Product Overview
The ABB CI871AK01 3BSE092693R1 Communication Interface Module is a high-performance industrial automation component designed for seamless integration of ABB’s Advant OCS and Symphony Plus control systems with various field devices and networks. As part of ABB’s 800xA Extended Automation System, this module serves as a critical link for real-time data exchange, enabling efficient monitoring and control of complex industrial processes.
Engineered for reliability and flexibility, the CI871AK01 3BSE092693R1 supports multiple communication protocols, including Modbus RTU/TCP, Profibus DP, and Foundation Fieldbus, making it suitable for diverse applications in power generation, oil & gas, and manufacturing. The module features 24V DC power supply, hot-swappable design, and redundant communication ports to ensure continuous operation in mission-critical environments. Its compact form factor (130mm x 210mm x 70mm) and lightweight construction (1.2 kg) facilitate easy installation in standard control cabinets.
In industrial automation systems, the CI871AK01 3BSE092693R1 plays a pivotal role in bridging the gap between field devices and centralized control systems. It enables real-time data acquisition from sensors, actuators, and other intelligent devices, while also transmitting control commands to regulate industrial processes. The module’s advanced diagnostic capabilities and support for remote configuration via ABB’s System 800xA software enhance operational efficiency and reduce maintenance downtime.Whatsapp:+86 18859254943.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | CI871AK01 3BSE092693R1 |
| Manufacturer | ABB |
| Product Type | Communication Interface Module |
| Power Supply | 24V DC ±10% |
| Power Consumption | 15W (max) |
| Communication Protocols | Modbus RTU/TCP, Profibus DP, Foundation Fieldbus |
| Physical Dimensions | 130mm x 210mm x 70mm |
| Weight | 1.2 kg |
| Operating Temperature | -20°C to +60°C |
| Humidity | 5–95% non-condensing |
| Protection Rating | IP20 |
| Certifications | CE, UL, CSA |
| Redundancy Support | Dual communication ports |
| Hot-Swap Capability | Yes |
CI871AK01 3BSE092693R1
Key Features and Advantages
Multi-Protocol Support: The CI871AK01 3BSE092693R1 supports simultaneous operation of multiple communication protocols, allowing seamless integration with diverse field devices and legacy systems. This flexibility reduces the need for additional interface modules, simplifying system architecture and lowering costs.
Redundant Communication: Equipped with dual communication ports, the module ensures continuous data transmission even in the event of a port failure. This redundancy is critical for applications where uninterrupted communication is essential, such as power generation and oil refining.
Hot-Swappable Design: The module’s hot-swappable capability allows for replacement during system operation without shutting down the entire control system. This feature minimizes downtime during maintenance or upgrades, ensuring continuous production in industrial environments.
Advanced Diagnostics: Built-in diagnostic tools provide real-time monitoring of communication status, signal strength, and device health. The module’s LED indicators and fault codes simplify troubleshooting, enabling quick resolution of issues and reducing maintenance time.
Remote Configuration: The CI871AK01 3BSE092693R1 can be configured remotely using ABB’s System 800xA software, eliminating the need for on-site adjustments. This capability streamlines system setup and reduces operational costs, particularly for distributed industrial facilities.
Application Areas
The ABB CI871AK01 3BSE092693R1 Communication Interface Module is widely used in industries requiring robust and flexible communication solutions:Whatsapp:+86 18859254943.
- Power Generation: Integrates with ABB’s Symphony Plus control system to manage communication between turbines, generators, and auxiliary equipment. The module’s support for Modbus and Profibus protocols enables seamless integration with third-party devices, enhancing overall system efficiency.
- Oil & Gas: Deployed in offshore platforms and refineries to connect sensors, valves, and pumps to centralized control systems. The module’s redundancy features ensure reliable communication in harsh environments, minimizing the risk of production disruptions.
- Manufacturing: Used in automotive, food processing, and pharmaceutical industries to enable communication between PLCs, robots, and other automation equipment. The module’s multi-protocol support simplifies integration of diverse devices, improving production line flexibility.
- Water Treatment: Connects monitoring sensors and actuators in water treatment plants to ABB’s control systems, ensuring real-time data exchange for efficient process management. The module’s ability to handle multiple protocols supports integration with legacy and modern equipment alike.
- Mining: Facilitates communication between underground sensors, conveyors, and surface control centers in mining operations. The module’s rugged design and wide temperature range make it suitable for harsh mining environments.
CI871AK01 3BSE092693R1
Related Products
- CI850A: A predecessor to the CI871AK01 3BSE092693R1, supporting fewer protocols but compatible with older ABB control systems.
- CI890A: An upgraded version with enhanced communication capabilities, including support for additional protocols such as HART and Ethernet/IP.
- CI840A: A compact communication module designed for space-constrained applications, offering basic protocol support.E-mail :sales@ygplc.com.
- CI860A: A high-speed communication module optimized for applications requiring rapid data transfer rates.
- 800xA Controller AC800M: A sets controller that works seamlessly with the CI871AK01 3BSE092693R1 to form a complete control system solution.
- Fieldbus Coupler YLINK: A device that interfaces with the CI871AK01 3BSE092693R1 to connect field devices using Foundation Fieldbus protocol.
- Profibus DP/PA Link Module: A module that extends the Profibus communication capabilities of the CI871AK01 3BSE092693R1, enabling connection to PA devices.
Installation and Maintenance
Installation Preparation:
Before installing the CI871AK01 3BSE092693R1, ensure the control system is powered off and the mounting area is clean and free of debris. Verify the 24V DC power supply is within specifications and properly grounded. Align the module with the DIN rail and secure it using the provided locking mechanism. Connect communication cables to the appropriate ports, following ABB’s recommended wiring practices. Finally, configure the module using ABB’s System 800xA software, ensuring correct protocol settings and communication parameters.
Before installing the CI871AK01 3BSE092693R1, ensure the control system is powered off and the mounting area is clean and free of debris. Verify the 24V DC power supply is within specifications and properly grounded. Align the module with the DIN rail and secure it using the provided locking mechanism. Connect communication cables to the appropriate ports, following ABB’s recommended wiring practices. Finally, configure the module using ABB’s System 800xA software, ensuring correct protocol settings and communication parameters.
Maintenance Recommendations:
- Regular Inspections: Conduct visual inspections quarterly to check for loose connections, damaged cables, or signs of overheating. Clean the module’s surface to prevent dust accumulation, which can affect performance.
- Firmware Updates: Periodically update the module’s firmware using ABB’s official software to ensure compatibility with new devices and protocols, and to address any security vulnerabilities.
- Communication Testing: Test communication links monthly using diagnostic tools to verify signal strength and data integrity. Replace any faulty cables or connectors promptly.
- Redundancy Verification: Semi-annually test the module’s redundant communication ports by temporarily disconnecting one port and ensuring continuous operation.
CI871AK01 3BSE092693R1
Product Warranty
We provide a 12-month quality warranty for the ABB CI871AK01 3BSE092693R1 Communication Interface Module, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning module free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.
With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to optimize your industrial communication infrastructure with the CI871AK01 3BSE092693R1 Communication Interface Module.
Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and installation guidelines.
