BENTLY 3300/16-11-01-03-00-00-01 Proximity Probe System
Product Overview: BENTLY 3300/16-11-01-03-00-00-01
The BENTLY 3300/16-11-01-03-00-00-01 proximity probe system is a high-precision industrial sensor solution designed for real-time monitoring of shaft vibration and displacement in rotating machinery. As a core component of Bently Nevada’s 3300 Series Machinery Health Monitoring System, this system combines a proximity probe, extension cable, and proximitor module to deliver accurate measurements for predictive maintenance in critical applications. The 3300/16-11-01-03-00-00-01 leverages eddy current technology to detect minute mechanical movements, enabling early identification of issues like misalignment, bearing wear, or imbalance before they escalate into costly failures.
Engineered for industrial harshness, the system includes a 5 mm nominal diameter probe (11-01), 1 m probe cable (03), and 3 m extension cable (00), all constructed with stainless-steel shielding to resist corrosion and electromagnetic interference. The 配套的 proximitor module (not included, typically 3300/40M) converts the probe’s analog signal into a standardized output for integration with monitoring systems. The -50°C to +177°C operating temperature range and IP65 protection rating ensure reliability in extreme environments, from power plant turbines to offshore compressors.
In automation ecosystems, the 3300/16-11-01-03-00-00-01 serves as the frontline sensor for machinery health assessment, feeding critical data to distributed control systems (DCS) and supervisory control networks. Its compatibility with Bently Nevada’s comprehensive suite of monitoring modules ensures seamless integration, making it an essential component for industries reliant on 24/7 equipment operation.
Technical Specifications: BENTLY 3300/16-11-01-03-00-00-01
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 3300/16-11-01-03-00-00-01 |
| Manufacturer | BENTLY NEVADA |
| Product Type | Proximity Probe System |
| Probe Diameter | 5 mm |
| Probe Cable Length | 1 m |
| Extension Cable Length | 3 m |
| Measurement Range | 0–2 mm (linear) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| Operating Temperature | -50°C to +177°C |
| Protection Rating | IP65 (probe and cables) |
| Connector Type | 18-pin Bently Nevada compatible |
| Weight | 0.8 kg |
| Country of Origin | United States |
Main Features and Advantages: BENTLY 3300/16-11-01-03-00-00-01
High-Precision Eddy Current Technology: The 3300/16-11-01-03-00-00-01 utilizes eddy current principles to measure shaft displacement with micron-level accuracy, critical for detecting early-stage mechanical issues. Its 7.87 V/mm sensitivity ensures precise monitoring of even minor vibrations, enabling proactive maintenance.
Rugged Industrial Design: The stainless-steel braided shielding on the probe and cables resists abrasion, corrosion, and electromagnetic interference (EMI), making the system suitable for high-vibration and electrically noisy environments. The IP65 rating protects against dust and water jets, enhancing durability in harsh industrial settings.
Modular System Integration: Designed for Bently Nevada’s 3300 Series, the system integrates seamlessly with proximitor modules (e.g., 3300/40M) and monitoring racks, ensuring plug-and-play compatibility. This standardization reduces installation complexity and minimizes the risk of compatibility issues.
Wide Environmental Tolerance: With an operating range spanning -50°C to +177°C, the system withstands extreme temperatures in applications like high-temperature furnaces or arctic oil fields. The robust construction ensures consistent performance without signal degradation.
Easy Calibration and Maintenance: The system supports on-site calibration using Bently Nevada’s standard tools, allowing operators to verify measurement accuracy without specialized equipment. The modular design facilitates quick replacement of components, reducing downtime during maintenance.
Application Areas: BENTLY 3300/16-11-01-03-00-00-01
The BENTLY 3300/16-11-01-03-00-00-01 proximity probe system is essential for industries where machinery reliability is non-negotiable:
- Power Generation: Monitors steam turbines, generators, and auxiliary equipment in thermal, hydro, and nuclear power plants, ensuring early detection of rotor imbalances or bearing degradation.
- Oil and Gas: Deployed in refineries, pipelines, and offshore platforms to monitor compressors and pumps. The system’s corrosion resistance makes it suitable for harsh offshore environments.
