GE IS200TVIBH2BBB Mark VIe Vibration Monitoring Module
Product Overview
The GE IS200TVIBH2BBB is a high-precision vibration monitoring module designed as a critical component of GE’s Mark VIe distributed control system (DCS), specializing in real-time vibration analysis for rotating machinery. Engineered to convert mechanical vibrations into electrical signals, this module serves as the core of turbine, compressor, and generator health monitoring in power generation, oil & gas, and manufacturing sectors. As part of the IS200 Series, the IS200TVIBH2BBB integrates seamlessly with other Mark VIe components (e.g., control processors, I/O modules), enabling comprehensive machinery protection and predictive maintenance strategies.
Featuring a rugged industrial design, the GE IS200TVIBH2BBB supports multi-channel vibration measurement with a frequency response ranging from 10 to 10,000 Hz, ensuring accurate detection of imbalance, bearing wear, and structural defects. Its advanced signal conditioning circuitry includes anti-aliasing filters and galvanic isolation, minimizing noise interference in harsh environments. The module’s dual-channel architecture allows simultaneous monitoring of radial and axial vibrations, while built-in self-diagnostics provide real-time health feedback, reducing mean time to repair (MTTR). With a wide operating temperature range (-40°C to +85°C) and compliance with industry standards (e.g., API 670), the IS200TVIBH2BBB delivers reliable performance in critical applications.
In automation ecosystems, the IS200TVIBH2BBB bridges field-mounted vibration sensors with the Mark VIe control platform, enabling real-time data transmission to SCADA systems for trend analysis and alarm activation. Its compatibility with GE’s Proficy software suite allows remote configuration and predictive maintenance scheduling, enhancing operational efficiency. By combining precision measurement with robust fault tolerance, this module optimizes equipment lifespan and reduces unplanned downtime, making it indispensable for industries reliant on continuous operation.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200TVIBH2BBB |
| Manufacturer | GE |
| Product Type | Vibration Monitoring Module |
| Platform | Mark VIe |
| Input Channels | 2 isolated channels |
| Frequency Response | 10–10,000 Hz |
| Measurement Range | 0–100 mils (0–2.54 mm) displacement, 0–100 in./sec (0–2540 mm/sec) velocity |
| Output Signal | 4–20 mA, ±10 V DC |
| Power Supply | 24 V DC ±10% (from Mark VIe rack) |
| Physical Dimensions | 228.6 mm (H) × 177.8 mm (W) × 76.2 mm (D) |
| Weight | 1.5 kg |
| Operating Temperature | -40°C to +85°C |
| Mounting | Rack-mounted in Mark VIe enclosure |
| Certifications | CE, UL, IEC 61131-2 |
Key Features and Advantages
High-Accuracy Vibration Analysis: The IS200TVIBH2BBB delivers precise vibration measurements with ±1% accuracy, enabling early detection of mechanical anomalies. Its dual-channel design supports simultaneous monitoring of multiple axes, providing comprehensive insights into equipment health.
Robust Signal Conditioning: Advanced filtering and isolation circuitry reduce electromagnetic interference, ensuring reliable data acquisition in high-noise environments. Galvanic isolation between channels prevents ground loops, enhancing measurement integrity.
Hot-Swap Capability: The module can be replaced without powering down the system, minimizing downtime during maintenance. This feature is critical for 24/7 operations in power plants and refineries.
Comprehensive Diagnostics: Built-in self-test functions monitor module health, signal integrity, and power supply status, with real-time alerts via LED indicators and the Mark VIe system. This proactive approach reduces troubleshooting time.
Wide Environmental Tolerance: Engineered to withstand extreme temperatures, vibration, and humidity, the IS200TVIBH2BBB meets rigorous industrial standards, making it suitable for offshore platforms, refineries, and heavy manufacturing.
Seamless System Integration: Compatible with GE’s Mark VIe I/O modules and Proficy software, the module supports scalable automation architectures. Its open communication protocols (Modbus, Ethernet/IP) enable integration with third-party systems.
