CAMERON AAP3798102-00130 Solenoid Valve Module
Product Overview ：CAMERON AAP3798102-00130
The CAMERON AAP3798102-00130 is a high-reliability Solenoid Valve Module engineered for critical wellhead control and safety systems in the oil & gas industry. As part of Cameron’s advanced 井口控制系统 (Wellhead Control Systems) portfolio, this module serves as a pivotal component in managing hydraulic or pneumatic fluid flow for automated valve actuation, emergency shutdown (ESD) sequences, and pressure regulation. Designed to withstand extreme industrial environments, the AAP3798102-00130 ensures precise control over wellsite operations, minimizing downtime and enhancing safety in onshore and offshore applications.
Featuring a dual-coil configuration and fail-safe design, the CAMERON AAP3798102-00130 delivers reliable switching performance even in harsh conditions, including high pressure, vibration, and temperature fluctuations. The module integrates seamlessly with Cameron’s QCS (Quick Connect System) and other third-party control platforms, enabling real-time monitoring and remote operation via digital interfaces. Its compact form factor and rugged construction make it ideal for space-constrained installations in subsea manifolds, production trees, and surface control panels.
In automation ecosystems, the AAP3798102-00130 acts as a critical link between control systems and field devices, translating electronic signals into mechanical actions to ensure compliance with industry standards like API 6A and ISO 13679. By combining precision engineering with robust diagnostics, this module reduces the risk of operational failures, protects high-value assets, and supports sustainable oil & gas production practices.
Technical Specifications ：CAMERON AAP3798102-00130
| Parameter Name | Parameter Value |
|---|---|
| Product Model | AAP3798102-00130 |
| Manufacturer | Cameron (Schlumberger) |
| Product Type | Solenoid Valve Module |
| Input Voltage | 24 V DC ±10% |
| Operating Pressure | 3,000–15,000 psi (207–1,034 bar) |
| Flow Rate | 5–15 L/min (dependent on pressure) |
| Physical Dimensions | 152 mm (H) × 89 mm (W) × 102 mm (D) |
| Weight | 1.8 kg |
| Temperature Range | -40°C to +125°C |
| Mounting | Panel-mounted or direct valve integration |
| Certifications | API 6A, NACE MR0175, IP67 |
| Media Compatibility | Hydraulic oil, natural gas, methanol |
CAMERON AAP3798102-00130
Key Features and Advantages ：CAMERON AAP3798102-00130
Dual-Coil Redundancy: The AAP3798102-00130 features two independent solenoid coils, allowing for redundant operation and fail-safe switching. This design ensures continuous functionality even if one coil fails, critical for maintaining wellsite safety during maintenance or fault conditions.
Extreme Environment Rating: With an IP67 ingress protection rating and NACE-compliant materials, the module resists corrosion, dust, and water intrusion, making it suitable for subsea, offshore, and high-humidity environments. Its ability to operate across a wide temperature range (-40°C to +125°C) further enhances versatility in global oil & gas operations.
Precision Flow Control: The module’s high-flow design and rapid response time (≤10 ms) enable precise regulation of fluid flow, critical for managing well pressure, choke operations, and ESD scenarios. Its compatibility with both hydraulic and pneumatic systems reduces the need for multiple component types, simplifying inventory management.
Easy Integration: Designed for plug-and-play installation, the AAP3798102-00130 connects directly to Cameron’s control panels and third-party PLC/DCS systems via standard electrical interfaces. This interoperability minimizes installation time and supports retrofitting into existing infrastructure.
Advanced Diagnostics: Built-in status indicators and fault detection mechanisms allow operators to monitor coil health, voltage levels, and flow performance in real time, reducing troubleshooting time and enabling proactive maintenance.
CAMERON AAP3798102-00130
Application Areas ：CAMERON AAP3798102-00130
The CAMERON AAP3798102-00130 is exclusively designed for mission-critical applications in the oil & gas sector:
- Subsea Production: Controls subsea tree valves, hydraulic actuators, and chemical injection systems in deepwater environments, ensuring reliable operation under high pressure and harsh marine conditions.
