GE IC695CPE330 Product Specification
Product Overview
The GE IC695CPE330 is a high-performance CPU module engineered for GE’s RX3i PLC platform, serving as the processing core for industrial automation systems in manufacturing, power generation, oil and gas, and water/wastewater applications. Designed to execute complex control logic with speed and reliability, this module integrates seamlessly with RX3i I/O modules, communication interfaces, and human-machine interfaces (HMIs) to enable real-time monitoring and control of critical processes.
As the central processing unit of the RX3i system, the GE IC695CPE330 features a 1.2 GHz dual-core processor and 512 MB RAM/2 GB flash memory, supporting fast execution of ladder logic, structured text, and function block diagrams—up to 10,000 instructions per millisecond. Its robust architecture includes dual Ethernet ports (10/100/1000 Mbps) for industrial protocols like Modbus TCP/IP, Ethernet/IP, and PROFINET, enabling seamless communication with SCADA systems, HMIs, and other PLCs.
The GE IC695CPE330’s rugged design—including a conformal coating and IP20-rated enclosure—supports operation in temperatures ranging from -25°C to +70°C, with resistance to vibration (10–2000 Hz, 10 G rms) and humidity (5–95% non-condensing). It offers hot standby redundancy when paired with a second GE IC695CPE330, ensuring zero downtime during hardware failures—a critical feature in mission-critical systems like turbine control or chemical batch processing. Front-panel LEDs provide real-time status for power, run mode, and communication, simplifying troubleshooting, while compatibility with GE’s Proficy Machine Edition software allows easy programming and configuration.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC695CPE330 |
| Manufacturer | General Electric (GE) |
| Product Type | CPU Module (Central Processing Unit) |
| Series | RX3i PLC Platform |
| Processor | 1.2 GHz dual-core industrial-grade processor |
| Memory | 512 MB RAM, 2 GB flash memory |
| Communication Ports | 2 × 10/100/1000 Mbps Ethernet (RJ45), 1 × USB 2.0 (configuration) |
| Supported Protocols | Modbus TCP/IP, Ethernet/IP, PROFINET, DNP3, IEC 61850 |
| Physical Dimensions | 115 mm (H) × 220 mm (W) × 125 mm (D) |
| Weight | 1.1 kg |
| Operating Temperature | -25°C to +70°C |
| Humidity | 5–95% non-condensing |
| Power Supply | 24 VDC ±10% (5 W max) |
| Redundancy Support | Hot standby (requires second GE IC695CPE330 and IC695RNR001 redundancy module) |
| Mounting Type | RX3i rack mount (compatible with IC695CHS010 10-slot rack) |
| Certifications | CE, UL 61010-1, ATEX/IECEx Zone 2 |
Main Features and Advantages
High-Speed Processing:
The GE IC695CPE330’s 1.2 GHz dual-core processor executes control logic at up to 10,000 instructions per millisecond, enabling real-time response in time-sensitive applications—such as synchronizing robotic arms in automotive assembly lines or adjusting turbine fuel valves during grid fluctuations. This processing power ensures minimal latency, critical for maintaining precision in processes where even 100 ms delays can impact product quality or safety.
The GE IC695CPE330’s 1.2 GHz dual-core processor executes control logic at up to 10,000 instructions per millisecond, enabling real-time response in time-sensitive applications—such as synchronizing robotic arms in automotive assembly lines or adjusting turbine fuel valves during grid fluctuations. This processing power ensures minimal latency, critical for maintaining precision in processes where even 100 ms delays can impact product quality or safety.
Redundant architecture:
Support for hot standby redundancy—when paired with a second GE IC695CPE330 and IC695RNR001 module—ensures seamless failover (<50 ms) during CPU failures. This redundancy eliminates single points of failure, a must for industries like nuclear power or chemical processing, where unplanned downtime could lead to environmental hazards or production losses.
Support for hot standby redundancy—when paired with a second GE IC695CPE330 and IC695RNR001 module—ensures seamless failover (<50 ms) during CPU failures. This redundancy eliminates single points of failure, a must for industries like nuclear power or chemical processing, where unplanned downtime could lead to environmental hazards or production losses.
Versatile communication:
Dual Gigabit Ethernet ports support multiple industrial protocols (Modbus TCP/IP, Ethernet/IP, PROFINET), enabling integration with SCADA systems, HMIs (like GE IC695HMI300), and third-party devices. For example, the module can communicate with Siemens PLCs via PROFINET and Allen-Bradley systems via Ethernet/IP, simplifying integration in hybrid automation environments.
Dual Gigabit Ethernet ports support multiple industrial protocols (Modbus TCP/IP, Ethernet/IP, PROFINET), enabling integration with SCADA systems, HMIs (like GE IC695HMI300), and third-party devices. For example, the module can communicate with Siemens PLCs via PROFINET and Allen-Bradley systems via Ethernet/IP, simplifying integration in hybrid automation environments.
Rugged environmental resilience:
A conformal coating protects against dust, moisture, and chemical vapors, while the wide operating temperature range (-25°C to +70°C) and vibration resistance ensure reliability in harsh settings—from arctic oil rigs to desert solar farms. ATEX/IECEx Zone 2 certification extends its use to hazardous locations like refineries, where explosive atmospheres are a risk.
