GE IC695CMM002VC PACSystems RX3i Communication Module
Product Overview
The GE IC695CMM002VC is a high-performance communication module engineered for GE’s PACSystems RX3i programmable automation controllers, serving as a critical gateway for data exchange in industrial automation systems. As part of the IC695 Series, this module enables seamless communication between RX3i controllers and a wide range of devices—including HMIs, SCADA systems, and remote I/O networks—across manufacturing, energy, and process industries.
Featuring multi-protocol support, the GE IC695CMM002VC integrates Ethernet/IP, Modbus TCP/IP, and Profibus DP, eliminating the need for multiple specialized modules. Its dual Ethernet ports (10/100/1000 Mbps) support network redundancy, ensuring uninterrupted data flow in mission-critical applications where downtime is costly. The module’s 2500 Vrms galvanic isolation protects against voltage spikes and electromagnetic interference (EMI), a common challenge in factories with heavy machinery or variable frequency drives.
In automation systems, the IC695CMM002VC integrates seamlessly with the RX3i backplane, communicating via the controller’s high-speed bus to minimize latency. Its compact design fits within standard RX3i racks, maximizing space efficiency, while onboard diagnostics—including link status monitoring and error logging—enable proactive fault resolution. By combining versatile protocol support, redundancy, and reliability, the GE IC695CMM002VC enhances system connectivity, simplifies integration, and ensures data integrity in industrial environments where seamless communication is essential.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC695CMM002VC |
| Manufacturer | GE |
| Product Type | Multi-Protocol Communication Module (PACSystems RX3i) |
| Series | IC695 (PACSystems RX3i) |
| Supported Protocols | Ethernet/IP, Modbus TCP/IP, Profibus DP Master/Slave |
| Interfaces | 2x 10/100/1000 Mbps Ethernet (RJ45), 1x Profibus DP (DB9) |
| Isolation Rating | 2500 Vrms (signal to backplane) |
| Data Transfer Rate | Up to 1000 Mbps (Ethernet), 12 Mbps (Profibus DP) |
| Physical Dimensions | 120 mm (H) × 165 mm (W) × 80 mm (D) |
| Weight | 0.5 kg |
| Operating Temperature | -25°C to +70°C |
| Power Requirements | 5 V DC (backplane, 200 mA); 24 V DC (external, 50 mA) |
| Certifications | CE, UL 508, ATEX Zone 2, IEC 61131-2 |
Main Features and Advantages
Multi-protocol flexibility:
The IC695CMM002VC supports Ethernet/IP, Modbus TCP/IP, and Profibus DP, enabling connectivity with diverse industrial devices—from Allen-Bradley HMIs to Siemens PLCs—without protocol converters. This eliminates the need for multiple communication modules, reducing inventory costs and simplifying system design. For example, in a automotive plant, it can simultaneously communicate with Ethernet-based robots and Profibus-driven conveyors.
The IC695CMM002VC supports Ethernet/IP, Modbus TCP/IP, and Profibus DP, enabling connectivity with diverse industrial devices—from Allen-Bradley HMIs to Siemens PLCs—without protocol converters. This eliminates the need for multiple communication modules, reducing inventory costs and simplifying system design. For example, in a automotive plant, it can simultaneously communicate with Ethernet-based robots and Profibus-driven conveyors.
Redundant network support:
Dual 10/100/1000 Mbps Ethernet ports enable ring topology redundancy, where a secondary network path automatically activates if the primary fails. This ensures uninterrupted data flow in critical applications like power plant SCADA systems, minimizing downtime from network faults.
Dual 10/100/1000 Mbps Ethernet ports enable ring topology redundancy, where a secondary network path automatically activates if the primary fails. This ensures uninterrupted data flow in critical applications like power plant SCADA systems, minimizing downtime from network faults.
High-speed data transfer:
With gigabit Ethernet capability, the module handles large datasets—such as real-time production metrics or sensor trends—at speeds up to 1000 Mbps. Profibus DP support (12 Mbps) ensures fast communication with legacy field devices, bridging new and old automation technologies.
With gigabit Ethernet capability, the module handles large datasets—such as real-time production metrics or sensor trends—at speeds up to 1000 Mbps. Profibus DP support (12 Mbps) ensures fast communication with legacy field devices, bridging new and old automation technologies.
Robust isolation:
2500 Vrms signal-to-backplane isolation protects the RX3i controller from voltage transients and ground loops, common in factories with welding equipment or motor drives. This isolation ensures signal integrity, preventing data corruption in noisy electrical environments.
2500 Vrms signal-to-backplane isolation protects the RX3i controller from voltage transients and ground loops, common in factories with welding equipment or motor drives. This isolation ensures signal integrity, preventing data corruption in noisy electrical environments.
Rugged environmental design:
Rated for -25°C to +70°C operating temperatures and ATEX Zone 2 certification, the IC695CMM002VC thrives in harsh settings—from Arctic oil rigs to desert solar farms. Its conformal coating resists dust and moisture, ensuring reliability in washdown areas or humid chemical plants.
Rated for -25°C to +70°C operating temperatures and ATEX Zone 2 certification, the IC695CMM002VC thrives in harsh settings—from Arctic oil rigs to desert solar farms. Its conformal coating resists dust and moisture, ensuring reliability in washdown areas or humid chemical plants.
Seamless RX3i integration:
Designed exclusively for the PACSystems RX3i platform, the module plugs directly into the RX3i backplane, leveraging the controller’s high-speed bus for low-latency communication. It works with GE’s Proficy Machine Edition software for configuration, allowing engineers to map data tags and monitor network health in real time.
