EMERSON 5X00273G01 | DeltaV Analog Input Module | 5X00121G01

Description

Product Overview: EMERSON 5X00273G01 DeltaV Analog Input Module

Technical Specifications: EMERSON 5X00273G01 DeltaV Analog Input Module

Parameter Name	Parameter Value
Product Model	5X00273G01
Manufacturer	Emerson
Product Type	Analog Input Module
Channels	16 isolated, universal (4–20 mA, 0–10 V DC, RTD, thermocouple)
Input Resolution	16-bit
Isolation	Galvanic isolation (250 V AC/DC per channel)
Power Supply	24 V DC ±10% (from DeltaV backplane)
Physical Dimensions	101.6 mm (H) × 177.8 mm (W) × 63.5 mm (D)
Weight	0.9 kg
Operating Temperature	-40°C to +70°C
Mounting	Rack-mounted in DeltaV chassis
Certifications	CE, FM, CSA, ATEX (for hazardous areas)

5X00273G01

5X00273G01

Key Features and Advantages: EMERSON 5X00273G01 DeltaV Analog Input Module

Comprehensive Diagnostics: Real-time diagnostics monitor channel health, including open/short circuit detection, overrange conditions, and calibration status. Alerts are transmitted to the DeltaV operator station, enabling rapid response to faults and reducing troubleshooting time.

5X00273G01

Application Areas: EMERSON 5X00273G01 DeltaV Analog Input Module

• Oil & Gas: Monitoring pressure transmitters in upstream wellheads, flow meters in pipelines, and temperature sensors in refinery processes to ensure safe and efficient operations.
• Chemical Processing: Acquiring data from pH meters, level transmitters, and gas analyzers in reactor systems, enabling real-time control of chemical reactions and compliance with environmental regulations.
• Power Generation: Measuring steam turbine temperatures, boiler pressures, and generator winding currents in thermal and combined-cycle power plants, supporting load balancing and grid stability.
• Water/Wastewater: Monitoring flow rates, chlorine levels, and pump pressures in treatment facilities to optimize water quality and distribution efficiency.

• Process Control Loops: Providing feedback signals for PID controllers to maintain setpoints in critical processes like distillation, blending, and polymerization.
• Safety Instrumented Systems (SIS): Integrating with emergency shutdown systems by acquiring analog signals from safety-rated sensors, ensuring rapid response to abnormal conditions.
• Condition Monitoring: Capturing vibration and temperature data from rotating equipment (e.g., pumps, motors) for predictive maintenance analytics via Emerson’s AMS Suite.


  5X00273G01

Related Products: EMERSON 5X00273G01 DeltaV Analog Input Module

1. EMERSON 5X00272G01 DeltaV Digital Input Module: A companion module for discrete signal acquisition, ideal for integrating binary status signals (e.g., valve positions, motor starters) with the 5X00273G01.
2. EMERSON 5X00285G01 DeltaV Analog Output Module: Provides analog output channels for controlling actuators and valves, complementing the 5X00273G01 in closed-loop control systems.
3. EMERSON 5X00140G01 DeltaV Controller Module: A high-performance controller that processes data from the 5X00273G01, enabling real-time control and advanced algorithm execution.
4. EMERSON 5X00223G01 DeltaV Communications Module: Enables integration with third-party systems via protocols like Modbus RTU/TCP, Profibus DP, or HART, extending the 5X00273G01’s connectivity.
5. EMERSON 5X00274G01 DeltaV High-Density Analog Input Module: A 32-channel variant for high-density applications, offering double the channel capacity of the 5X00273G01 in a compact form factor.
6. EMERSON 5X00195G01 DeltaV Power Supply Module: Provides redundant power to the DeltaV chassis, ensuring uninterrupted operation of the 5X00273G01 in mission-critical systems.
7. EMERSON 5X00265G01 DeltaV Thermocouple Input Module: Specialized for thermocouple signals, offering enhanced noise immunity for high-temperature measurement applications.

Installation and Maintenance: EMERSON 5X00273G01 DeltaV Analog Input Module

• Routine Checks: Inspect the module quarterly for loose connections, damaged cables, or physical wear. Use DeltaV’s diagnostic tools to verify channel accuracy and perform loop tests with a calibrated signal source.
• Calibration: Perform annual calibration of field instruments and module inputs to ensure measurement precision. Document calibration results for compliance with ISO 9001 and industry-specific standards.
• Firmware Updates: Periodically update the module’s firmware via DeltaV’s Asset Management Software to access new features and security patches, following Emerson’s recommended procedures.
• Spare Parts Management: Maintain a spare 5X00273G01 module in a static-free environment, ensuring rapid replacement in case of failure. Store modules at 20–25°C with relative humidity below 60% to prevent component degradation.


  5X00273G01

Product Warranty: EMERSON 5X00273G01 DeltaV Analog Input Module
