GE IS200TSVCH2ADC MRP061873 Temperature Input Module
Product Overview
The GE IS200TSVCH2ADC MRP061873 is a high-precision Temperature Input Module designed for GE’s Mark VIe distributed control system (DCS), catering to critical industrial automation and machinery monitoring applications. Engineered to convert analog temperature signals from field sensors into digital data, this module serves as the interface between temperature transmitters and the control system, enabling real-time monitoring and control of process temperatures in power generation, oil & gas, and manufacturing sectors. As part of the IS200 Series, the IS200TSVCH2ADC MRP061873 integrates seamlessly with other Mark VIe components (e.g., control modules, communication gateways), forming a robust ecosystem for industrial temperature management.
Featuring a rugged industrial design, the GE IS200TSVCH2ADC MRP061873 supports multiple temperature sensor types, including resistance temperature detectors (RTDs), thermocouples (J, K, T types), and millivolt inputs, with configurable ranges to adapt to diverse applications. Its advanced signal conditioning circuitry includes anti-aliasing filters and galvanic isolation, ensuring measurement accuracy within ±0.1% of full scale while minimizing electromagnetic interference. The module’s hot-swappable design allows replacement without powering down the system, reducing downtime during maintenance. With a wide operating temperature range (-40°C to +85°C) and compliance with industry standards (e.g., IEC 61131-2), the IS200TSVCH2ADC MRP061873 ensures reliable performance in harsh industrial environments, from offshore platforms to thermal power plants.
In automation systems, the IS200TSVCH2ADC MRP061873 plays a pivotal role in converting raw temperature data into actionable insights for process control. Its compatibility with GE’s Proficy software suite enables real-time data visualization, trend analysis, and remote configuration, enhancing operational efficiency and predictive maintenance capabilities. By delivering precise temperature monitoring, this module supports critical applications such as turbine casing temperature control, reactor process optimization, and heat exchanger management, ensuring safety, efficiency, and compliance in industrial operations.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200TSVCH2ADC MRP061873 |
| Manufacturer | GE |
| Product Type | Temperature Input Module |
| Platform | Mark VIe |
| Input Channels | 8 isolated channels |
| Sensor Types | RTD (Pt100, Ni100), thermocouples (J, K, T), 0–100 mV |
| Resolution | 16-bit |
| Accuracy | ±0.1% of full scale |
| Isolation | 250 V RMS galvanic isolation per channel |
| Power Supply | 24 V DC ±10% (from Mark VIe rack) |
| Physical Dimensions | 228.6 mm (H) × 177.8 mm (W) × 76.2 mm (D) |
| Weight | 1.5 kg |
| Operating Temperature | -40°C to +85°C |
| Mounting | Rack-mounted in Mark VIe enclosure |
| Communication | Proprietary Mark VIe bus (compatible with Modbus via gateway) |
Key Features and Advantages
Multi-Sensor Compatibility: The IS200TSVCH2ADC MRP061873 accommodates diverse temperature sensors, eliminating the need for dedicated modules and reducing hardware complexity. This versatility supports mixed-sensor setups in complex industrial processes.
High Precision and Noise Immunity: With 16-bit resolution and advanced filtering, the module delivers highly accurate temperature measurements even in noisy environments. Galvanic isolation between channels prevents ground loops, ensuring signal integrity.
Hot-Swap Capability: Designed for maintenance in live systems, the module can be replaced without interrupting operations, critical for 24/7 industrial processes where downtime impacts productivity.
Redundant Design Elements: Built-in error-checking and redundant power paths enhance reliability, ensuring continuous operation during transient faults. This is vital for mission-critical applications like turbine temperature monitoring.
Rugged Industrial Construction: The module’s metal enclosure and conformal-coated circuitry withstand extreme temperatures, vibration, and humidity, meeting rigorous industrial standards (e.g., IEC 60068-2-6 for vibration resistance).
Seamless System Integration: Compatible with GE’s Mark VIe ecosystem and Proficy software, the module supports real-time data integration with SCADA and DCS systems, enabling remote monitoring and predictive maintenance.