Designed exclusively for the PACSystems RX3i platform, the module plugs directly into the RX3i backplane, leveraging the controller’s high-speed bus for low-latency communication. It works with GE’s Proficy Machine Edition software for configuration, allowing engineers to map data tags and monitor network health in real time.
Advanced diagnostics:
Onboard diagnostics track link status, packet errors, and protocol-specific faults, alerting operators via the RX3i controller and front-panel LEDs. This enables proactive troubleshooting—such as identifying a loose Ethernet cable or a failing Profibus node—reducing mean time to repair (MTTR).
Onboard diagnostics track link status, packet errors, and protocol-specific faults, alerting operators via the RX3i controller and front-panel LEDs. This enables proactive troubleshooting—such as identifying a loose Ethernet cable or a failing Profibus node—reducing mean time to repair (MTTR).
Application Areas
The GE IC695CMM002VC excels in industries requiring versatile, reliable communication:
- Manufacturing:
Connects RX3i controllers to HMIs, robotic cells, and MES systems in automotive and electronics plants. Enables real-time production tracking and recipe management across multi-vendor equipment. - Energy Sector:
Links wind turbine controllers to SCADA systems, transmitting performance data (rotor speed, power output) for grid synchronization. Its redundancy ensures communication continuity in remote renewable energy sites. - Chemical Processing:
Integrates with distributed control systems (DCS) to share reactor pressure, temperature, and valve position data. Profibus support connects to legacy analyzers, while Ethernet links to cloud-based analytics platforms. - Water and Wastewater:
Facilitates communication between pump controllers, flow meters, and SCADA systems, enabling remote monitoring of treatment processes. Its rugged design withstands wet, corrosive environments.
Specific applications include coordinating assembly line robots via Ethernet/IP, transmitting turbine data to utility SCADA systems, and linking legacy weigh scales to modern PLCs via Profibus.
Related Products
- GE IC695CMM001 (PACSystems RX3i Communication Module):
A single-protocol Ethernet/IP variant, ideal for systems without Profibus needs. Differs from the IC695CMM002VC in protocol support. - GE IC695CPU310 (PACSystems RX3i Controller):
The central processor that uses the IC695CMM002VC to exchange data with external devices, executing control logic based on incoming information. - GE IC695ESW008 (PACSystems RX3i Ethernet Switch):
An 8-port gigabit switch that extends the IC695CMM002VC’s network reach, supporting redundant ring topologies in large facilities. - GE IC695PNC001 (PACSystems RX3i Profinet Module):
Complements the IC695CMM002VC by adding Profinet support, suitable for European markets with heavy use of this protocol. - GE IC695MDL645 (PACSystems RX3i Digital Input Module):
Works with the communication module to send sensor data (e.g., limit switch status) to remote HMIs for operator visibility. - GE IC695AOG500 (PACSystems RX3i Analog Output Module):
Receives setpoints from SCADA systems via the IC695CMM002VC, adjusting valve positions or pump speeds in closed-loop control.
Installation and Maintenance
Pre-installation preparations:
Ensure the RX3i rack is securely mounted, grounded, and ventilated (ambient temperature -25°C to +70°C). Verify compatibility with the RX3i controller firmware (v10.0 or later) using Proficy Machine Edition. Insert the IC695CMM002VC into an empty slot, securing it with the front panel screw. Connect Ethernet cables to ports 1 and 2 (for redundancy) and Profibus cables to the DB9 connector, using shielded wiring to minimize EMI. Configure protocols and IP addresses via Proficy, mapping data tags between the module and connected devices.
Ensure the RX3i rack is securely mounted, grounded, and ventilated (ambient temperature -25°C to +70°C). Verify compatibility with the RX3i controller firmware (v10.0 or later) using Proficy Machine Edition. Insert the IC695CMM002VC into an empty slot, securing it with the front panel screw. Connect Ethernet cables to ports 1 and 2 (for redundancy) and Profibus cables to the DB9 connector, using shielded wiring to minimize EMI. Configure protocols and IP addresses via Proficy, mapping data tags between the module and connected devices.
Maintenance suggestions:
Perform quarterly visual inspections to check for loose connectors or damaged cables. Monitor network health via Proficy, tracking error rates and link drops. Update firmware annually to address security patches and protocol enhancements. Clean dust from vents biannually with compressed air, especially in dusty environments like cement plants. Test redundancy by disconnecting the primary Ethernet cable to confirm failover to the secondary path. Store spare IC695CMM002VC modules in anti-static packaging at 10–30°C with <60% humidity, testing them yearly to ensure functionality.
Perform quarterly visual inspections to check for loose connectors or damaged cables. Monitor network health via Proficy, tracking error rates and link drops. Update firmware annually to address security patches and protocol enhancements. Clean dust from vents biannually with compressed air, especially in dusty environments like cement plants. Test redundancy by disconnecting the primary Ethernet cable to confirm failover to the secondary path. Store spare IC695CMM002VC modules in anti-static packaging at 10–30°C with <60% humidity, testing them yearly to ensure functionality.
Product Guarantee
Our company offers a one-year quality warranty service for the IC695CMM002VC, covering hardware malfunctions not caused by human factors. During the warranty period, if the product shows abnormal performance or functional failure, we will provide replacement services. In addition, for discontinued models or urgent demands, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts, and provide reliable services to support the continuous and stable operation of industrial systems.
As a leading enterprise in the industrial control industry, established in 2007, we have 17 years of experience. We are an import and export trade distribution company, mainly selling major brands of industrial control parts, with many unpopular discontinued models and a large stock. Our supply channel advantages ensure a large number of in-stock items, meeting customers’ urgent needs for spare parts. We distribute PLC modules, DCS cards, ESD system cards, and more, with a focus on reliable service and timely delivery.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