Application Areas
The GE IS200TVIBH2BBB is essential for vibration monitoring in industries where equipment reliability is non-negotiable:
- Power Generation: Monitors steam turbines, generators, and auxiliary equipment in thermal, hydro, and nuclear plants to ensure grid stability and optimize maintenance schedules.
- Oil & Gas: Installed on compressors, pumps, and turbines in refineries and offshore platforms to detect early signs of wear, preventing unplanned shutdowns.
- Manufacturing: Used in high-speed rotating machinery (e.g., motors, fans, conveyors) in automotive, chemical, and food processing facilities to maintain production continuity.
- Mining: Deployed in crushers, mills, and ventilation systems to monitor equipment health in harsh environments, reducing maintenance costs.
Specific applications include:
- Bearing Condition Monitoring: Analyzes vibration patterns to detect bearing degradation, enabling proactive replacement before catastrophic failure.
- Imbalance Detection: Identifies rotational imbalance in turbines and pumps, allowing timely balancing to reduce mechanical stress.
- Structural Vibration Analysis: Measures casing vibrations in reciprocating engines to assess structural integrity.
Related Products
- IS200TCCVH1A Turbine Control Module: Works with the IS200TVIBH2BBB to integrate vibration data into turbine control logic.
- IS200TSVIH1B Temperature Input Module: Complements vibration monitoring with temperature data for comprehensive equipment health analysis.
- IS200ALGHH1BB Algorithm Module: Processes vibration data with advanced algorithms for predictive maintenance insights.
- IS200COMM Communication Module: Enables Ethernet connectivity for remote access to IS200TVIBH2BBB data via SCADA systems.
- IS200PWR Power Supply Module: Ensures reliable power for the IS200TVIBH2BBB in redundant configurations.
- IS200TBCH Terminal Block Module: Simplifies field wiring for vibration sensor connections to the IS200TVIBH2BBB.
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IS200TVIBH2BBB, ensure the Mark VIe rack is properly grounded and ventilated. Verify power supply compatibility (24 V DC) and install redundant power modules for reliability. Mount the module in the rack using provided hardware, ensuring adequate spacing for heat dissipation. Connect vibration sensors to the input channels using shielded cables, routing them separately from high-voltage lines to minimize interference. Use GE’s Proficy software to configure measurement parameters (e.g., alarm thresholds, frequency range) before commissioning.
Before installing the GE IS200TVIBH2BBB, ensure the Mark VIe rack is properly grounded and ventilated. Verify power supply compatibility (24 V DC) and install redundant power modules for reliability. Mount the module in the rack using provided hardware, ensuring adequate spacing for heat dissipation. Connect vibration sensors to the input channels using shielded cables, routing them separately from high-voltage lines to minimize interference. Use GE’s Proficy software to configure measurement parameters (e.g., alarm thresholds, frequency range) before commissioning.
Maintenance Suggestions:
- Routine Inspections: Quarterly visual checks of LED indicators and secure connections. Use Proficy software to review vibration trends and diagnostic reports.
- Calibration: Annually calibrate the IS200TVIBH2BBB using a vibration shaker table to ensure measurement accuracy. Document calibration results for compliance.
- Firmware Updates: Periodically update the module’s firmware to incorporate bug fixes and new features, following GE’s validated procedures.
- Spare Parts Management: Store spare IS200TVIBH2BBB modules in a controlled environment (10–30°C, <50% humidity) to ensure rapid replacement during failures.
Product Guarantee
Our company provides a 12-month quality warranty for the GE IS200TVIBH2BBB, covering hardware defects under normal use. In the event of measurement anomalies or functional failures, we offer prompt replacement services to minimize downtime. For legacy or urgent requirements, our global supply chain ensures rapid delivery of the IS200TVIBH2BBB and related spares. Our technical support team assists with installation, calibration, and troubleshooting, delivering reliable solutions to maintain your equipment’s health and operational efficiency.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
