Product Overview
The ABB LD800HSE 3BDH000320R02 is a high-performance communication module designed as a core component of ABB’s AC500 PLC system, a leading platform in industrial automation. This module serves as a critical interface for enabling high-speed data exchange between PLC controllers, I/O modules, and other industrial devices, ensuring seamless communication in complex automation networks. As a key part of ABB’s trusted product lineup, the ABB LD800HSE 3BDH000320R02 is engineered to meet the demanding requirements of modern industrial environments, where reliability and real-time performance are paramount.
Specifically optimized for High-Speed Ethernet (HSE) communication, the ABB LD800HSE 3BDH000320R02 supports fast and secure data transmission, making it ideal for applications requiring rapid response times, such as manufacturing lines, process control systems, and smart factory setups. It integrates seamlessly with ABB’s AC500 CPU modules, I/O modules, and human-machine interfaces (HMIs), forming a cohesive automation ecosystem that enhances operational efficiency and reduces system complexity.
By leveraging advanced communication protocols and robust hardware design, the ABB LD800HSE 3BDH000320R02 ensures stable connectivity even in harsh industrial conditions, including environments with electromagnetic interference (EMI) or temperature fluctuations. Its modular architecture allows for easy expansion and 升级，enabling users to adapt their automation systems to evolving production needs without extensive overhauls. For industries relying on precise and uninterrupted data flow, the ABB LD800HSE 3BDH000320R02 delivers consistent performance and long-term value.
Technical Specifications
| Parameter Name | Parameter Values |
|---|---|
| Manufacturer | ABB |
| Product Type | HSE Communication Module (AC500 Series) |
| Physical Dimensions | 100 mm (width) × 150 mm (height) × 50 mm (depth) |
| Weight | Approx. 250 grams |
| Interface Type | 2 x 10/100 Mbps Ethernet ports (RJ45) |
| Communication Protocol | Supports HSE (High-Speed Ethernet), compatible with PROFINET and Modbus TCP |
| Working Environment | Operating temperature: -25°C to +70°C; Storage temperature: -40°C to +85°C; Humidity: 5% to 95% RH (non-condensing) |
| Installation | DIN rail mounting (EN 50022 standard); Tool-free installation for quick setup |
LD800HSE 3BDH000320R02
Related Products
- ABB PM590-ETH: AC500 CPU module with integrated Ethernet, designed to work with the ABB LD800HSE 3BDH000320R02 for enhanced processing and communication capabilities.
- ABB DI810: Digital input module that pairs with the LD800HSE 3BDH000320R02 to collect field data and transmit it via HSE for real-time monitoring.
- ABB DO810: Digital output module, complementary to the LD800HSE 3BDH000320R02, enabling control signals to be sent from the PLC to actuators.
- ABB LD801F: Profibus DP communication module, an alternative to the LD800HSE 3BDH000320R02 for systems requiring Profibus-based communication.
- ABB PS510: Power supply module providing stable 24V DC power to the LD800HSE 3BDH000320R02 and other AC500 components.
- ABB AI835: Analog input module that integrates with the LD800HSE 3BDH000320R02 to transmit continuous process data (e.g., temperature, pressure) over Ethernet.
- ABB AC500-eCo PM564-T-ETH: Compact CPU module for small-scale applications, compatible with the LD800HSE 3BDH000320R02 for cost-effective communication setups.
Main Features and Advantages
High-Speed Data Transmission: The ABB LD800HSE 3BDH000320R02 supports 10/100 Mbps Ethernet communication, ensuring rapid data exchange between connected devices. This high bandwidth is critical for applications requiring real-time control, such as synchronized manufacturing processes or dynamic process adjustments, where delays can lead to production inefficiencies or quality issues.
Seamless System Integration: As part of ABB’s AC500 ecosystem, the LD800HSE 3BDH000320R02 is fully compatible with a wide range of ABB PLC components, including CPUs, I/O modules, and HMIs. This compatibility eliminates integration challenges, reduces setup time, and ensures consistent performance across the entire automation system.
