Bently Nevada 3500/54 133396-01 Communication Gateway Module
Product Overview：Bently Nevada 3500/54 133396-01
The Bently Nevada 3500/54 133396-01 is a high-performance Communication Gateway Module designed as a critical component of Bently Nevada’s 3500 Series Machinery Protection System. Engineered to facilitate seamless data exchange between the 3500 framework and higher-level automation systems, this module serves as a bridge between machine health monitoring data and plant-wide control networks. As a dual-channel communication hub, the 3500/54 133396-01 supports multiple industrial protocols, enabling real-time transmission of vibration, temperature, and process data to DCS, PLC, or SCADA systems in industries such as oil & gas, power generation, and manufacturing.
Featuring a rugged industrial design, the 3500/54 133396-01 ensures reliable operation in harsh environments, with built-in redundancy to minimize downtime. It integrates advanced diagnostic capabilities to monitor communication integrity, alerting operators to network anomalies or protocol mismatches. The module’s compatibility with Bently Nevada’s 3500 Series Configuration Software simplifies setup and troubleshooting, allowing users to configure protocol parameters, data mapping, and alarm thresholds with precision. By enabling centralized monitoring of critical machinery, the 3500/54 133396-01 enhances predictive maintenance capabilities and reduces the risk of unplanned outages.
Within the 3500 Series ecosystem, the 3500/54 133396-01 plays a pivotal role in system scalability, supporting up to two independent communication paths (e.g., MODBUS RTU and Ethernet/IP) simultaneously. This dual-protocol capability eliminates the need for separate interface modules, streamlining hardware requirements and reducing integration complexity. Whether deployed in standalone machinery protection systems or large-scale industrial networks, this module ensures seamless data flow, empowering operators to make informed decisions for optimizing equipment performance and safety.
Technical Specifications：Bently Nevada 3500/54 133396-01
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 3500/54 133396-01 |
| Manufacturer | Bently Nevada |
| Product Type | Communication Gateway Module |
| Protocol Support | MODBUS RTU, Ethernet/IP, Profibus DP |
| Physical Dimensions | 10.16 cm (H) × 16.51 cm (W) × 22.86 cm (D) |
| Weight | 1.2 kg |
| Power Supply | 19.2–26.4 V DC (redundant inputs) |
| Operating Temperature | -40°C to +85°C |
| Mounting | Rack-mounted in 3500 Series enclosure |
| Certifications | API 670, IEC 61000-6-2, IEC 61000-6-4 |
| Data Transfer Rate | Up to 100 Mbps (Ethernet), 115.2 kbps (serial) |
| Redundancy | Dual-channel, hot-swappable |
Bently 350054 133396-01
Key Features and Advantages：Bently Nevada 3500/54 133396-01
Multi-Protocol Connectivity: The 3500/54 133396-01 supports simultaneous operation of multiple industrial communication protocols, enabling integration with diverse control systems without additional hardware. This flexibility reduces reliance on custom interfaces and simplifies system expansion.
Redundant Architecture: With dual independent communication channels and redundant power inputs, the module ensures continuous data transmission even if one channel fails. Hot-swappable design allows maintenance without interrupting system operation, critical for mission-critical applications.
Advanced Diagnostics: Built-in diagnostics monitor protocol errors, network latency, and power supply status in real time. LED indicators and configurable alarms provide immediate feedback on module health, minimizing troubleshooting time and enhancing system reliability.
Ease of Configuration: The module is fully configurable via Bently Nevada’s 3500 Series Software, offering a user-friendly interface for setting up data points, baud rates, and security parameters. Predefined data templates for vibration and process variables accelerate commissioning.
Rugged Industrial Design: Constructed with a metal enclosure and conformal coating, the 3500/54 133396-01 withstands high vibration, temperature fluctuations, and electromagnetic interference, ensuring long-term performance in offshore platforms, power plants, and heavy manufacturing environments.
Scalability: Supports up to 128 data points per channel, allowing seamless integration with large-scale monitoring systems. Its modular design enables easy addition of extra communication channels as system requirements evolve.
Bently 350054 133396-01
Application Areas：Bently Nevada 3500/54 133396-01
The Bently Nevada 3500/54 133396-01 is essential in industries where real-time machinery data is critical for operational efficiency and safety:
- Oil & Gas: Integrates vibration and temperature data from turbines, compressors, and pumps into refinery DCS systems, enabling early detection of bearing wear or misalignment in offshore and onshore facilities.
