BENTLY 3300/20-12-01-03-00-00 Proximitor Monitor
Product Overview
The BENTLY 3300/20-12-01-03-00-00 is a high-precision Proximitor Monitor designed as a critical component of Bently Nevada’s 3300 Series Machinery Protection System. Engineered to convert proximity probe signals into standardized electrical outputs, this monitor enables real-time measurement of shaft displacement, vibration, and axial position in rotating machinery. As part of the 3300 Series, the 3300/20-12-01-03-00-00 supports seamless integration with other 3300 modules (e.g., vibration monitors, keyphasor modules), forming a comprehensive solution for machinery health monitoring in industries such as oil & gas, power generation, and manufacturing.
Featuring a rugged industrial design, the BENTLY 3300/20-12-01-03-00-00 processes signals from 8 mm proximity probes, providing a measurement range of 0–250 mils (0–6.35 mm) with ±0.5% linearity. Its advanced signal conditioning circuitry includes anti-aliasing filters and galvanic isolation, minimizing electromagnetic interference and ensuring reliable data acquisition in harsh environments. The monitor’s wide operating temperature range (-40°C to +85°C) and IP65-rated enclosure make it suitable for direct installation in demanding industrial settings, while its compatibility with API 670 standards ensures compliance with safety and reliability requirements.
In automation ecosystems, the 3300/20-12-01-03-00-00 serves as the interface between proximity probes and higher-level monitoring systems, converting mechanical movements into 4–20 mA or 0–10 V DC signals for analysis. Its modular design allows easy integration into 3300 Series racks, while built-in LED indicators provide real-time status feedback on signal health and fault conditions. By delivering precise and reliable displacement data, this monitor supports predictive maintenance, reduces unplanned downtime, and extends equipment lifespan in mission-critical applications.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 3300/20-12-01-03-00-00 |
| Manufacturer | Bently Nevada |
| Product Type | Proximitor Monitor |
| Series | 3300 |
| Probe Type | 8 mm proximity probe (compatible with 3300 XL series) |
| Measurement Range | 0–250 mils (0–6.35 mm) |
| Linearity | ±0.5% of full scale |
| Output Signal | 4–20 mA, 0–10 V DC |
| Excitation Voltage | 24 V DC (supplied by monitor) |
| Frequency Response | 0–10 kHz |
| Physical Dimensions | 101.6 mm (H) × 152.4 mm (W) × 127 mm (D) |
| Weight | 1.5 kg |
| Operating Temperature | -40°C to +85°C |
| Mounting | Rack-mounted in 3300 Series enclosure |
| Certifications | CE, UL, API 670 |
Key Features and Advantages
High-Accuracy Displacement Measurement: The 3300/20-12-01-03-00-00 provides precise shaft displacement readings with ±0.5% linearity, enabling early detection of misalignment, bearing wear, or shaft rubs. Its wide measurement range accommodates both small and large machinery movements, supporting comprehensive health analysis.
Robust Signal Conditioning: Advanced filtering and galvanic isolation eliminate noise interference, ensuring clean output signals even in high-electromagnetic environments. This reliability is critical for maintaining accurate measurements in industrial settings with heavy machinery or power equipment.
Modular and Scalable Design: As part of the 3300 Series, the monitor integrates seamlessly with other 3300 modules (e.g., vibration monitors, communication gateways), allowing scalable system configurations for small to large monitoring setups. Its hot-swappable design enables maintenance without system shutdowns.
Wide Environmental Tolerance: Engineered to withstand extreme temperatures (-40°C to +85°C) and harsh conditions, the monitor’s IP65-rated enclosure protects against dust, moisture, and water jets, making it suitable for offshore platforms, refineries, and other challenging environments.
Industry-Standard Compliance: Compliant with API 670 and IEC 61131-2, the 3300/20-12-01-03-00-00 meets rigorous safety and reliability standards, ensuring regulatory compliance in critical applications.
Application Areas
The BENTLY 3300/20-12-01-03-00-00 is essential for machinery health monitoring in industries where equipment reliability is critical:
- Oil & Gas: Monitors shaft displacement in compressors, pumps, and turbines at refineries, pipelines, and offshore rigs to detect misalignment or bearing degradation, preventing costly shutdowns.
