TRICONEX 3806E 9720051-00
High-Reliability Analog Output Module for Safety-Critical Industrial Automation
High-Reliability Analog Output Module for Safety-Critical Industrial Automation
Product Overview
The TRICONEX 3806E 9720051-00 is a high-performance analog output module engineered for industrial automation systems requiring precision, safety, and uninterrupted operation. As a core component of the TRICONEX Tricon safety instrumented system (SIS), this module delivers reliable signal conditioning and control for critical processes in industries such as oil & gas, chemical processing, and power generation. The TRICONEX 3806E 9720051-00 is designed to convert digital signals from the Tricon controller into analog outputs (4–20 mA or 20–320 mA), enabling precise actuation of valves, motors, and other field devices in safety-critical applications certified to Safety Integrity Level 3 (SIL 3).
With 8 isolated output channels and a 12-bit resolution, the TRICONEX 3806E 9720051-00 ensures accurate signal transmission even in harsh industrial environments. Its triple modular redundancy (TMR) architecture—featuring three independent processing channels and a voting mechanism—eliminates single points of failure, ensuring continuous operation in the presence of component faults. The module’s built-in diagnostics monitor signal integrity, wiring continuity, and module health in real time, providing actionable alerts to prevent unplanned downtime. By integrating seamlessly with TRICONEX termination boards and communication modules, the TRICONEX 3806E 9720051-00 forms a robust foundation for emergency shutdown systems (ESD), burner management systems (BMS), and high-integrity pressure protection systems (HIPPS).
Technical Specifications
| Parameter | Value |
|---|---|
| Product Model | TRICONEX 3806E 9720051-00 |
| Manufacturer | TRICONEX |
| Product Type | Analog Output Module for Tricon Safety System |
| Output Channels | 8 isolated channels |
| Signal Range | 4–20 mA (±6% over-range), 20–320 mA |
| Resolution | 12 bits |
| Accuracy | ±0.25% of full-scale reading (FSR) within 0°C–60°C |
| Diagnostics | Built-in fault detection (open circuit, over-range, wiring errors) |
| Compatibility | Tricon CX controller, 9771-210 termination board, FI-PFH-TR-AO-380X adapter |
| Power Supply | 24 VDC ±10% |
| Operating Temperature | -40°C to 70°C |
| Humidity | 5–95% non-condensing |
| Physical Dimensions | 163 mm (L) × 38 mm (W) × 58 mm (H) [compact form factor for Tricon racks] |
| Weight | 0.8 kg |
| Certifications | SIL 3 (IEC 61508), CE, TÜV Rheinland-approved |
3806E 9720051-00
Related Products
- TRICONEX 3805E: A 16-channel analog output module with extended diagnostic capabilities, ideal for large-scale systems requiring higher I/O density.
- TRICONEX 3601E: A digital output module supporting SIL 3 applications, often paired with the TRICONEX 3806E 9720051-00 for hybrid control systems.
- TRICONEX 3723X: A 32-channel analog input module that complements the TRICONEX 3806E 9720051-00 in closed-loop process control.
- TRICONEX 9771-210: A termination board designed for direct integration with the TRICONEX 3806E 9720051-00, providing secure field wiring connections.
- TRICONEX 4351B: A redundant communication module enabling Ethernet/IP connectivity between the Tricon system and external SCADA platforms.
- TRICONEX 3625: A high-speed digital output module optimized for fast-acting safety interlocks, suitable for applications requiring sub-millisecond response times.
Main Features and Advantages
SIL 3 Safety Integrity: The TRICONEX 3806E 9720051-00 is certified to SIL 3, ensuring it meets the highest safety standards for applications where system failure could lead to catastrophic consequences. Its TMR architecture and self-diagnostic tools validate signal integrity and module health, reducing the risk of undetected faults.
Precision Signal Control: With 12-bit resolution and ±0.25% accuracy, the module delivers precise analog outputs to control valves, actuators, and other field devices. The 4–20 mA and 20–320 mA ranges accommodate a wide variety of industrial sensors and actuators, including those in hazardous environments.
Hot-Swap Capability: The TRICONEX 3806E 9720051-00 supports online replacement without system shutdown, minimizing downtime during maintenance. This feature is critical for industries like oil refining and power generation, where continuous operation is essential.
Robust Diagnostic Tools: Built-in diagnostics monitor output signals, wiring integrity, and module components in real time. Alerts for open circuits, over-range values, or component degradation enable proactive maintenance, reducing unplanned outages.
Flexible Integration: The module’s compatibility with TRICONEX termination boards and third-party adapters (e.g., Pepperl+Fuchs FI-PFH-TR-AO-380X) allows seamless integration into both legacy and modern automation systems. Its compact design also saves space in control racks.
3806E 9720051-00
Installation and Maintenance
Pre-Installation Preparations:
- Verify system compatibility: Ensure the Tricon controller and termination boards (e.g., 9771-210) are configured to support the TRICONEX 3806E 9720051-00. Check power supply stability (24 VDC ±10%) and grounding to prevent electrical interference.
- Inspect environmental conditions: Confirm the installation area meets temperature (-40°C to 70°C) and humidity (5–95% non-condensing) requirements. Clear the mounting area of debris and ensure the rack is securely fastened to minimize vibration.
Installation Steps:
- Power down the Tricon system or use redundant paths to avoid process interruption.
- Align the TRICONEX 3806E 9720051-00 with the designated slot in the Tricon rack, pressing firmly to engage backplane connectors.
- Connect shielded cables from the module to the termination board, following polarity guidelines. Secure wiring with strain relief to prevent accidental disconnections.
- Power on the system and use TRICONEX’s TriStation software to validate module communication and calibrate output signals.
Maintenance Suggestions:
- Perform quarterly visual inspections to check for loose connections, corrosion, or physical damage. Use TriStation’s diagnostic tools to review fault logs and signal quality.
- Schedule annual calibration using certified equipment to maintain accuracy. Replace the module if self-diagnostics detect irreparable faults, ensuring compatibility with the latest firmware updates.
- For hot-swap replacements, follow lockout/tagout procedures and ensure the spare module is pre-configured with the correct firmware version.
Application Fields
The TRICONEX 3806E 9720051-00 excels in industries where precise analog control is critical for safety and operational efficiency:
- Oil & Gas: Controls valve openings in wellheads and pipelines to manage hydrocarbon flow, supporting ESD systems during leaks or overpressure events.
- Chemical Processing: Regulates reactor temperature and pressure by adjusting actuator positions, preventing hazardous material releases and ensuring compliance with OSHA and REACH standards.
- Power Generation: Manages steam turbine speed and generator load in thermal plants, optimizing energy output while safeguarding against equipment damage.
- Pharmaceuticals: Ensures consistent sterilization and fermentation processes by maintaining precise actuator control, adhering to FDA and GMP regulations.
- Mining: Adjusts slurry density and conveyor belt tension in mineral processing, enhancing throughput while minimizing equipment wear.
3806E 9720051-00
Product Guarantee
Our company, a leading industrial control distributor with 17 years of experience, provides a 12-month warranty for the TRICONEX 3806E 9720051-00, covering manufacturing defects and hardware failures not caused by misuse. In the event of malfunction, we offer prompt replacement or repair services to minimize downtime. As a trusted supplier of TRICONEX products, we maintain a large inventory of the TRICONEX 3806E 9720051-00 and related components, including hard-to-find and discontinued models, to meet urgent customer needs. Our technical support team is available to assist with installation, configuration, and troubleshooting, ensuring seamless integration into your safety automation system. With reliable supply channels and a commitment to quality, we stand behind the performance and durability of every product we deliver.
