BENTLY 3500/15 114M5330-01 Product Specification
Product Overview: BENTLY 3500/15 114M5330-01
The BENTLY 3500/15 114M5330-01 is a low voltage DC power supply module designed for the Bently Nevada 3500 Series Machinery Protection System, a globally recognized solution for real-time monitoring of critical rotating equipment. Engineered to deliver stable and reliable power distribution, this module ensures continuous operation of the 3500 system’s monitoring and control modules in industrial environments such as power plants, oil refineries, and manufacturing facilities.
As a core component of the 3500 Series, the BENTLY 3500/15 114M5330-01 converts input voltages (20–30 VDC) into regulated outputs compatible with other 3500 modules, including vibration monitors, speed sensors, and communication gateways. Its compact design (120.7 mm × 50.8 mm × 251.5 mm) and DIN rail mounting allow seamless integration into the 3500 rack, supporting both single and redundant power configurations. This redundancy feature ensures uninterrupted system operation, even during module replacement or maintenance.
In automation systems, the BENTLY 3500/15 114M5330-01 plays a critical role in maintaining equipment integrity by providing consistent power to monitoring modules. Its wide input voltage range and robust construction (withstand -40°C to +70°C temperatures) make it suitable for harsh industrial conditions, while LED indicators for power status and fault detection enable proactive maintenance. By ensuring stable power delivery, this module contributes to the 3500 System’s ability to detect anomalies in rotating machinery, such as turbines and compressors, thereby reducing downtime and optimizing operational efficiency.
Technical Specifications: BENTLY 3500/15 114M5330-01
| Parameter Name | Parameter Value |
|---|---|
| Product Model | BENTLY 3500/15 114M5330-01 |
| Manufacturer | Bently Nevada |
| Product Type | Low Voltage DC Power Supply Module |
| Input Voltage | 20–30 VDC |
| Output Voltage | Regulated DC outputs for 3500 Series modules |
| Physical Dimensions | 120.7 mm (H) × 50.8 mm (W) × 251.5 mm (D) |
| Weight | 1.39 kg |
| Country of Origin | United States |
| Redundancy Support | Dual power supply configuration for fault tolerance |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5%–95% non-condensing |
| Communication Protocol | RS485 (for diagnostic and configuration purposes) |
| Installation | DIN rail mounting in 3500 Series rack |
3500/15 114M5330-01
Main Features and Advantages: BENTLY 3500/15 114M5330-01
Wide Input Voltage Range: The BENTLY 3500/15 114M5330-01 accepts input voltages from 20–30 VDC, accommodating fluctuations in industrial power systems. This flexibility reduces the need for external voltage regulators, simplifying system design and lowering costs.
Redundant Power Architecture: By supporting dual power supply setups, the module ensures continuous operation even if one supply fails. This redundancy is critical in mission-critical applications, such as offshore oil platforms or nuclear power plants, where downtime can lead to significant financial losses.
Robust Environmental Performance: Built to withstand extreme temperatures (-40°C to +70°C) and harsh conditions, the module is ideal for environments with high vibration or humidity. Its rugged design minimizes maintenance requirements and extends service life.
Real-Time Diagnostic Capabilities: LED indicators provide instant feedback on power status, fault conditions, and module health. This allows operators to identify and resolve issues promptly, preventing cascading failures in the monitoring system.
Seamless Integration: As part of the 3500 Series ecosystem, the BENTLY 3500/15 114M5330-01 works seamlessly with Bently Nevada’s vibration monitoring modules (e.g., 3500/42, 3500/45) and communication gateways (e.g., 3500/92). This integration ensures a unified platform for machinery protection and data analysis.
3500/15 114M5330-01
Application Areas: BENTLY 3500/15 114M5330-01
The BENTLY 3500/15 114M5330-01 is widely used in industries where reliable power supply is essential for machinery protection:
-
Power Generation:
- Supports gas and steam turbine monitoring systems by providing stable power to vibration sensors and control modules. Ensures early detection of bearing wear or imbalance, preventing catastrophic failures in power plants.
-
Oil and Gas:
- Deployed in offshore platforms and refineries to power monitoring systems for compressors, pumps, and turbines. Redundant power configurations maintain system availability in remote or harsh environments.
-
Manufacturing:
- Integrates with production line equipment, such as high-speed motors and conveyor systems, to monitor vibration and ensure quality control. Enables predictive maintenance to reduce unplanned downtime.
-
Water and Wastewater Treatment:
- Powers pumps and agitators in treatment plants, ensuring continuous operation and regulatory compliance. Diagnostic features help identify equipment degradation before it affects water quality.
Related Products: BENTLY 3500/15 114M5330-01
- BENTLY 3500/22 106M1081-01: A framework interface module that connects the 3500 Series rack to host systems, enabling data transmission to control rooms or cloud platforms.
- BENTLY 3500/42 114M5329-01: A vibration monitoring module for acceleration and speed measurements, often paired with the BENTLY 3500/15 114M5330-01 in rotating machinery protection systems.
- BENTLY 3500/45 114M5335-01: Monitors axial displacement and differential expansion in turbines, relying on the BENTLY 3500/15 114M5330-01 for stable power supply.
- BENTLY 3500/92 118M0915-01: A communication gateway module that converts 3500 Series data into protocols like Modbus or OPC UA, enhancing interoperability with third-party systems.
- BENTLY 3500/05 131150-01: The 3500 Series instrument frame, providing mechanical and electrical infrastructure for the BENTLY 3500/15 114M5330-01 and other modules.
3500/15 114M5330-01
Installation and Maintenance: BENTLY 3500/15 114M5330-01
Installation Preparation:
Before installing the BENTLY 3500/15 114M5330-01, verify the following:
Before installing the BENTLY 3500/15 114M5330-01, verify the following:
- Ensure the input voltage matches the module’s requirements (20–30 VDC). Use a multimeter to check power supply stability.
- Clean the 3500 Series rack to remove dust or debris that could affect module performance. Align the module with the left-side slots of the rack, as specified in the 3500 Series installation manual.
- If configuring redundant power, install a second BENTLY 3500/15 114M5330-01 in the adjacent slot and connect both to the same power source for automatic failover.
Maintenance Recommendations:
- Regularly inspect the module’s LED indicators to ensure normal operation. A blinking red LED indicates a fault, requiring immediate investigation.
- Clean the module’s vents and connectors quarterly to prevent dust accumulation, which can cause overheating. Use compressed air or a soft brush for gentle cleaning.
- Update the module’s firmware periodically using Bently Nevada’s official software tools to access the latest features and bug fixes.
- Perform annual functional tests to verify power output stability and redundancy switching. Document results to track long-term performance.
3500/15 114M5330-01
Product Warranty: BENTLY 3500/15 114M5330-01
Our company provides a one-year quality warranty for the BENTLY 3500/15 114M5330-01, covering hardware failures due to non-human factors. During the warranty period, we will replace the product if it exhibits performance anomalies or functional failures. For discontinued models or urgent needs, our global supply chain network ensures rapid response to scarce spare parts requests, supporting the continuous and stable operation of industrial systems.
Note: This product description is based on publicly available technical data and industry applications. For detailed specifications, consult the official Bently Nevada datasheet or contact our technical support team.
