BENTLY 330100-90-00 Proximity Probe
Product Overview: BENTLY 330100-90-00
The BENTLY 330100-90-00 proximity probe is a high-precision industrial sensor engineered for real-time monitoring of shaft vibration and displacement in rotating machinery. As a core component of Bently Nevada’s 3300 Series Machinery Health Monitoring System, this probe utilizes eddy current technology to deliver accurate measurements, enabling early detection of mechanical issues such as misalignment, bearing wear, or imbalance. The 330100-90-00 is designed to interface seamlessly with Bently Nevada’s Proximitor modules, forming a robust solution for predictive maintenance in mission-critical industrial applications.
Featuring a 5 mm nominal probe diameter and 90 mm active length, the 330100-90-00 is optimized for measuring shaft vibrations in tight spaces, such as turbine casings or compressor housings. Its stainless steel construction and IP65 protection rating ensure durability in harsh environments, with an operating temperature range of -50°C to +177°C that withstands extreme industrial conditions. The probe’s 1 m cable length (with a 18-pin connector) facilitates flexible installation while maintaining signal integrity, making it suitable for both new installations and retrofitted monitoring systems.
In automation ecosystems, the 330100-90-00 serves as the frontline sensor for machinery health assessment, feeding critical data to monitoring systems for real-time analysis. Its compatibility with Bently Nevada’s comprehensive suite of modules and software tools enables seamless integration into distributed control systems (DCS) and supervisory control networks, positioning it as an essential component for industries reliant on uninterrupted equipment operation.
Technical Specifications: BENTLY 330100-90-00
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 330100-90-00 |
| Manufacturer | BENTLY NEVADA |
| Product Type | Proximity Probe |
| Probe Diameter | 5 mm |
| Active Length | 90 mm |
| Cable Length | 1 m |
| Connector Type | 18-pin Bently Nevada compatible |
| Measurement Range | 0–2 mm (linear) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Operating Temperature | -50°C to +177°C |
| Storage Temperature | -50°C to +200°C |
| Protection Rating | IP65 |
| Material | Stainless steel |
| Weight | 0.3 kg |
| Country of Origin | United States |
Main Features and Advantages: BENTLY 330100-90-00
High-Precision Eddy Current Technology: The 330100-90-00 leverages eddy current principles to measure shaft displacement with micron-level accuracy, critical for detecting early signs of mechanical degradation. This precision allows operators to identify issues like rotor rubs or bearing defects before they escalate into costly failures.
Rugged Industrial Design: Built with a stainless steel housing and IP65-rated construction, the probe resists corrosion, moisture, and mechanical stress, ensuring reliability in harsh environments. Its ability to operate in extreme temperatures (-50°C to +177°C) makes it suitable for applications ranging from arctic oil fields to high-temperature furnace systems.
Seamless System Integration: Specifically designed for Bently Nevada’s 3300 Series, the 330100-90-00 ensures plug-and-play compatibility with Proximitor modules (e.g., 3300/40M) and monitoring racks. This integration simplifies system setup and reduces the risk of compatibility issues, enabling rapid deployment in complex industrial setups.
Long-Life Performance: The probe’s corrosion-resistant materials and robust cable construction extend its service life, even in chemically aggressive or high-vibration environments. This longevity minimizes replacement costs and maintenance frequency, enhancing overall system reliability.
Easy Calibration and Maintenance: The 330100-90-00 supports on-site calibration using Bently Nevada’s standard tools, allowing operators to verify performance without specialized equipment. Its modular design facilitates quick replacement if needed, minimizing downtime during maintenance.
Application Areas: BENTLY 330100-90-00
The BENTLY 330100-90-00 proximity probe is widely applied in industries where machinery reliability is non-negotiable:
- Power Generation: Monitors steam turbines, generators, and auxiliary equipment in thermal, hydro, and nuclear power plants. The probe’s high-temperature tolerance ensures accurate measurements in turbine casings and generator shafts, supporting proactive maintenance to prevent unplanned outages.
- Oil and Gas: Deployed in refineries, pipelines, and offshore platforms to monitor compressors, pumps, and motors. Its corrosion resistance makes it ideal for harsh offshore environments and chemically active processing areas, where equipment health directly impacts operational safety.