Rugged Industrial Design: Built to withstand harsh industrial conditions, the module features a durable housing that resists vibration, shock, and EMI. Its wide operating temperature range (-25°C to +70°C) allows reliable operation in environments such as factories, refineries, and outdoor installations, minimizing downtime due to environmental stress.
Flexible Protocol Support: The ABB LD800HSE 3BDH000320R02 supports multiple industry-standard protocols, including HSE, PROFINET, and Modbus TCP. This flexibility enables it to integrate with legacy systems and new equipment alike, making it a versatile choice for both system upgrades and new installations.
Easy Installation and Maintenance: Designed for DIN rail mounting with tool-free connections, the module simplifies installation and reduces setup errors. Its modular design also allows for quick replacement during maintenance, minimizing system downtime and lowering operational costs.
Installation and Maintenance
Pre-installation preparations: Before installing the ABB LD800HSE 3BDH000320R02, ensure the mounting rail (EN 50022 standard) is securely fastened and free from debris. Verify that the power supply (24V DC) is stable and meets the module’s voltage requirements. Check compatibility with the target AC500 CPU module and other connected devices to avoid protocol mismatches. Power off the system entirely before connecting the module to prevent electrical damage.
Maintenance suggestions: Conduct regular visual inspections of the ABB LD800HSE 3BDH000320R02 to check for loose connections, dust accumulation, or physical damage. Clean the Ethernet ports periodically using compressed air to remove debris that may disrupt communication. Monitor communication logs for errors or dropouts, which could indicate issues with cabling or network congestion. Ensure firmware is updated to the latest version using ABB’s programming software to access new features and security enhancements. If faults occur, isolate the module by disconnecting power and checking connections before replacing, if necessary.
LD800HSE 3BDH000320R02
Application Fields
The ABB LD800HSE 3BDH000320R02 is widely applied across industries that depend on reliable and high-speed industrial communication. In automotive manufacturing, it facilitates real-time data exchange between robotic arms, conveyor systems, and central PLCs, ensuring synchronized production lines and reducing cycle times. Its ability to handle large data volumes makes it suitable for monitoring and controlling assembly processes, where precision and timing are critical.
In chemical and process industries, the module enables secure communication between sensors, valves, and control systems in hazardous environments. Its rugged design and EMI resistance ensure stable operation even near heavy machinery or in areas with high electrical noise, supporting safe and efficient process control, such as batch mixing or pressure regulation.
Water and wastewater treatment plants utilize the ABB LD800HSE 3BDH000320R02 to connect SCADA systems with pumps, filters, and monitoring devices. The module’s reliable data transmission ensures accurate real-time monitoring of water quality, flow rates, and treatment processes, enabling timely adjustments to maintain regulatory compliance.
In food and beverage production, where hygiene and efficiency are priorities, the module integrates with cleaning-in-place (CIP) systems, filling machines, and packaging lines. Its easy maintenance and resistance to moisture help minimize downtime in cleanroom environments, ensuring uninterrupted production of perishable goods.
Across all these fields, the ABB LD800HSE 3BDH000320R02 solves the challenge of connecting diverse automation components into a unified network, enhancing operational visibility, reducing manual intervention, and improving overall system reliability.
LD800HSE 3BDH000320R02
Product Guarantee
Our company provides a one-year quality warranty for the ABB LD800HSE 3BDH000320R02, covering hardware malfunctions that are not caused by improper installation, misuse, or external damage. During the warranty period, if the module exhibits performance issues or functional failures under normal operating conditions, we will provide a replacement or repair service free of charge.
As a leading import and export trade distribution company with 17 years of experience in the industrial control industry, we maintain a large stock of ABB industrial control spare parts, including both popular models and hard-to-find discontinued items. Our robust global supply chain ensures we can quickly fulfill urgent orders, minimizing downtime for your operations.
In addition to warranty coverage, we offer comprehensive technical support, including assistance with installation, troubleshooting, and firmware updates. Our team of experts is available to address any questions or concerns, ensuring you get the most out of your ABB LD800HSE 3BDH000320R02 and related automation systems.
For inquiries, contact us via WhatsApp at +86 18859254943 or email sales@ygplc.com.
