Product Overview
The ABB 500TRM02 1MRB150011R0001 terminal block module is a high-performance interface solution designed for industrial automation systems, serving as a critical link between field devices and control systems. As part of ABB’s S700 I/O series, this module is engineered to provide reliable signal conditioning and secure connectivity for analog and digital signals, ensuring seamless integration with PLCs, DCS systems, and HMIs.
With a 16-channel configuration and 24V DC signal handling capability, the 500TRM02 1MRB150011R0001 supports a wide range of industrial applications, including process control, machine automation, and monitoring systems. Its DIN rail mounting design (35mm) and compact dimensions (100mm x 50mm x 30mm) facilitate easy installation in space-constrained control cabinets, while the IP20 protection rating safeguards against dust and solid particle ingress. The module’s screw-type termination ensures robust connections for field wiring, minimizing the risk of signal loss or interference.Whatsapp:+86 18859254943.
In automation systems, the 500TRM02 1MRB150011R0001 acts as a central hub for signal distribution, enabling precise control and monitoring of sensors, actuators, and other field devices. Its isolated channels provide galvanic separation between input/output signals, enhancing system reliability and protecting against voltage spikes. By supporting standard industrial protocols such as PROFIBUS and Modbus, the module seamlessly integrates with ABB’s AC500 PLCs and other third-party control systems, making it ideal for complex automation setups.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 500TRM02 1MRB150011R0001 |
| Manufacturer | ABB |
| Product Type | Terminal Block Module |
| Channel Count | 16 |
| Signal Type | Analog/Digital |
| Rated Voltage | 24V DC |
| Rated Current | 5A per channel |
| Termination Type | Screw-type |
| Physical Dimensions | 100mm x 50mm x 30mm |
| Weight | 0.3 kg |
| Operating Temperature | -20°C to +60°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | 35mm DIN rail |
| Protection Rating | IP20 |
500TRM02 1MRB150011R0001
Key Features and Advantages
High-Density Signal Handling: The 500TRM02 1MRB150011R0001 supports 16 channels in a compact form factor, allowing for efficient use of control cabinet space. This density is particularly beneficial in applications with high I/O requirements, such as large-scale manufacturing lines or process plants.Whatsapp:+86 18859254943.
Galvanic Isolation: Each channel features isolated signal paths, protecting the control system from ground loops and voltage transients. This isolation enhances system stability and reduces the risk of equipment damage due to electrical interference.
Reliable Termination: The module’s screw-type terminals provide secure connections for field wiring, ensuring long-term reliability even in high-vibration environments. The terminals are designed for easy access and maintenance, minimizing downtime during system upgrades.
Wide Compatibility: The 500TRM02 1MRB150011R0001 is compatible with ABB’s S700 I/O series and AC500 PLCs, as well as third-party systems supporting PROFIBUS or Modbus protocols. This flexibility allows for seamless integration into existing automation infrastructure.
Enhanced Safety: The module’s IP20 protection rating and overload protection mechanisms (fuse-compatible design) ensure safe operation in harsh industrial environments. These features comply with international safety standards, reducing the likelihood of equipment failure or personnel injury.
Application Areas
The ABB 500TRM02 1MRB150011R0001 terminal block module is ideally suited for diverse industrial sectors requiring reliable signal conditioning and distribution:Whatsapp:+86 18859254943.
- Manufacturing: Integrates with PLCs to manage sensor and actuator signals in automotive assembly lines, packaging machines, and robotics systems, ensuring precise control and synchronization.
- Energy Production: Supports monitoring and control of turbines, generators, and auxiliary equipment in power plants, enabling real-time data acquisition and optimization of energy output.
- Oil & Gas: Manages signals from pressure, temperature, and flow sensors in refineries and offshore platforms, ensuring compliance with safety standards and operational efficiency.
- Water Treatment: Distributes signals to pumps, valves, and analytical instruments in wastewater treatment plants, facilitating automated process control and environmental monitoring.
- Transportation: Interfaces with railway signaling systems and airport baggage handling equipment, providing reliable connectivity for mission-critical operations.
500TRM02 1MRB150011R0001
Related Products
- 500TRM01: A 8-channel variant of the 500TRM02 1MRB150011R0001, suitable for applications with lower I/O requirements.
- 500TRM03: A 32-channel high-density module for large-scale automation systems, offering increased signal handling capacity.
- ABB AC500 PLC: A complementary PLC system that integrates seamlessly with the 500TRM02 1MRB150011R0001 to enable advanced automation and control.
- ABB CP600 HMI: A human-machine interface that pairs with the module to provide real-time system monitoring and user interaction.
- 500PSM03 Power Supply Module: A power supply module that ensures stable voltage delivery to the 500TRM02 1MRB150011R0001 and connected devices.
- ABB S700 I/O Modules: A range of input/output modules that work alongside the terminal block module to expand system functionality.
- 500TRM04: A variant with built-in surge protection for applications in high-electromagnetic interference environments.
- ABB 3BSE032605R1 Redundancy Module: Enhances system reliability by providing redundant signal paths for mission-critical applications.
Installation and Maintenance
Installation Preparation:
Before installing the 500TRM02 1MRB150011R0001, verify the 24V DC power supply and ensure the DIN rail is clean and properly grounded. Align the module with the rail and secure it using the provided clips. Connect field wiring to the screw-type terminals, following ABB’s torque specifications (2.5 N·m for 2.5mm² cables). Finally, link the module to the control system via the appropriate communication interface (e.g., PROFIBUS or Modbus).Whatsapp:+86 18859254943.
Before installing the 500TRM02 1MRB150011R0001, verify the 24V DC power supply and ensure the DIN rail is clean and properly grounded. Align the module with the rail and secure it using the provided clips. Connect field wiring to the screw-type terminals, following ABB’s torque specifications (2.5 N·m for 2.5mm² cables). Finally, link the module to the control system via the appropriate communication interface (e.g., PROFIBUS or Modbus).Whatsapp:+86 18859254943.
Maintenance Recommendations:
- Routine Inspections: Regularly check for loose connections, signs of corrosion, or dust accumulation. Clean the module’s surface quarterly to maintain optimal performance.
- Signal Integrity Checks: Use a multimeter to verify signal levels at the terminals during annual maintenance. Replace any worn or damaged terminals immediately.
- Firmware Updates: While the 500TRM02 1MRB150011R0001 does not require firmware updates, consult ABB’s technical documentation for hardware revisions or compatibility notices.
- Spare Parts Management: Maintain a stock of 500TRM02 1MRB150011R0001 modules and compatible fuses to minimize downtime in case of component failure.
500TRM02 1MRB150011R0001
Product Warranty
We provide a 12-month quality warranty for the ABB 500TRM02 1MRB150011R0001 terminal block module, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning module free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.
With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to optimize your automation system with the 500TRM02 1MRB150011R0001 terminal block module.
Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and installation guidelines.E-mail :sales@ygplc.com.