A conformal coating protects against dust, moisture, and chemical vapors, while the wide operating temperature range (-25°C to +70°C) and vibration resistance ensure reliability in harsh settings—from arctic oil rigs to desert solar farms. ATEX/IECEx Zone 2 certification extends its use to hazardous locations like refineries, where explosive atmospheres are a risk.
Advanced diagnostics:
Built-in self-tests monitor CPU health, memory integrity, and communication links, with faults logged to flash memory for post-mortem analysis. Front-panel LEDs (Power, Run, Fault, Redundancy Status) provide instant visual feedback, while remote diagnostics via Proficy Machine Edition allow engineers to troubleshoot issues without onsite visits—reducing maintenance costs in remote locations like offshore platforms.
Built-in self-tests monitor CPU health, memory integrity, and communication links, with faults logged to flash memory for post-mortem analysis. Front-panel LEDs (Power, Run, Fault, Redundancy Status) provide instant visual feedback, while remote diagnostics via Proficy Machine Edition allow engineers to troubleshoot issues without onsite visits—reducing maintenance costs in remote locations like offshore platforms.
Seamless RX3i integration:
The GE IC695CPE330 interfaces directly with RX3i I/O modules (e.g., IC695ALG626 analog input, IC695MDL645 discrete output) via the backplane, enabling plug-and-play expansion. Its compatibility with the RX3i rack system (e.g., IC695CHS010) simplifies system design, while support for online programming allows logic modifications without stopping operations—ideal for optimizing batch recipes in food processing or adjusting energy usage in smart grids.
The GE IC695CPE330 interfaces directly with RX3i I/O modules (e.g., IC695ALG626 analog input, IC695MDL645 discrete output) via the backplane, enabling plug-and-play expansion. Its compatibility with the RX3i rack system (e.g., IC695CHS010) simplifies system design, while support for online programming allows logic modifications without stopping operations—ideal for optimizing batch recipes in food processing or adjusting energy usage in smart grids.
Application Areas
-
Manufacturing:
- Serves as the control core for automotive assembly lines, coordinating robotic welding, material handling, and quality inspection stations via Ethernet/IP.
- Manages batch processing in pharmaceutical plants, executing recipes stored in flash memory to ensure consistent drug formulation.
-
Power Generation:
- Controls combined-cycle gas turbines, adjusting fuel flow and air intake based on data from IC695ALG626 analog modules to optimize efficiency.
- Integrates with SCADA systems via DNP3 protocol, providing real-time generator performance data to grid operators.
-
Oil and Gas:
- Manages offshore platform processing systems, regulating separator pressure and flow rates using Modbus TCP/IP to communicate with field devices.
- Executes emergency shutdown (ESD) logic in refineries, triggering valve closures via IC695MDL645 outputs when hazardous conditions are detected.
-
Water/Wastewater:
- Automates treatment plant processes, coordinating pumps, valves, and filters based on sensor inputs to meet discharge standards.
- Communicates with remote monitoring systems via IEC 61850, enabling utility companies to track water quality and consumption.
-
Renewable Energy:
- Optimizes wind farm operations, adjusting turbine pitch and yaw via PROFINET to maximize energy capture while protecting equipment from high winds.
- Manages battery storage systems in solar plants, balancing charge/discharge cycles to stabilize grid output.
Related Products
- GE IC695CHS010: 10-slot rack that houses GE IC695CPE330 and other RX3i modules, providing mechanical stability and backplane connectivity.
- GE IC695PSD140: 24 VDC power supply module that delivers stable power to GE IC695CPE330 and associated I/O modules.
- GE IC695ALG626: Analog input module whose sensor data is processed by GE IC695CPE330 for closed-loop control.
- GE IC695MDL645: Discrete output module actuated by GE IC695CPE330 to control valves, motors, and alarms.
- GE IC695RNR001: Redundancy module enabling hot standby operation between two GE IC695CPE330 CPUs.
- GE IC695HMI300: HMI panel that interfaces with GE IC695CPE330 for operator monitoring and control.
- GE IC695ETM001: Ethernet switch module that extends network connectivity for GE IC695CPE330 in distributed systems.
Installation and Maintenance
Pre-installation preparations: Before installing GE IC695CPE330, verify the IC695CHS010 rack is properly grounded to prevent electrostatic discharge (ESD). Use an ESD wrist strap during handling. Mount the CPU in the rack’s designated slot (typically slot 0 for primary CPU), ensuring secure seating in the backplane. Connect 24 VDC power via IC695PSD140, and Ethernet cables to network switches or HMIs. For redundant setups, install the second GE IC695CPE330 in slot 1 and connect the IC695RNR001 module to enable failover.
Maintenance suggestions: Perform monthly visual inspections of GE IC695CPE330 front-panel LEDs to confirm normal operation (green Run, no Fault). Clean dust from ventilation slots with compressed air quarterly to maintain cooling. Annually, update firmware via Proficy Machine Edition to access security patches and protocol enhancements. Test redundancy by powering down the primary CPU and verifying seamless switchover to the standby unit. Backup logic programs to external storage quarterly to prevent data loss, and replace the module every 10 years or if processing latency exceeds 50 ms, as aging components may impact performance.