- Manufacturing: Installed in CNC machines, presses, and robotic arms to maintain production quality by detecting vibrations that could affect product consistency.
- Water Treatment: Used in pump stations and wastewater treatment plants to monitor critical equipment, supporting continuous operation and regulatory compliance.
- Aerospace and Defense: Integrates with aircraft engines and ground support equipment, where precise vibration data is critical for mission readiness and safety.
Related Products: BENTLY 3300/16-11-01-03-00-00-01
- BENTLY 3300/40M Proximitor Module (173343-01): Processes signals from the 3300/16-11-01-03-00-00-01, converting mechanical movements into standardized electrical outputs.
- BENTLY 3300/16-11-01-05-00-00-01: A variant with a 5 m extension cable, offering flexibility for installations requiring greater probe reach.
- BENTLY 3300/20 Proximitor (177230-01): An alternative proximitor module with enhanced diagnostic features, compatible with the 3300/16-11-01-03-00-00-01.
- BENTLY 3300/32 Keyphasor Module (125712-01): Provides phase reference signals for the probe system, enabling precise vibration analysis and machinery alignment.
- BENTLY 106M1081-01 Vibration Proximity Probe: A 5 mm probe variant, interchangeable with the 3300/16-11-01-03-00-00-01 for spare parts management.
- BENTLY 3300/05 Rack Chassis: Houses proximitor modules and other monitoring components, forming a comprehensive system with the 3300/16-11-01-03-00-00-01.
Installation and Maintenance: BENTLY 3300/16-11-01-03-00-00-01
Pre-installation Preparations:
Before installing the 3300/16-11-01-03-00-00-01, inspect the probe and cables for physical damage and ensure the installation surface is clean and free of debris. Use the provided mounting bracket to secure the probe perpendicular to the target shaft, maintaining a minimum clearance for optimal eddy current induction. Connect the probe cable to the extension cable and proximitor module (e.g., 3300/40M 173343-01), ensuring connectors are fully engaged to prevent signal loss. Calibrate the system using Bently Nevada’s System 1 software to establish the zero gap and linear measurement range.
Before installing the 3300/16-11-01-03-00-00-01, inspect the probe and cables for physical damage and ensure the installation surface is clean and free of debris. Use the provided mounting bracket to secure the probe perpendicular to the target shaft, maintaining a minimum clearance for optimal eddy current induction. Connect the probe cable to the extension cable and proximitor module (e.g., 3300/40M 173343-01), ensuring connectors are fully engaged to prevent signal loss. Calibrate the system using Bently Nevada’s System 1 software to establish the zero gap and linear measurement range.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks for cable abrasion, connector corrosion, or probe misalignment. Use a thermal imager to detect unusual temperature gradients that may indicate internal wire issues.
- Calibration Verification: Annually verify probe sensitivity using a calibration fixture, adjusting as needed to maintain measurement accuracy. Reference Bently Nevada’s procedures for step-by-step guidance.
- Environmental Monitoring: Regularly assess the operating environment for changes in temperature, humidity, or mechanical stress. Add additional shielding if conditions exceed specified limits.
- Spare Parts Management: Keep spare probes, cables, and connectors on hand to facilitate rapid replacement. Leverage our global supply chain for quick delivery of discontinued components.
Product Guarantee: BENTLY 3300/16-11-01-03-00-00-01
Our company provides a 12-month quality warranty for the BENTLY 3300/16-11-01-03-00-00-01 proximity probe system, covering hardware defects from non-human causes. During the warranty period, we will replace any component with abnormal sensitivity, cable failures, or connector degradation at no cost. For urgent needs or discontinued models, our extensive inventory and global logistics network ensure prompt fulfillment, minimizing downtime and supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we prioritize reliable products and exceptional service. The 3300/16-11-01-03-00-00-01 exemplifies our commitment to quality, offering the precision and durability required for critical machinery monitoring. Contact us today to enhance your predictive maintenance strategy with this advanced probe system.
Note: All product names, logos, and brands are property of their owners. This document is informational and does not substitute for Bently Nevada’s official technical manuals.
