TRICONEX 3000656-210C1R Product Specification
Product Overview
The TRICONEX 3000656-210C1R is a high-reliability control module designed for TRICONEX’s Triple Modular Redundant (TMR) safety instrumented systems (SIS). It serves as a key component in executing safety logic, processing input signals from field devices, and generating output commands to ensure critical industrial processes operate within safe limits. This module is part of TRICONEX’s Trident platform, which is widely used in safety-critical applications where system failures could lead to severe consequences.
The TRICONEX 3000656-210C1R operates on a TMR architecture, meaning it includes three independent processing channels that work in parallel. This design ensures that if one channel fails, the other two continue to function, maintaining system integrity and preventing downtime. It integrates seamlessly with other TRICONEX components, such as the TRICONEX 3700A power supply and TRICONEX 3721 digital input modules, forming a cohesive safety system.
Built to withstand tough industrial conditions, the TRICONEX 3000656-210C1R operates in temperatures from -40°C to +70°C and handles humidity between 5% and 95% (non-condensing). Its compact size and durable construction make it suitable for installation in control cabinets across various industries, including oil refineries, chemical plants, and nuclear power facilities. The TRICONEX 3000656-210C1R ensures that safety functions, such as emergency shutdowns, are executed reliably, protecting both personnel and equipment.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | TRICONEX 3000656-210C1R |
| Manufacturer | TRICONEX |
| Product Type | TMR Safety Control Module |
| Compatible Systems | TRICONEX Trident TMR Safety Instrumented Systems (SIS) |
| Processing Channels | 3 (Triple Modular Redundant) |
| Input Voltage | 24 VDC |
| Physical Dimensions | 220 mm (L) × 150 mm (W) × 80 mm (H) |
| Weight | 1.2 kg |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing |
| Communication Protocol | TRICONEX Proprietary Backplane Protocol |
| Certifications | IEC 61508 (SIL 3), CE, UL 508 |
Related Products
- TRICONEX 3700A: A redundant power supply module that provides 24 VDC to the TRICONEX 3000656-210C1R, ensuring stable operation.
- TRICONEX 3721: A digital input module that sends sensor data to the TRICONEX 3000656-210C1R for safety logic processing.
- TRICONEX 2401S2: A digital output module that receives commands from the TRICONEX 3000656-210C1R to actuate valves or alarms.
- TRICONEX 8111: A communication module that allows the TRICONEX 3000656-210C1R to exchange data with external systems like DCS.
- TRICONEX 2201: A communication baseplate that houses the TRICONEX 3000656-210C1R and connects it to the system backplane.
Main Features and Advantages
Triple redundancy: The TRICONEX 3000656-210C1R uses three separate processing channels. Each channel checks the same input data. If one channel fails, the other two keep working. This means the system does not stop, even with a single fault. This is critical in oil refineries, where a shutdown could lead to leaks or fires.
SIL 3 compliance: The TRICONEX 3000656-210C1R meets IEC 61508 SIL 3 standards. This ensures it can be used in high-risk applications, such as nuclear power plants, where safety is the top priority. It reduces the chance of mistakes in safety actions, like false emergency shutdowns.
Easy integration: The module fits into TRICONEX Trident system racks without extra tools. It connects to other modules through the backplane, so no extra wiring is needed. This makes installation fast and reduces the risk of setup errors.
Tough design: The TRICONEX 3000656-210C1R works in extreme temperatures, from very cold (-40°C) to very hot (+70°C). It also handles high humidity. This makes it suitable for outdoor use, like on offshore oil platforms or in desert plants.
Low maintenance: The module has no moving parts, so it rarely needs repairs. It can be replaced while the system is running (hot-swappable), which means no downtime during maintenance. This is helpful in chemical plants that run 24/7.
Installation and Maintenance
Pre-installation preparations: Before installing the TRICONEX 3000656-210C1R, turn off power to the system rack. Check that the rack slot is clean and free of dust. Make sure the input voltage is 24 VDC, matching the power supply (like the TRICONEX 3700A). Align the module with the rack guides and slide it in until it clicks into place. Tighten the front screws to keep it secure.
Maintenance suggestions: Check the TRICONEX 3000656-210C1R once a month. Look for loose screws or signs of overheating, like discolored plastic. Wipe dust off the module with a dry cloth. Test the redundancy every three months by using system software to simulate a fault in one channel. Make sure the other two channels take over. If the module shows a fault light that won’t turn off, replace it to keep the system safe.
Application Fields
In oil and gas: The TRICONEX 3000656-210C1R controls emergency shutdown systems on offshore platforms. It processes data from pressure sensors. If pressure gets too high, it sends a signal to close valves. Its redundancy ensures this happens even if one channel fails during a storm.
In chemical processing: The module is used in batch reactor systems. It takes input from temperature sensors (connected to TRICONEX 3721 modules). If the temperature exceeds safe limits, it triggers isolation valves to stop the reaction. This prevents chemical leaks.
In nuclear power: The TRICONEX 3000656-210C1R is part of reactor safety systems. It monitors coolant levels and radiation. If levels are unsafe, it activates safety measures, like shutting down the reactor. Its SIL 3 rating meets strict nuclear safety rules.
In water treatment: The module controls pump systems in wastewater plants. It uses input from level sensors to adjust pump speeds. This keeps water levels stable and prevents overflows. Its tough design works in the humid environment of treatment facilities.
Product Guarantee
Our company offers a one-year quality warranty service for TRICONEX 3000656-210C1R, covering hardware malfunctions not caused by human factors. During the warranty period, if TRICONEX 3000656-210C1R shows abnormal performance or stops working, we will replace it. For discontinued models or urgent needs, our global supply chain lets us quickly get hard-to-find parts. This helps keep your industrial systems running.
