Product Overview
The TRICONEX 3000678-1001 is a critical power supply module designed for TRICONEX safety instrumented systems (SIS) and industrial automation setups. As a key component in TRICONEX’s portfolio, TRICONEX 3000678-1001 provides stable and reliable power to connected I/O modules, processors, and communication devices, ensuring uninterrupted operation of safety-critical systems. This module is part of TRICONEX’s fault-tolerant architecture, engineered to meet the rigorous demands of high-risk industries where power disruptions could lead to process failures or safety hazards.
TRICONEX 3000678-1001 is built to deliver consistent power output even in harsh industrial environments, with features that protect against voltage fluctuations, overloads, and short circuits. Its design integrates seamlessly with TRICONEX racks and modules, such as the TRICONEX 3700A rack and TRICONEX 2651 processor, making it a versatile choice for both new installations and system upgrades. By ensuring a steady power supply to critical components, TRICONEX 3000678-1001 plays a vital role in maintaining the integrity of safety loops, reducing the risk of unplanned shutdowns, and supporting continuous industrial operations.
Technical Specifications
| Product model | TRICONEX 3000678-1001 |
|---|---|
| Manufacturer | TRICONEX |
| Product type | Power supply module |
| Physical dimensions | 152 mm (length) x 102 mm (width) x 38 mm (height) |
| Weight | 450 grams |
| Place of origin | United States |
| Input voltage | 100-240V AC (50/60 Hz) |
| Output voltage | 24V DC |
| Output current | 10A |
| Efficiency | 85% typical |
| Operating temperature range | -20°C to 70°C |
| Humidity tolerance | 5% to 95% non-condensing |
| Overload protection | 120% of rated current (automatic recovery) |
| Short circuit protection | Instantaneous (automatic recovery) |
| Certifications | UL, CE, ATEX |
3000678-1001
Related products
- TRICONEX 3625: A 24V DC power supply module with a 5A output, suitable for smaller TRICONEX systems where lower current is needed, offering a compact alternative to TRICONEX 3000678-1001.
- TRICONEX 3700A: A rack assembly designed to house TRICONEX 3000678-1001 and other TRICONEX modules, providing mechanical support and backplane connectivity for integrated system operation.
- TRICONEX 2651: A processor module that relies on TRICONEX 3000678-1001 for power, using the module’s stable output to execute safety logic and control functions in SIS.
- TRICONEX 4329: A communication module powered by TRICONEX 3000678-1001, enabling data transfer between the SIS and external devices while maintaining signal integrity.
- TRICONEX 3000110-360: An external terminator baseplate that works with TRICONEX 3000678-1001 to distribute power to field devices, ensuring consistent energy flow in extended I/O configurations.
- TRICONEX 8312: A safety relay module that receives power from TRICONEX 3000678-1001, using its reliable output to activate emergency shutdown mechanisms in critical processes.
Main features and advantages
Stable power output: TRICONEX 3000678-1001 delivers a consistent 24V DC output with a 10A current rating, ensuring that connected TRICONEX modules—such as processors and I/O cards—receive the power they need to operate without interruptions. This stability is crucial in safety systems, where even minor voltage drops can cause false readings or system malfunctions.
Rugged industrial design: The module is built to withstand extreme conditions, including temperatures ranging from -20°C to 70°C and high humidity. Its durable casing and internal components resist corrosion and physical damage, making TRICONEX 3000678-1001 suitable for installation in harsh environments like offshore oil platforms, chemical plants, and power generation facilities.
Comprehensive protection mechanisms: TRICONEX 3000678-1001 includes overload and short circuit protection, automatically shutting down or reducing output when abnormal conditions are detected. This prevents damage to the module itself and the connected equipment, extending the lifespan of the entire system and reducing maintenance costs.
Seamless system integration: Designed specifically for TRICONEX racks and modules, TRICONEX 3000678-1001 fits easily into existing setups without the need for additional adapters. Its compatibility with key components like the TRICONEX 3700A rack and TRICONEX 2651 processor simplifies system design and reduces installation time.
High efficiency: With an 85% typical efficiency rating, TRICONEX 3000678-1001 minimizes energy waste, lowering operational costs in long-term use. This efficiency also reduces heat generation, contributing to a cooler operating environment for other modules in the rack.
3000678-1001
Installation and maintenance
Pre-installation preparations: Before installing TRICONEX 3000678-1001, check that the TRICONEX rack (such as the TRICONEX 3700A) is properly grounded and mounted on a flat, stable surface. Verify that the input power source matches the module’s 100-240V AC requirement and that the power cable is in good condition, with no signs of damage. Inspect the module for physical defects, such as cracks in the casing or bent pins, which could affect performance.
Installation steps: Align TRICONEX 3000678-1001 with the designated slot in the TRICONEX rack, ensuring the connectors on the back of the module line up with those in the rack. Slide the module into place until it is fully seated, then secure it with the provided screws to prevent movement from vibrations. Connect the input power cable to the module’s power inlet, ensuring the connection is tight to avoid power loss. Finally, check that the module’s status LED lights up, indicating it is receiving power correctly.
Maintenance suggestions: Conduct regular visual inspections of TRICONEX 3000678-1001 to look for loose connections, corrosion, or damage to the casing. Clean the module’s vents monthly to remove dust and debris, which can block airflow and cause overheating. Test the module’s output voltage quarterly using a multimeter to ensure it remains within the 24V DC ±10% range. If the status LED shows an error—such as a red light—refer to the user manual to identify the issue and address it promptly. Replace the module if it fails to recover from overload or short circuit conditions, as continued use could compromise system safety.
Application fields
TRICONEX 3000678-1001 is widely used in industries where reliable power supply is critical to safety and operational efficiency. In oil and gas facilities, it powers emergency shutdown systems (ESDs) on offshore platforms and refineries, ensuring that sensors, controllers, and shutdown valves receive consistent power to detect and respond to hazardous conditions like pressure spikes or gas leaks.
In chemical processing plants, TRICONEX 3000678-1001 supports the SIS by providing power to I/O modules that monitor reactor temperatures, flow rates, and chemical levels. Its ability to withstand corrosive environments and temperature extremes makes it a reliable choice for these settings, where equipment failure could lead to chemical spills or explosions.
Power generation facilities, including nuclear and coal-fired plants, rely on TRICONEX 3000678-1001 to supply power to turbine control systems. The module’s stable output ensures that vibration sensors, pressure monitors, and safety relays operate correctly, enabling the system to shut down turbines quickly in case of anomalies to prevent equipment damage or power outages.
Pharmaceutical manufacturing plants also use TRICONEX 3000678-1001 to power safety systems that monitor cleanroom conditions and sterilization processes. Its consistent power delivery helps maintain compliance with strict regulatory standards, ensuring that production environments remain safe and sterile.
3000678-1001
Product guarantee
Our company offers a one-year quality warranty service for TRICONEX 3000678-1001, covering hardware malfunctions not caused by human factors. During the warranty period, if TRICONEX 3000678-1001 shows abnormal performance—such as unstable output voltage or failure to power on—we will provide a replacement to minimize downtime. Our company is a leading import and export trade distribution company in the industrial control industry, established in 2007 with 17 years of experience. We have a large stock of industrial control parts, including unpopular and discontinued models, and our global supply channels allow us to meet urgent customer needs for spare parts. For TRICONEX 3000678-1001 and other TRICONEX products, we also offer technical support to assist with installation, troubleshooting, and maintenance, ensuring that your systems operate continuously and reliably.
