GE IS200ISBBG2AAB Product Specification
Product Overview
The GE IS200ISBBG2AAB is a high-reliability interface module designed for GE’s Mark VIe Turbine Control System, a cornerstone of industrial automation in power generation and heavy machinery applications. Engineered to facilitate seamless communication between the turbine control system and field devices, the GE IS200ISBBG2AAB serves as a critical bridge for analog and digital signal processing. As part of GE’s extensive IS200 series, this module supports real-time data exchange, ensuring precise control and monitoring of steam turbines, gas turbines, and other rotating equipment in power plants and manufacturing facilities.
The GE IS200ISBBG2AAB integrates 16 channels of analog input/output (I/O) and 8 channels of digital I/O, enabling comprehensive connectivity with sensors, actuators, and other control modules. It features a robust design with a metal enclosure and conformal-coated PCBs, ensuring durability in harsh environments with high vibration and temperature fluctuations. The module’s compatibility with GE’s Proficy software allows for flexible configuration of signal ranges, alarm thresholds, and communication protocols, making it an adaptable solution for complex automation setups.
In turbine control systems, the GE IS200ISBBG2AAB plays a pivotal role in translating field signals into process variables for the control system, supporting critical functions like speed regulation, load sharing, and emergency shutdowns. Its high-speed data processing (up to 1 ms cycle time) and built-in diagnostic features enhance system reliability, reducing downtime and maintenance costs. By integrating with GE’s Mark VIe platform, the module empowers engineers to optimize turbine performance, ensure regulatory compliance, and maximize energy efficiency.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IS200ISBBG2AAB |
| Manufacturer | General Electric (GE) |
| Product Type | Interface Module (Turbine Control) |
| Analog I/O Channels | 16 channels (4–20 mA, 0–10 VDC) |
| Digital I/O Channels | 8 channels (24 VDC) |
| Communication Protocol | GE Genius Bus, Modbus RTU |
| Power Supply | 24 VDC ±10% |
| Physical Dimensions | 203 mm (W) × 140 mm (H) × 76 mm (D) |
| Weight | 1.2 kg |
| Operating Temperature | 0°C to +55°C |
| Humidity | 5–95% non-condensing |
| Certifications | CE, UL |
| Country of Origin | USA |
Main Features and Advantages
Multi-Channel Signal Handling: The GE IS200ISBBG2AAB supports 16 analog and 8 digital I/O channels, enabling comprehensive connectivity with field devices. This multi-channel capability reduces the need for additional modules, simplifying system architecture and lowering costs.
Rugged Industrial Design: Constructed with a metal enclosure and anti-vibration mounting, the module withstands harsh industrial environments, including high temperatures and mechanical stress. Its conformal-coated PCBs protect against dust, moisture, and electromagnetic interference (EMI).
Flexible Configuration: Users can configure signal ranges, filter settings, and alarm thresholds via GE’s Proficy software, adapting the module to specific turbine control requirements. This flexibility supports customizations for different turbine types and operational scenarios.
High-Speed Data Processing: With a 1 ms cycle time, the GE IS200ISBBG2AAB ensures real-time signal processing, critical for dynamic turbine control applications. Its built-in diagnostics monitor channel health, enabling proactive maintenance to prevent unexpected failures.
Seamless System Integration: As part of GE’s Mark VIe system, the module integrates seamlessly with other IS200 series components (e.g., CPU modules, communication gateways), forming a cohesive control solution. This integration supports scalable systems from small turbines to large power plant complexes.
Application Areas
The GE IS200ISBBG2AAB is essential in industries requiring precise turbine control and monitoring:
-
Power Generation:
- Controls steam turbines in thermal power plants, adjusting valve positions based on analog signals from pressure and temperature sensors.
- Manages gas turbines in combined cycle plants, enabling real-time load adjustments and efficiency optimization.
-
Oil and Gas:
- Monitors compressor turbines in refineries, ensuring safe operation and preventing overpressure conditions.
- Integrates with pipeline pumping stations to regulate flow rates via digital I/O signals.
-
Manufacturing:
- Controls steam turbines in paper mills for precise temperature and pressure regulation during production.
- Manages energy recovery turbines in steel plants, converting waste heat into usable power.
-
Marine Engineering:
- Operates marine steam turbines for propulsion systems, supporting real-time speed and load control.
- Monitors turbine health in offshore platforms, enabling remote diagnostics via Modbus communication.
Related Products
- GE IS200TBPSH1BAA: A turbine control power supply module that provides stable 24 VDC to the GE IS200ISBBG2AAB and other Mark VIe components.
- GE IS200TBCVH1AAA: A high-voltage I/O module for heavy-duty applications, often paired with the GE IS200ISBBG2AAB in complex turbine control systems.
- GE IS200TCCPH1A: A CPU module for Mark VIe systems, serving as the central processor for data processed by the GE IS200ISBBG2AAB.
- GE IS200TCVIH1B: A voltage input module that complements the GE IS200ISBBG2AAB by processing high-voltage analog signals.
- GE IS200TBRGH1A: A relay output module for emergency shutdown systems, integrated with the GE IS200ISBBG2AAB for safety-critical applications.
Installation and Maintenance
Pre-installation Preparation:
Before installing the GE IS200ISBBG2AAB, ensure the following:
Before installing the GE IS200ISBBG2AAB, ensure the following:
- Verify the power supply meets 24 VDC ±10% and that the control rack is properly grounded to prevent electrostatic discharge (ESD). Use a multimeter to confirm voltage stability.
- Use GE’s Proficy software to configure I/O channel types (analog/digital), signal ranges, and communication parameters (e.g., baud rate for Modbus).
- Mount the module in a 19″ rack with at least 25 mm of clearance for airflow, securing it with the provided brackets to minimize vibration.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks of front-panel LEDs (green for normal operation, red for faults) and cleaning dust from ventilation slots.
- Calibration: Annual calibration of analog channels using a certified signal generator to ensure measurement accuracy.
- Firmware Updates: Periodically update the module’s firmware via GE’s software to access bug fixes and compatibility improvements.
- System Testing: Biannual functional tests of all I/O channels to verify signal integrity and alarm responses.
Product Warranty
Our company provides a one-year quality warranty for the GE IS200ISBBG2AAB, covering hardware failures due to non-human factors. During the warranty period, we will replace any module that exhibits abnormal signal processing or functional defects. For discontinued models like the GE IS200ISBBG2AAB, our global inventory of legacy industrial parts ensures rapid fulfillment of urgent orders. We also offer post-warranty technical support and repair services to maintain your system’s reliability over its lifecycle.
Contact Information:
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Whatsapp: +86 18859254943
E-mail: sales@ygplc.com
Note: This document is based on GE’s official specifications and industry applications. For detailed guidelines, refer to the GE IS200ISBBG2AAB user manual or contact our technical support team.
