31.2 V DC) and use shielded cables to minimize EMI . Configure the module’s communication parameters (e.g., Modbus address) using Honeywell’s Experion software, ensuring compatibility with the host controller. Connect field devices to the removable screw terminals, following the wiring diagram provided in the user manual to avoid polarity errors.Whatsapp:+86 18859254943.
Before installing the Honeywell CC-PUIO31, ensure the control system is powered off and the DIN rail is securely mounted. Verify the 24 V DC power supply meets the module’s requirements (18–31.2 V DC) and use shielded cables to minimize EMI . Configure the module’s communication parameters (e.g., Modbus address) using Honeywell’s Experion software, ensuring compatibility with the host controller. Connect field devices to the removable screw terminals, following the wiring diagram provided in the user manual to avoid polarity errors.Whatsapp:+86 18859254943.
CC-PUIO31
Maintenance Recommendations:
Regularly inspect the module for physical damage, loose connections, or dust accumulation, particularly in high-humidity environments. Clean the enclosure with a dry cloth and check LED indicators for fault signals, a red light may indicate a communication failure or power irregularity . Update the firmware periodically to access the latest features and security patches. For HART-enabled devices, use Honeywell’s HART configuration tools to validate sensor calibrations and diagnostics. In case of persistent issues, contact our technical support team for remote troubleshooting or replacement guidance.
Regularly inspect the module for physical damage, loose connections, or dust accumulation, particularly in high-humidity environments. Clean the enclosure with a dry cloth and check LED indicators for fault signals, a red light may indicate a communication failure or power irregularity . Update the firmware periodically to access the latest features and security patches. For HART-enabled devices, use Honeywell’s HART configuration tools to validate sensor calibrations and diagnostics. In case of persistent issues, contact our technical support team for remote troubleshooting or replacement guidance.
Product Assurance
Our company provides a one-year quality warranty for the Honeywell CC-PUIO31, covering hardware failures due to non-human factors. During the warranty period, we will promptly replace any defective components at no additional cost. For discontinued models or urgent requirements, our global supply chain network leverages extensive inventory and strategic partnerships to fulfill orders within tight timelines, even for hard-to-find spare parts. With 17 years of expertise in industrial control distribution, we ensure that your systems benefit from the CC-PUIO31’s advanced capabilities, backed by our commitment to reliable service and technical support. Trust us to deliver solutions that enhance your operational efficiency and maintain the highest standards of industrial automation.E-mail :sales@ygplc.com.
