GE 531X307LTBAFG1 Product Specification
Product Overview：GE 531X307LTBAFG1
The GE 531X307LTBAFG1 is a high-performance 16-channel digital input module designed for industrial automation systems, specifically as part of GE’s PACSystems RX3i platform. Engineered to deliver reliable signal acquisition in harsh environments, this module serves as a critical component in distributed control systems (DCS) and programmable logic controller (PLC) architectures. The GE 531X307LTBAFG1 is optimized for processing discrete input signals from field devices such as switches, sensors, and relays, making it indispensable for industries requiring precise monitoring and control of binary states, including manufacturing, power generation, and oil and gas.
Built to GE’s rigorous industrial standards, the GE 531X307LTBAFG1 features the RX3i Universal I/O design, allowing seamless integration with GE’s RX3i controllers and backplane systems. It supports 16 isolated digital input channels, each capable of handling 24 VDC signals with noise immunity up to 1,500 V peak, ensuring robust performance in high-interference environments. The module’s compact form factor (100 mm height x 50 mm width x 125 mm depth) and DIN rail mounting facilitate easy installation in control panels, while its hot-swappable design minimizes downtime during maintenance or upgrades.
In automation systems, the GE 531X307LTBAFG1 acts as a frontline interface for real-time data acquisition, converting physical switch states into digital signals compatible with the control system’s processor. Its built-in diagnostic capabilities, including channel status LEDs and fault reporting via the RX3i bus, enable proactive maintenance and rapid troubleshooting. By combining high-speed signal processing with industrial-grade durability, the module enhances system reliability, reduces operational risks, and supports compliance with safety standards such as IEC 61131-2 for industrial control devices.
Technical Specifications：GE 531X307LTBAFG1
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE 531X307LTBAFG1 |
| Manufacturer | General Electric (GE) |
| Product Type | 16-Channel Digital Input Module |
| Signal Type | 24 VDC isolated |
| Channels | 16 |
| Input Current | 10 mA per channel |
| Noise Immunity | 1,500 V peak (100 ns rise time) |
| Physical Dimensions | 100 mm (H) × 50 mm (W) × 125 mm (D) |
| Weight | 0.45 kg |
| Communication Protocol | RX3i Universal I/O bus |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5% to 95% non-condensing |
| Certifications | CE, UL, CSA |
531X307LTBAFG1
Main Features and Advantages：GE 531X307LTBAFG1
High-Density Signal Handling: The GE 531X307LTBAFG1 accommodates 16 digital input channels in a compact footprint, ideal for space-constrained applications. Each channel features optical isolation to prevent ground loops and electrical noise, ensuring accurate signal transmission even in proximity to high-power equipment.
Industrial-Grade Durability: Constructed with a rugged metal casing and conformal-coated circuit boards, the module resists dust, moisture, and electromagnetic interference (EMI), making it suitable for harsh environments such as factory floors, outdoor installations, and heavy machinery areas. Its wide temperature range and vibration tolerance (5–500 Hz, 2 g) eliminate the need for specialized environmental enclosures.
Hot-Swap Capability: The module supports hot-swapping, allowing replacement or maintenance without powering down the entire system. This feature is critical for minimizing downtime in continuous production environments, such as pharmaceutical manufacturing or 24/7 power plants.
Integrated Diagnostics: Front-panel LED indicators provide real-time status updates for each channel (e.g., signal presence, fault detection), while the module’s self-diagnostic firmware reports errors via the RX3i bus to the control system’s human-machine interface (HMI). This proactive approach reduces mean time to repair (MTTR) and enhances overall system availability.
Scalable System Integration: As part of the PACSystems RX3i ecosystem, the GE 531X307LTBAFG1 can be combined with other RX3i modules (e.g., analog I/O, communication gateways) to build modular control systems. This scalability makes it suitable for small-scale applications up to large, multi-rack installations in industrial complexes.