- Manufacturing: Installed in CNC machines, presses, and robotic arms to detect vibrations that could affect product quality. The probe helps maintain precision in high-speed manufacturing processes, such as automotive assembly lines or semiconductor fabrication.
- Water Treatment: Used in pump stations and wastewater treatment plants to monitor pump shafts and impellers, ensuring continuous operation and compliance with environmental regulations. Its durability in humid conditions makes it suitable for water-intensive environments.
- Aerospace and Defense: Supports condition monitoring of aircraft engines, ground support equipment, and military machinery, where failure risks must be minimized for mission success and safety.
Related Products: BENTLY 330100-90-00
- BENTLY 3300/40M Proximitor Module (173343-01): A 配套使用 module that processes signals from the 330100-90-00, converting proximity measurements into standardized outputs for monitoring systems.
- BENTLY 135489-03 Extension Cable: Extends the reach of the 330100-90-00 with a 3-meter length, enabling installation in hard-to-reach areas while maintaining signal integrity.
- BENTLY 3300/32 Keyphasor Module (125712-01): Provides phase reference signals for the 330100-90-00, enabling precise vibration analysis and machinery alignment.
- BENTLY 3300/05 Rack Chassis: Houses Proximitor modules and other monitoring components, integrating the 330100-90-00 into a comprehensive health monitoring system.
- BENTLY 330100-90-05: A variant with a 5 m cable length, offering flexibility for installations requiring extended probe placement.
- BENTLY 3500/42M Vibration Monitoring Module: A higher-performance module for complex systems, working with the 330100-90-00 to support multiple vibration channels.
Installation and Maintenance: BENTLY 330100-90-00
Pre-installation Preparations:
Before installing the 330100-90-00, verify the installation location meets temperature and environmental requirements. Clean the mounting surface and ensure proper clearance around the probe tip to avoid mechanical interference. Use the provided mounting bracket to secure the probe to the machinery casing, maintaining a perpendicular alignment to the target shaft. Connect the probe cable to the Bently Nevada Proximitor module (e.g., 3300/40M 173343-01), ensuring the connector is tightly secured to prevent signal loss. Calibrate the probe using Bently Nevada’s System 1 software to establish the zero gap and linear range before commissioning.
Before installing the 330100-90-00, verify the installation location meets temperature and environmental requirements. Clean the mounting surface and ensure proper clearance around the probe tip to avoid mechanical interference. Use the provided mounting bracket to secure the probe to the machinery casing, maintaining a perpendicular alignment to the target shaft. Connect the probe cable to the Bently Nevada Proximitor module (e.g., 3300/40M 173343-01), ensuring the connector is tightly secured to prevent signal loss. Calibrate the probe using Bently Nevada’s System 1 software to establish the zero gap and linear range before commissioning.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks for cable wear, connector corrosion, or physical damage to the probe tip. Use a thermal imager to detect unusual temperature gradients that could indicate probe malfunction.
- Calibration Verification: Annually verify probe sensitivity and linearity using a calibration fixture, adjusting as needed to maintain measurement accuracy. Reference Bently Nevada’s calibration procedures for step-by-step guidance.
- Environmental Monitoring: Regularly assess the operating environment for changes in temperature, humidity, or vibration levels that could affect probe performance. Install additional protection (e.g., heat shields) if conditions exceed specified limits.
- Spare Parts Management: Keep a spare 330100-90-00 on hand, along with compatible connectors and cables, to facilitate rapid replacement in case of failure. Leverage our global supply chain for quick delivery of discontinued or urgent components.
Product Guarantee: BENTLY 330100-90-00
Our company provides a 12-month quality warranty for the BENTLY 330100-90-00 proximity probe, covering hardware defects from non-human causes. During the warranty period, we will replace any probe with abnormal sensitivity, cable failures, or structural damage at no cost. For discontinued models or urgent repair needs, our extensive inventory and global logistics network ensure prompt fulfillment, minimizing downtime and supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we are committed to reliable products and exceptional service. The 330100-90-00 exemplifies our dedication to quality, offering the precision and durability required for critical machinery monitoring. Contact us today to optimize your predictive maintenance strategy with this advanced proximity probe.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for Bently Nevada’s official technical manuals.