- Power Generation: Transmits critical data from steam and gas turbines to plant-wide SCADA systems, supporting load balancing and compliance with grid stability standards in thermal and renewable energy plants.
- Manufacturing: Connects machinery protection systems to PLC-based production lines in automotive and chemical plants, ensuring real-time monitoring of conveyor systems, motors, and high-speed rotating equipment.
- Marine Engineering: Facilitates data exchange between shipboard machinery monitoring systems and bridge control panels, enhancing safety and maintenance planning for marine turbines and propulsion systems.
Specific applications include:
- Predictive Maintenance: Enables remote monitoring of machinery health via Ethernet/IP, allowing maintenance teams to analyze trends and schedule repairs proactively.
- Safety System Integration: Transmits alarm signals from the 3500 Series to ESD systems, ensuring rapid response to critical faults.
- Historical Data Logging: Supports data logging to historians via MODBUS, enabling long-term trend analysis and regulatory compliance reporting.
Related Products：Bently Nevada 3500/54 133396-01
- 3500/92 Communication Gateway: A higher-performance variant with additional protocol support (e.g., OPC UA), ideal for complex industrial networks.
- 3500/22M Proximitor Monitor: Works alongside the 3500/54 133396-01 to provide vibration and displacement data, forming a complete machinery protection solution.
- 3500/42M Vibration Monitor: Supplies real-time vibration measurements for integration via the 3500/54 133396-01 in multi-module setups.
- 3500/05 Rack Enclosure: Houses the 3500/54 133396-01 and other 3500 Series modules, providing a centralized platform for data acquisition and communication.
- 3500/32M Relay Module: Triggers physical alarms or shutdowns based on data transmitted through the 3500/54 133396-01, enhancing safety control.
- 3500/53 Speed/Torque Monitor: Complements the gateway by providing rotational speed data for synchronization with control systems.
- 3300 XL Series Proximity Probes: Sensors that feed vibration data into the 3500 Series, with signals transmitted via the 3500/54 133396-01.
- 3500/44M Rack Interface Module: Manages power and communication within the 3500 Series rack, ensuring stable operation of the gateway module.
Bently 350054 133396-01
Installation and Maintenance：Bently Nevada 3500/54 133396-01
Installation Preparation:
Before installing the Bently Nevada 3500/54 133396-01, ensure the 3500 Series rack is properly grounded and powered. Verify compatibility with target control systems and select appropriate communication protocols (e.g., MODBUS for legacy systems, Ethernet/IP for modern setups). Mount the module in an available slot within the rack, securing it with the provided hardware. Connect shielded cables for serial or Ethernet connections to minimize interference, and use the 3500 Series software to configure IP addresses, baud rates, and data mapping.
Before installing the Bently Nevada 3500/54 133396-01, ensure the 3500 Series rack is properly grounded and powered. Verify compatibility with target control systems and select appropriate communication protocols (e.g., MODBUS for legacy systems, Ethernet/IP for modern setups). Mount the module in an available slot within the rack, securing it with the provided hardware. Connect shielded cables for serial or Ethernet connections to minimize interference, and use the 3500 Series software to configure IP addresses, baud rates, and data mapping.
Maintenance Recommendations:
- Routine Checks: Perform monthly inspections to ensure secure cable connections and monitor LED status indicators for abnormal (e.g., fault lights). Clean the module’s vents to prevent dust accumulation that could affect thermal performance.
- Firmware Updates: Periodically update the module’s firmware using Bently Nevada’s official tools to access new protocol support and security patches. Backup configuration files before updates to prevent data loss.
- Redundancy Testing: Quarterly test dual-channel redundancy by simulating a channel failure to ensure seamless failover. Document test results to validate system reliability.
- Spare Parts Management: Store spare 3500/54 133396-01 modules in a controlled environment (10–30°C, <60% humidity) in static-proof packaging. Rotate inventory to ensure shelf-life integrity for rapid deployment during emergencies.
Bently 350054 133396-01
Product Warranty：Bently Nevada 3500/54 133396-01
Our company provides a 12-month quality warranty for the Bently Nevada 3500/54 133396-01, covering hardware defects under normal use. In the event of performance issues, we offer prompt replacement services to minimize operational disruptions. For discontinued or legacy models like the 3500/54 133396-01, our global supply chain network specializes in sourcing rare industrial control components, ensuring quick turnaround for urgent needs. Our technical support team is available 24/7 to assist with installation, protocol configuration, and troubleshooting, delivering tailored solutions to keep your automation systems running reliably.
For sales inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
