GE IS200AEPGG1AAA Analog Input Module
Product Overview：GE IS200AEPGG1AAA
The ：GE IS200AEPGG1AAA is a high-precision Analog Input Module designed for industrial automation systems, specifically as part of GE’s Mark VIe control platform for power generation, oil & gas, and heavy machinery applications. Engineered to convert continuous analog signals from field sensors (e.g., temperature transmitters, pressure transducers) into digital data, this module serves as a critical interface between process instrumentation and the distributed control system (DCS). The IS200AEPGG1AAA supports up to 16 isolated input channels, each configurable to accept voltage (0–10 V DC) or current (4–20 mA) signals, making it versatile for monitoring diverse process parameters in harsh industrial environments.
As a key component of the IS200 series, the GE IS200AEPGG1AAA integrates advanced signal conditioning and noise filtering to ensure accurate data acquisition even in high-electromagnetic interference (EMI) settings. Its modular design facilitates seamless integration into GE’s Mark VIe racks, enabling real-time data transmission to the control system for process optimization and fault detection. The module’s built-in self-diagnostics continuously monitor channel health, providing early warnings for signal loss or drift, which is essential for maintaining operational continuity in mission-critical applications like turbine control and pipeline monitoring.
In automation ecosystems, the IS200AEPGG1AAA enhances system reliability by offering galvanic isolation (250 V RMS) between input channels and the control system, protecting against voltage surges and ground loops. Its compatibility with GE’s Proficy software suite allows for remote configuration, calibration, and trend analysis, reducing maintenance downtime and improving diagnostic efficiency. Whether deployed in power plants, refineries, or manufacturing facilities, this module delivers consistent performance, ensuring precise monitoring of process variables and supporting proactive maintenance strategies.
Technical Specifications：GE IS200AEPGG1AAA
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200AEPGG1AAA |
| Manufacturer | GE |
| Product Type | Analog Input Module |
| Platform | Mark VIe |
| Input Channels | 16 isolated channels |
| Input Signal Types | 4–20 mA, 0–10 V DC |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Isolation | 250 V RMS galvanic isolation per channel |
| Physical Dimensions | 177.8 mm (H) × 101.6 mm (W) × 76.2 mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | -40°C to +85°C |
| Mounting | Rack-mounted (19-inch standard) |
| Communication | Serial interface via Mark VIe backplane |
GE IS200AEPGG1AAA
Key Features and Advantages：GE IS200AEPGG1AAA
High-Precision Signal Conditioning: The IS200AEPGG1AAA features 16-bit resolution and ±0.1% accuracy, ensuring precise conversion of analog signals to digital data. Its advanced filtering algorithms suppress high-frequency noise, making it suitable for applications requiring minimal measurement drift, such as turbine temperature monitoring or chemical process control.
Galvanic Isolation: Each input channel is galvanically isolated to 250 V RMS, preventing ground loops and voltage spikes from affecting the control system. This isolation enhances system safety and reliability, particularly in environments with unstable power supplies or high EMI, such as industrial motor drives or offshore platforms.
Modular Design for Easy Integration: The module’s plug-and-play design allows quick replacement in GE’s Mark VIe racks, reducing installation time and minimizing downtime during maintenance. Its standardized form factor and backplane communication protocol ensure compatibility with other IS200 series modules (e.g., digital I/O, communication interfaces), simplifying system expansion.
Comprehensive Diagnostics: Built-in diagnostics monitor channel status, power supply health, and signal integrity in real time. Faults are reported via LED indicators and the control system, enabling rapid identification of issues such as open circuits or out-of-range signals. This proactive approach reduces mean time to repair (MTTR) and supports predictive maintenance strategies.
Wide Environmental Tolerance: Designed to withstand extreme conditions, the IS200AEPGG1AAA operates reliably in temperatures ranging from -40°C to +85°C and resists vibration (up to 5 g) and shock (30 g). Its rugged enclosure and conformal coating protect against dust, moisture, and corrosive elements, making it suitable for harsh industrial environments.
GE IS200AEPGG1AAA
Application Areas：GE IS200AEPGG1AAA
The GE IS200AEPGG1AAA is widely deployed in industries where precise analog signal monitoring is critical for process control and safety:
- Power Generation: Monitors temperature, pressure, and flow parameters in steam and gas turbines, ensuring optimal performance and compliance with emission standards. Used in thermal power plants, combined cycle facilities, and renewable energy systems.