- Power Generation: Installed on steam turbines, generators, and auxiliary equipment in thermal, hydro, and nuclear plants to ensure safe operation and grid stability by measuring shaft position and vibration.
- Manufacturing: Used in high-speed rotating machinery (e.g., motors, fans, conveyors) in automotive, chemical, and food processing facilities to maintain production continuity and product quality.
- Aerospace & Defense: Deployed on test stands and propulsion systems to analyze shaft dynamics, ensuring compliance with rigorous performance standards.
Specific applications include:
- Radial Vibration Analysis: Measures shaft vibration amplitude to identify imbalance or misalignment issues before they escalate into catastrophic failures.
- Axial Displacement Monitoring: Tracks thrust bearing wear in turbines and compressors, triggering alarms when clearances exceed safe limits.
- Shaft Position Sensing: Monitors rotor position in critical processes, such as steam turbine lube oil system operation, to prevent metal-to-metal contact.
Related Products
- 3300/22M Keyphasor Module: Works in tandem with the 3300/20-12-01-03-00-00 to provide rotational reference signals for phase-locked vibration analysis.
- 3300/42M Vibration Monitor: Processes displacement data from the 3300/20-12-01-03-00-00 to provide comprehensive vibration analysis and alarm outputs.
- 330700 Proximity Probe System: A 5 mm tip variant for smaller machinery, compatible with the 3300/20-12-01-03-00-00 for the combined displacement and vibration monitoring.
- 330500 Proximity Probe System: A 11 mm tip model for large shafts, integrating with the monitor in multi-probe setups.
- 330903 Extension Cable: Extends the proximity probe system for remote mounting, compatible with the 3300/20-12-01-03-00-00 for flexible installation.
- 3500/42M Proximitor Monitor: An upgraded version in the 3500 Series, offering advanced features while maintaining compatibility with the 3300/20-12-01-03-00-00 in legacy systems.
Installation and Maintenance
Pre-installation Preparations:
Before installing the BENTLY 3300/20-12-01-03-00-00, ensure the 3300 Series rack is properly grounded and ventilated. Verify compatibility with the connected proximity probe (e.g., 3300 XL 8 mm probe) and route shielded cables away from high-voltage lines to minimize interference. Mount the monitor in the rack using the provided hardware, ensuring adequate spacing for heat dissipation. Configure the monitor’s input range and output scaling via the front-panel switches or remote configuration software, following Bently Nevada’s guidelines for optimal performance.
Before installing the BENTLY 3300/20-12-01-03-00-00, ensure the 3300 Series rack is properly grounded and ventilated. Verify compatibility with the connected proximity probe (e.g., 3300 XL 8 mm probe) and route shielded cables away from high-voltage lines to minimize interference. Mount the monitor in the rack using the provided hardware, ensuring adequate spacing for heat dissipation. Configure the monitor’s input range and output scaling via the front-panel switches or remote configuration software, following Bently Nevada’s guidelines for optimal performance.
Maintenance Suggestions:
- Routine Inspections: Quarterly visual checks of LED indicators to verify signal health and fault status. Use a multimeter to measure output signals and compare them against expected values from the proximity probe.
- Calibration: Annually calibrate the 3300/20-12-01-03-00-00 using a precision displacement shaker to maintain measurement accuracy. Document calibration results for compliance and traceability.
- Cleaning: Remove dust and debris from the monitor’s vents monthly to prevent overheating, especially in dusty environments. Use compressed air or a soft brush for cleaning.
- Spare Parts Management: Store spare 3300/20-12-01-03-00-00 monitors in a controlled environment (10–30°C, <50% humidity) to ensure quick replacement during failures. Test spares periodically to maintain functionality.
Product Guarantee
Our company provides a 12-month quality warranty for the BENTLY 3300/20-12-01-03-00-00, covering hardware defects under normal use. In the event of signal instability or functional failures, we offer prompt replacement services to minimize downtime. For legacy or urgent requirements, our global supply chain ensures rapid delivery of the 3300/20-12-01-03-00-00 and related spares. Our technical support team assists with installation, calibration, and troubleshooting, ensuring reliable operation to safeguard your industrial monitoring systems.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