- Onshore Wellheads: Manages surface safety valves, choke manifolds, and production flowlines, supporting automated well control and compliance with environmental regulations.
- Refining & Petrochemicals: Integrates with pressure relief systems and emergency shutdown networks in refineries, minimizing the risk of leaks or explosions.
- Drilling Rigs: Facilitates blowout preventer (BOP) actuation and mud circulation control, enhancing safety during drilling and completion operations.
Specific use cases include:
- Emergency Shutdown (ESD) Systems: Triggers rapid valve closure in response to overpressure, leaks, or fire, preventing uncontrolled fluid release.
- Well Testing & Intervention: Enables precise control of flowback operations and well stimulation processes, optimizing production efficiency.
- Remote Operations: Supports telemetry-based control via SCADA systems, allowing operators to manage wellsite functions from centralized command centers.
Related Products
- CAMERON AAP3798102-00120: A low-pressure variant (1,500 psi) designed for lighter-duty applications, ideal for gas lift systems or low-pressure wells.
- CAMERON AAP3798102-00140: Features a 12 V DC input for battery-powered systems, suitable for remote or solar-powered wellheads.
- CAMERON AAP3798103-00130: A three-way solenoid valve module for complex fluid routing in multiphase production systems.
- CAMERON QCS-100 Control Panel: A centralized control platform that integrates with the AAP3798102-00130 for real-time monitoring and diagnostics.
- CAMERON HPS-400 Hydraulic Power Unit: Provides hydraulic supply for solenoid actuation, sets (used in conjunction) with the module in high-pressure applications.
- CAMERON SVI-3000 Position Indicator: Monitors valve position and transmits feedback to the control system, enhancing closed-loop control accuracy.
- CAMERON AAP3798202-00130: A redundant solenoid module with built-in diagnostics for critical ESD systems, offering enhanced fault tolerance.
- CAMERON API 6A Valves: Compatible valve models (e.g., CHK series) for seamless integration into wellhead control systems.
CAMERON AAP3798102-00130
Installation and Maintenance ：CAMERON AAP3798102-00130
Installation Preparation:
Before installing the CAMERON AAP3798102-00130, verify the compatibility of electrical supply (24 V DC) and hydraulic/pneumatic media with the module’s specifications. Ensure proper grounding and use shielded cables to minimize electromagnetic interference. Mount the module in a vertical orientation within the control panel, allowing adequate clearance for heat dissipation and easy access to terminals. Pressure test the entire system after installation to confirm leak-free operation.
Before installing the CAMERON AAP3798102-00130, verify the compatibility of electrical supply (24 V DC) and hydraulic/pneumatic media with the module’s specifications. Ensure proper grounding and use shielded cables to minimize electromagnetic interference. Mount the module in a vertical orientation within the control panel, allowing adequate clearance for heat dissipation and easy access to terminals. Pressure test the entire system after installation to confirm leak-free operation.
Maintenance Recommendations:
- Routine Inspections: Conduct quarterly visual checks for signs of corrosion, loose connections, or fluid leaks. Use a multimeter to verify coil resistance and voltage supply stability.
- Function Testing: Perform annual actuation tests to ensure rapid response and proper valve positioning. Calibrate pressure sensors and flow meters integrated with the module as part of routine maintenance.
- Environmental Cleaning: Clean the module’s exterior with a non-corrosive solvent to remove dust, salt deposits, or chemical residues, particularly in offshore or harsh onshore environments.
- Spare Parts Inventory: Maintain a spare AAP3798102-00130 module in a dry, temperature-controlled environment to minimize downtime in case of unexpected failure.
CAMERON AAP3798102-00130
Product Warranty ：CAMERON AAP3798102-00130
Our company provides a 12-month quality warranty for the CAMERON AAP3798102-00130, covering hardware defects arising from non-human causes. During the warranty period, we offer prompt replacement services for modules experiencing performance anomalies or functional failures. For discontinued models or urgent requirements, our global supply chain network ensures rapid delivery of rare or legacy components, supporting uninterrupted operation of industrial systems. Our technical support team is available 24/7 to assist with installation guidance, troubleshooting, and system optimization, ensuring long-term reliability and customer satisfaction.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