- Oil & Gas: Tracks process variables in refineries, pipelines, and offshore platforms, such as crude oil flow rates, pressure in compression stations, and tank levels. Enables real-time adjustments to maintain operational efficiency and prevent leaks or overloads.
- Manufacturing: Supports quality control in automotive, chemical, and food processing industries by monitoring analog signals from sensors in conveyor systems, mixers, and extruders. Ensures consistent product quality and reduces waste.
- Water/Wastewater Treatment: Measures pH, level, and flow in treatment plants, optimizing chemical dosing and pump operation to meet regulatory requirements.
Specific applications include:
- Condition Monitoring: Integrates with vibration sensors and RTDs to detect early signs of equipment degradation, such as bearing wear in motors or overheating in transformers.
- Process Control Loops: Provides feedback for PID controllers in closed-loop systems, ensuring stable regulation of variables like temperature and pressure.
- Safety Systems: Feeds analog data into emergency shutdown (ESD) systems, enabling rapid response to critical events like overpressure or loss of cooling.
Related Products：GE IS200AEPGG1AAA
- IS200AEPCH1B: A 32-channel analog input module with higher channel density, ideal for large-scale systems requiring extensive signal monitoring.
- IS200DTPGG1B: A digital input module compatible with the IS200AEPGG1AAA, providing a mixed-signal solution for combined discrete and analog control applications.
- IS200BPPCH1B: A redundant power supply module for Mark VIe systems, ensuring uninterrupted operation of the IS200AEPGG1AAA during power fluctuations.
- IS200TCCVH1A: A vibration monitoring module that pairs with the IS200AEPGG1AAA to provide comprehensive machinery health data, supporting predictive maintenance strategies.
- IS200CBLCH1A: High-reliability communication cables for connecting the IS200AEPGG1AAA to remote I/O racks, ensuring low-latency data transmission.
- IS200APPSH1A: Application software module pre-loaded with GE’s control algorithms, enabling customized configuration for the IS200AEPGG1AAA in unique operational scenarios.
- IS200TRBDH1A: Terminal base module that provides a standardized wiring interface for field signals, simplifying installation and reducing cabling errors.
Installation and Maintenance：GE IS200AEPGG1AAA
Installation Preparation:
Before installing the GE IS200AEPGG1AAA, ensure the Mark VIe rack is properly grounded and ventilated. Verify that the module’s input range settings match the connected sensors (e.g., 4–20 mA or 0–10 V DC) using GE’s Proficy Machine Edition software. Mount the module in an available slot within the rack, securing it with the provided screws. Connect shielded cables from field sensors to the module’s terminal block, ensuring proper polarity and grounding to minimize interference. Power up the system and calibrate each channel using factory-recommended procedures to ensure accuracy.
Before installing the GE IS200AEPGG1AAA, ensure the Mark VIe rack is properly grounded and ventilated. Verify that the module’s input range settings match the connected sensors (e.g., 4–20 mA or 0–10 V DC) using GE’s Proficy Machine Edition software. Mount the module in an available slot within the rack, securing it with the provided screws. Connect shielded cables from field sensors to the module’s terminal block, ensuring proper polarity and grounding to minimize interference. Power up the system and calibrate each channel using factory-recommended procedures to ensure accuracy.
Maintenance Recommendations:
- Routine Inspections: Conduct monthly visual checks for loose connections, damaged cables, or overheating signs. Clean the module’s vents with compressed air to prevent dust accumulation that could affect heat dissipation.
- Calibration: Perform annual calibration using GE’s diagnostic tools to verify signal accuracy. Compare measured values against a calibrated signal source and adjust as needed. Document calibration results for compliance and maintenance records.
- Firmware Updates: Periodically update the module’s firmware to access bug fixes and performance improvements, following GE’s official guidelines. Back up all configurations before updating to avoid data loss.
- Spare Parts Management: Store spare IS200AEPGG1AAA modules in static-free packaging at room temperature (20–25°C) with low humidity (<50%). Rotate inventory regularly to ensure components remain within their operational lifespan.
GE IS200AEPGG1AAA
Product Warranty：GE IS200AEPGG1AAA
Our company provides a 12-month quality warranty for the GE IS200AEPGG1AAA, covering hardware defects under normal use. In the event of unexpected failures, we offer prompt replacement services to minimize operational disruptions. For legacy or discontinued models, our global supply chain network specializes in sourcing hard-to-find industrial control parts, ensuring quick delivery for urgent requirements. Our technical support team is available 24/7 to assist with installation, troubleshooting, and software configuration, delivering tailored solutions to keep your automation systems running efficiently.
For sales inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