Application Areas
The GE IS200TSVCH2ADC MRP061873 is widely deployed in industries requiring precise temperature control and monitoring:
- Power Generation: Monitors stator and rotor temperatures in generators, turbine casing temperatures, and boiler water temperatures in thermal power plants, ensuring optimal efficiency and preventing overheating.
- Oil & Gas: Measures process temperatures in refineries, pipeline compression stations, and offshore platforms, supporting safe operation and compliance with environmental regulations.
- Manufacturing: Controls temperatures in chemical reactors, kilns, and ovens in pharmaceutical, food & beverage, and automotive plants, ensuring product quality and process consistency.
- Water/Wastewater Treatment: Monitors water temperatures in treatment plants, optimizing chemical reaction efficiency and ensuring regulatory compliance.
Specific applications include:
- Turbine Health Monitoring: Integrates with RTDs to track rotor temperatures in steam turbines, providing early warnings of overheating.
- Process Optimization: Uses thermocouple inputs to maintain precise temperatures in distillation columns, enhancing separation efficiency in refineries.
- Safety Systems: Feeds temperature data into safety instrumented systems (SIS) to trigger alarms or shutdowns when critical thresholds are exceeded.
Related Products
- IS200TCCVH1A Turbine Control Module: Works with the IS200TSVCH2ADC MRP061873 to process temperature data for turbine speed and load control.
- IS200AAHAH2ADC Analog Input Module: Complements the temperature module with general analog signal acquisition for mixed-process monitoring.
- IS200AASAH2ADC Analog Output Module: Sends control signals based on temperature data from the IS200TSVCH2ADC MRP061873 to actuators.
- IS200COMM Communication Module: Enables Ethernet connectivity for the IS200TSVCH2ADC MRP061873, supporting remote temperature data access.
- IS200PWR Power Supply Module: Ensures reliable power for the IS200TSVCH2ADC MRP061873 in redundant power configurations.
- IS200TBCH Terminal Block Module: Simplifies field wiring for temperature sensors, compatible with the IS200TSVCH2ADC MRP061873
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IS200TSVCH2ADC MRP061873, ensure the Mark VIe rack is properly grounded and ventilated. Verify sensor compatibility (e.g., RTD or thermocouple) and configure input ranges using GE’s Proficy software. Route shielded cables for sensor connections, separating them from high-voltage lines to minimize interference. Mount the module in the rack, securing it with provided hardware, and connect power and communication cables per GE’s wiring guidelines. Calibrate the module with a known temperature source to validate accuracy before commissioning.
Before installing the GE IS200TSVCH2ADC MRP061873, ensure the Mark VIe rack is properly grounded and ventilated. Verify sensor compatibility (e.g., RTD or thermocouple) and configure input ranges using GE’s Proficy software. Route shielded cables for sensor connections, separating them from high-voltage lines to minimize interference. Mount the module in the rack, securing it with provided hardware, and connect power and communication cables per GE’s wiring guidelines. Calibrate the module with a known temperature source to validate accuracy before commissioning.
Maintenance Suggestions:
- Routine Checks: Monthly visual inspections of terminal connections and LED indicators to ensure secure wiring and normal operation. Use Proficy software to review channel diagnostics for out-of-range readings.
- Calibration: Annually calibrate the module using a precision temperature source to maintain accuracy. Document calibration results for compliance.
- Environmental Management: Quarterly cleaning of module vents to prevent dust accumulation, especially in dusty environments. Ensure the control room maintains stable temperature and humidity.
- Spare Parts Management: Store spare IS200TSVCH2ADC MRP061873 modules in a static-free, temperature-controlled environment (20–25°C) to ensure rapid replacement during failures.
Product Guarantee
Our company provides a 12-month quality warranty for the GE IS200TSVCH2ADC MRP061873, covering hardware defects under normal use. In the event of measurement inaccuracies or module failures, we offer prompt replacement services to minimize downtime. For legacy or urgent requirements, our global supply chain ensures rapid delivery of the IS200TSVCH2ADC MRP061873 and related spares. Our technical support team assists with installation, calibration, and troubleshooting, delivering reliable solutions to maintain your temperature monitoring systems.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