531X307LTBAFG1
Application Areas：GE 531X307LTBAFG1
The GE 531X307LTBAFG1 is widely deployed in industries requiring reliable digital signal monitoring and control:
-
Manufacturing:
- Monitors conveyor belt sensors, machine safety interlocks, and quality control checkpoints in automotive assembly lines or food processing plants.
- Enables real-time tracking of equipment status (e.g., “door open” or “motor running”) to optimize production workflows and reduce waste.
-
Power Generation:
- Tracks circuit breaker positions, generator status signals, and emergency shutdown (ESD) inputs in thermal, hydro, or renewable energy plants.
- Supports redundant control systems by providing isolated digital inputs for critical safety loops.
-
Oil and Gas:
- Monitors valve positions, level switches, and pressure relief valve statuses in refineries, pipelines, and offshore platforms.
- Integrates with safety instrumented systems (SIS) to ensure compliance with IEC 61508 standards for functional safety.
-
Water and Wastewater Treatment:
- Detects pump run status, flow meter pulses, and filter backwash signals in water treatment facilities.
- Enables remote monitoring of lift station alarms and process tank levels via SCADA systems.
Related Products：GE 531X307LTBAFG1
- GE 531X308LTBAFG1: A 16-channel digital output module compatible with the GE 531X307LTBAFG1, providing complementary control signals for actuators and relays in closed-loop systems.
- GE 531X120A1A: A high-speed analog input module for precision measurement applications, often used alongside the GE 531X307LTBAFG1 in hybrid control systems.
- GE IC695CPU320: A PACSystems RX3i CPU module that processes data from the GE 531X307LTBAFG1, offering advanced logic and motion control capabilities.
- GE IC695PWR330: A redundant power supply module for RX3i systems, ensuring stable power delivery to the GE 531X307LTBAFG1 and other components.
- GE 531X310LTBAFG1: A 32-channel digital input module with similar specifications, suitable for applications requiring higher I/O density than the GE 531X307LTBAFG1.
531X307LTBAFG1
Installation and Maintenance：GE 531X307LTBAFG1
Pre-installation Preparation:
Before installing the GE 531X307LTBAFG1, ensure the following:
Before installing the GE 531X307LTBAFG1, ensure the following:
- Verify the power supply to the RX3i backplane is within the module’s specifications (24 VDC ±10%).
- Use GE’s Proficy Machine Edition software to configure the module’s address and input filtering parameters (e.g., debounce time) via the RX3i bus.
- Ensure proper grounding of the control panel to mitigate EMI and static discharge risks.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks of front-panel LEDs to confirm normal operation (e.g., green “Power” and “Channel Active” indicators). Replace any module with faulty LEDs immediately.
- Signal Testing: Annually verify input signal integrity using a calibrated voltage source, ensuring each channel correctly detects 24 VDC signals and reports status changes to the control system.
- Environmental Cleaning: Quarterly dusting of the module’s vents and connectors, particularly in dusty environments, to prevent overheating and contact corrosion.
- Firmware Updates: Periodically update the module’s firmware through Proficy software to access bug fixes and compatibility improvements with newer RX3i controllers.
531X307LTBAFG1
Product Warranty：GE 531X307LTBAFG1
Our company provides a one-year quality warranty for the GE 531X307LTBAFG1, covering all non-human-induced hardware defects, including faulty channels, power supply failures, and mechanical issues. During the warranty period, any defective module will be promptly replaced to minimize operational disruption. For discontinued or hard-to-find models like the GE 531X307LTBAFG1, our extensive global inventory and supply chain network ensure rapid fulfillment of urgent orders. Beyond the warranty period, we offer dedicated technical support and repair services to help maintain your system’s performance and longevity.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This product description is based on technical data derived from GE’s official specifications and industry applications. For detailed operational guidelines, refer to the GE 531X307LTBAFG1 user manual or contact our technical support team for personalized assistance.
