BENTLY 136719-01 Proximity Probe Cable
Product Overview: BENTLY 136719-01
The BENTLY 136719-01 proximity probe cable is a high-reliability connectivity solution designed for extending the reach of vibration monitoring systems in industrial machinery. As a critical component of Bently Nevada’s 3300 Series Machinery Health Monitoring System, this cable bridges the gap between proximity probes and Proximitor modules, enabling precise measurement of shaft vibration and displacement in rotating equipment. Engineered for durability and signal integrity, the 136719-01 ensures seamless data transmission in harsh environments, making it essential for predictive maintenance strategies in mission-critical applications.
Featuring a 5-meter length and rugged stainless-steel braiding, the 136719-01 withstands mechanical stress, corrosion, and electromagnetic interference (EMI). The cable’s 18-pin Bently Nevada connector ensures a secure, corrosion-resistant link to both probes (e.g., 106M1081-01) and Proximitor modules (e.g., 3300/40M 173343-01), minimizing signal loss and noise. Its -50°C to +177°C operating temperature range and IP65 protection rating make it suitable for extreme conditions, from high-temperature turbine compartments to offshore platforms. The cable’s flexible design allows routing through tight spaces while maintaining measurement accuracy critical for early fault detection.
In automation systems, the 136719-01 plays a pivotal role in expanding vibration monitoring setups, enabling probes to be positioned in hard-to-reach areas. Its compatibility with Bently Nevada’s comprehensive suite of monitoring components ensures seamless integration into distributed control systems (DCS) and supervisory networks, supporting real-time machinery health assessment.
Technical Specifications: BENTLY 136719-01
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 136719-01 |
| Manufacturer | BENTLY NEVADA |
| Product Type | Proximity Probe Cable |
| Cable Length | 5 meters |
| Connector Type | 18-pin Bently Nevada compatible |
| Shielding | Stainless steel braid |
| Operating Temperature | -50°C to +177°C |
| Storage Temperature | -50°C to +200°C |
| Protection Rating | IP65 |
| Cable Jacket Material | Polyvinyl chloride (PVC) |
| Weight | 0.7 kg |
| Country of Origin | United States |
Main Features and Advantages: BENTLY 136719-01
Rugged Industrial Construction: The 136719-01 features a stainless-steel braided shield that resists abrasion, corrosion, and EMI, ensuring signal integrity in high-vibration and electrically noisy environments. This durability reduces maintenance costs and minimizes downtime from cable failure.
Precision Signal Transmission: Engineered for minimal signal loss, the cable maintains the high sensitivity (7.87 V/mm) of Bently Nevada probes, enabling accurate vibration measurements over extended distances. Its low capacitance and impedance characteristics preserve measurement fidelity for early detection of mechanical issues like bearing wear or shaft misalignment.
Wide Environmental Tolerance: With an operating range of -50°C to +177°C, the 136719-01 withstands extreme temperatures in industrial settings, from arctic oil fields to furnace applications. The IP65 rating protects against dust and water jets, enhancing reliability in harsh conditions.
Seamless System Integration: Designed for Bently Nevada’s 3300 Series, the cable ensures plug-and-play compatibility with Proximitor modules, probes, and rack systems. This standardization simplifies installation and reduces compatibility risks in complex monitoring setups.
Flexible Installation: The cable’s lightweight and flexible design facilitates routing through tight spaces, while its corrosion-resistant connectors require minimal maintenance. Regular visual inspections ensure long-term performance without specialized tools.
Application Areas: BENTLY 136719-01
The BENTLY 136719-01 proximity probe cable is essential for industries requiring robust vibration monitoring:
- Power Generation: Connects vibration probes to monitoring systems in steam turbines, generators, and auxiliary equipment, enabling real-time health assessment in power plants. The cable’s high-temperature tolerance suits direct installation near hot turbine casings.
- Oil and Gas: Deployed in offshore platforms and refineries to extend probe reach in compressors, pumps, and motors. Its corrosion resistance makes it suitable for saltwater environments and chemically active processing areas.
- Manufacturing: Used in CNC machines, presses, and robotic arms to monitor vibrations that could affect product quality. The cable’s EMI shielding ensures accuracy in electrically noisy production floors.
- Water Treatment: Links vibration sensors to control systems in pump stations and wastewater treatment plants, supporting continuous operation and regulatory compliance.
- Aerospace and Defense: Integrates with ground support equipment and military machinery, where reliable vibration data is critical for mission readiness.
Related Products: BENTLY 136719-01
- BENTLY 106M1081-01 Vibration Proximity Probe: A 配套使用 probe that connects to the 136719-01, providing precise shaft vibration measurements.
- BENTLY 3300/40M Proximitor Module (173343-01): Processes signals from the probe via the 136719-01, converting mechanical movements into electrical outputs.
- BENTLY 3300/32 Keyphasor Module (125712-01): Works with the 136719-01 to provide phase reference signals for vibration analysis.
- BENTLY 3300/05 Rack Chassis: Houses Proximitor modules connected via the 136719-01, forming a comprehensive monitoring system.
- BENTLY 135489-03 Extension Cable (3-meter): A shorter variant for applications requiring less reach, compatible with the same probe and module setup.
- BENTLY 133488-02 Connector Kit: Replacement connectors for the 136719-01, ensuring secure terminations during installation or repair.
Installation and Maintenance: BENTLY 136719-01
Pre-installation Preparations:
Before installing the 136719-01, inspect the cable for physical damage and ensure connector pins are clean and corrosion-free. Verify the installation route to avoid sharp bends or extreme temperatures. Use cable ties or conduits to secure the cable, maintaining a minimum bending radius of 50 mm to prevent internal wire damage. Connect one end to the proximity probe (e.g., 106M1081-01) and the other to the Proximitor module (e.g., 3300/40M 173343-01), ensuring connector latches are fully engaged.
Before installing the 136719-01, inspect the cable for physical damage and ensure connector pins are clean and corrosion-free. Verify the installation route to avoid sharp bends or extreme temperatures. Use cable ties or conduits to secure the cable, maintaining a minimum bending radius of 50 mm to prevent internal wire damage. Connect one end to the proximity probe (e.g., 106M1081-01) and the other to the Proximitor module (e.g., 3300/40M 173343-01), ensuring connector latches are fully engaged.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks for abrasion, fraying, or connector degradation. Use a thermal imager to detect unusual temperature spots indicating internal wire issues.
- Environmental Monitoring: Regularly assess the cable’s operating environment for changes in temperature, humidity, or mechanical stress. Add shielding or reroute the cable if conditions exceed specifications.
- Connector Care: Annually clean connector contacts with isopropyl alcohol to remove oxidation, ensuring optimal signal transmission. Tighten loose connections to prevent intermittent failures.
- Spare Parts Management: Keep a spare 136719-01 on hand, along with connector kits, for rapid replacement. Leverage our global supply chain for quick delivery of discontinued components.
Product Guarantee: BENTLY 136719-01
Our company provides a 12-month quality warranty for the BENTLY 136719-01 proximity probe cable, covering hardware defects from non-human causes. During the warranty period, we will replace any cable with shielding damage, connector failures, or signal degradation at no cost. For urgent needs or discontinued models, our extensive inventory and global logistics network ensure prompt fulfillment, minimizing downtime and supporting continuous industrial operation.
With 17 years of expertise in industrial control distribution, we prioritize reliable products and exceptional service. The 136719-01 exemplifies our commitment to quality, offering the durability and signal integrity required for critical machinery monitoring. Contact us today to enhance your vibration monitoring setup with this robust cable.
