ABB SYN5302A-Z,V217 3BHB006716R0217 Synchronization Module
Product Overview：ABB SYN5302A-Z,V217 3BHB006716R0217
The ABB SYN5302A-Z,V217 3BHB006716R0217 synchronization module is a high-precision industrial component designed to ensure seamless coordination between multiple devices in automation systems, particularly in power generation, manufacturing, and process control environments. As part of ABB’s SYN500 series, this module serves as a critical link for real-time synchronization, enabling precise timing and data alignment across distributed control systems (DCS) and programmable logic controllers (PLCs).
Engineered to meet the demands of mission-critical applications, the SYN5302A-Z,V217 3BHB006716R0217 supports multiple synchronization protocols, including IEEE 1588 Precision Time Protocol (PTP) and NTP, ensuring accurate time coordination for devices such as turbines, generators, and networked sensors. Its robust design features the AC 800M control platform compatibility, allowing integration with ABB’s industrial automation ecosystem for enhanced system reliability. The module’s compact form factor (220mm x 150mm x 80mm) and DIN rail mounting capability make it suitable for space-constrained control cabinets, while its wide operating temperature range (-40°C to +70°C) ensures performance in harsh industrial environments.
In automation systems, the SYN5302A-Z,V217 3BHB006716R0217 plays a pivotal role in maintaining operational coherence by synchronizing data acquisition, control signals, and communication networks. This is particularly critical in power plants, where precise timing is essential for generator synchronization with the grid, or in manufacturing lines requiring coordinated motion control. By reducing timing errors and improving system-wide consistency, the module enhances process efficiency, minimizes downtime, and supports predictive maintenance strategies.
Technical Specifications：ABB SYN5302A-Z,V217 3BHB006716R0217
| Parameter Name | Parameter Value |
|---|---|
| Product Model | SYN5302A-Z,V217 3BHB006716R0217 |
| Manufacturer | ABB |
| Product Type | Synchronization Module |
| Input Voltage | 24V DC ±10% |
| Communication Protocols | IEEE 1588 PTP, NTP, Modbus TCP/IP |
| Interface Types | 2 x Ethernet (RJ45), 1 x RS485 |
| Physical Dimensions | 220mm (W) x 150mm (H) x 80mm (D) |
| Weight | 1.8 kg |
| Operating Temperature | -40°C to +70°C |
| Humidity Resistance | 5–95% non-condensing |
| Mounting Type | DIN rail |
| Country of Origin | Sweden |
SYCHROTACT 5 3BHB006716R0277, SYN5302a-Z,V277
Main Features and Advantages：ABB SYN5302A-Z,V217 3BHB006716R0217
High-Precision Time Synchronization: The SYN5302A-Z,V217 3BHB006716R0217 delivers sub-microsecond synchronization accuracy via IEEE 1588 PTP, making it ideal for applications where precise timing is non-negotiable, such as power grid synchronization or high-speed manufacturing lines. This precision reduces errors in data logging, event sequencing, and control actions, enhancing overall system reliability.
Multi-Protocol Flexibility: Supporting both PTP and NTP, the module adapts to diverse network architectures, allowing seamless integration with legacy and modern systems alike. Its Modbus TCP/IP compatibility enables easy configuration and monitoring through ABB’s Control Builder M software, streamlining setup and reducing commissioning time.
Robust Industrial Design: Built to withstand harsh conditions, the module features a rugged enclosure with an IP20 protection rating, shielding it from dust and light moisture. Its wide temperature range and resistance to electromagnetic interference (EMI) ensure stable performance in industrial environments, including power plants, refineries, and heavy machinery installations.
Scalable System Integration: As part of ABB’s AC 800M platform, the SYN5302A-Z,V217 3BHB006716R0217 integrates seamlessly with other ABB components, such as PM866 processor modules and CI854 communication interfaces. This scalability allows users to build modular, future-proof automation systems that can adapt to evolving operational needs.
Real-Time Diagnostics: The module includes built-in LED indicators for power, synchronization status, and communication activity, enabling quick visual troubleshooting. Its self-diagnostic functions continuously monitor performance, alerting operators to issues such as protocol mismatches or timing deviations, and reducing mean time to repair (MTTR).
SYCHROTACT 5 3BHB006716R0277, SYN5302a-Z,V277
Application Areas：ABB SYN5302A-Z,V217 3BHB006716R0217
The ABB SYN5302A-Z,V217 3BHB006716R0217 synchronization module is deployed across industries that rely on precise timing and coordinated operations:
- Power Generation: In thermal, hydro, or wind farms, the module synchronizes generators with the utility grid, ensuring stable power output and compliance with grid codes. It also coordinates protective relays and monitoring systems for real-time fault detection.
- Manufacturing and Automation: Used in smart factories to synchronize robotic arms, conveyor belts, and quality control systems, ensuring seamless coordination in high-speed production lines. For example, in automotive assembly plants, it ensures precise timing for robotic welding and component placement.
- Process Industries: In oil refineries and chemical plants, the module synchronizes distributed control systems (DCS) with field devices, such as flow meters and valves, enabling accurate process control and safety system integration.
- Transportation Infrastructure: Deployed in railway signaling systems and airport baggage handling systems to ensure reliable, timed operations, reducing delays and enhancing safety.
- Renewable Energy: Supports synchronization of solar inverters and energy storage systems with the grid, optimizing power flow and reducing fluctuations in renewable energy networks.
SYCHROTACT 5 3BHB006716R0277, SYN5302a-Z,V277
Related Products：ABB SYN5302A-Z,V217 3BHB006716R0217
- SYN5301A-Z,V216: A predecessor model with basic synchronization capabilities, suitable for simpler applications requiring NTP support.
- SYN5303A-Z,V218: An upgraded version with additional Ethernet ports and support for advanced protocols like Profinet, ideal for complex industrial networks.
- PM866-ETH: ABB’s AC 800M processor module that works in tandem with the SYN5302A-Z,V217 3BHB006716R0217 to execute control logic and manage synchronized data.
- CI854 ABB: A Modbus TCP/IP communication interface that complements the module by expanding connectivity options for third-party devices.
- TB821: A terminal block module for wiring synchronization signals, ensuring secure connections in control cabinets.
- PS501A: A redundant power supply module that ensures stable power delivery to the SYN5302A-Z,V217 3BHB006716R0217, minimizing downtime due to power fluctuations.
- IM301: A DIN rail mounting bracket designed for ABB modules, providing mechanical support and easy installation.
Installation and Maintenance：ABB SYN5302A-Z,V217 3BHB006716R0217
Pre-installation Preparations:
Before installing the SYN5302A-Z,V217 3BHB006716R0217, verify that the control cabinet meets environmental requirements (temperature, humidity) and has adequate ventilation. Ensure the DIN rail is securely fastened and grounded to prevent EMI. Connect the module’s power supply (24V DC) using shielded cables to minimize interference, and configure the IP address via ABB’s Control Builder M software to match the network setup. Test communication with adjacent devices, such as the PM866 processor, to ensure seamless integration.
Before installing the SYN5302A-Z,V217 3BHB006716R0217, verify that the control cabinet meets environmental requirements (temperature, humidity) and has adequate ventilation. Ensure the DIN rail is securely fastened and grounded to prevent EMI. Connect the module’s power supply (24V DC) using shielded cables to minimize interference, and configure the IP address via ABB’s Control Builder M software to match the network setup. Test communication with adjacent devices, such as the PM866 processor, to ensure seamless integration.
Maintenance Recommendations:
Regular maintenance ensures optimal performance of the SYN5302A-Z,V217 3BHB006716R0217. Conduct monthly visual inspections to check for loose connections, damaged cables, or overheating. Clean the module’s surface with a dry cloth to remove dust, which can affect heat dissipation. Quarterly, verify synchronization accuracy using ABB’s diagnostic tools, and update the firmware as needed to address security patches or add new features. In high-vibration environments, such as manufacturing floors, inspect mounting brackets for tightness to prevent mechanical damage. For troubleshooting, use the module’s built-in diagnostics to identify communication errors or timing discrepancies, and replace faulty components promptly with ABB-certified spares.
Regular maintenance ensures optimal performance of the SYN5302A-Z,V217 3BHB006716R0217. Conduct monthly visual inspections to check for loose connections, damaged cables, or overheating. Clean the module’s surface with a dry cloth to remove dust, which can affect heat dissipation. Quarterly, verify synchronization accuracy using ABB’s diagnostic tools, and update the firmware as needed to address security patches or add new features. In high-vibration environments, such as manufacturing floors, inspect mounting brackets for tightness to prevent mechanical damage. For troubleshooting, use the module’s built-in diagnostics to identify communication errors or timing discrepancies, and replace faulty components promptly with ABB-certified spares.
SYCHROTACT 5 3BHB006716R0277, SYN5302a-Z,V277
Product Warranty：ABB SYN5302A-Z,V217 3BHB006716R0217
Our company offers a 12-month quality warranty for the ABB SYN5302A-Z,V217 3BHB006716R0217 synchronization module, covering all non-human-induced hardware defects. If the module experiences performance issues or functional failures during the warranty period, we will provide a replacement at no additional cost. For discontinued models or urgent repair needs, our global supply chain network enables rapid fulfillment of spare parts, minimizing downtime and ensuring continuous operation of your industrial systems.
With 17 years of expertise in industrial control distribution, we pride ourselves on delivering reliable products and exceptional customer support. The SYN5302A-Z,V217 3BHB006716R0217 exemplifies ABB’s commitment to precision and durability, and our team is available to assist with technical inquiries, installation guidance, and maintenance planning. Contact us today to leverage this advanced synchronization solution in your automation infrastructure.
Note: All product names, logos, and brands are the property of their respective owners. This document is for informational purposes only and does not substitute official technical documentation. Always refer to ABB’s manuals for detailed specifications and safety instructions.
