GE IS200EPSMG1AED Mark VIe Power Supply Module
Product Overview
The GE IS200EPSMG1AED is a high-reliability Power Supply Module designed as a critical component of GE’s Mark VIe distributed control system (DCS), catering to industrial automation and turbine control applications. Engineered to deliver stable and redundant power to control racks and field devices, this module ensures continuous operation of critical systems in power generation, oil & gas, and manufacturing sectors. As part of the IS200 Series, the IS200EPSMG1AED integrates seamlessly with other Mark VIe components (e.g., control modules, I/O cards), providing a robust power infrastructure for mission-critical operations.
Featuring a rugged industrial design, the GE IS200EPSMG1AED converts 100–240 V AC input to 24 V DC output with high efficiency, supporting both single and redundant configurations. Its hot-swappable architecture allows module replacement without powering down the system, minimizing downtime during maintenance. The module’s advanced power conditioning circuitry includes overvoltage, overcurrent, and thermal protection, ensuring reliable performance in harsh environments with temperature ranges from -40°C to +70°C. Complying with industry standards like IEEE 1131-2 and UL 508, the IS200EPSMG1AED is ideal for applications requiring continuous operation in challenging industrial settings.
In automation ecosystems, the IS200EPSMG1AED serves as the power backbone for Mark VIe control racks, delivering clean power to CPU modules, communication gateways, and I/O cards. Its redundant design (when paired with another IS200EPSMG1AED) eliminates single points of failure, critical for maintaining system availability in 24/7 operations. By combining high-efficiency power conversion with robust fault tolerance, this module enhances the reliability and longevity of industrial control systems, making it indispensable for sectors where downtime translates to significant losses.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IS200EPSMG1AED |
| Manufacturer | GE |
| Product Type | Power Supply Module |
| Platform | Mark VIe |
| Input Voltage | 100–240 V AC, 50/60 Hz |
| Output Voltage | 24 V DC ±0.5% |
| Output Current | 10 A continuous |
| Efficiency | 85% typical |
| Redundancy Support | Yes (parallel operation with identical modules) |
| Physical Dimensions | 228.6 mm (H) × 177.8 mm (W) × 76.2 mm (D) |
| Weight | 2.5 kg |
| Operating Temperature | -40°C to +70°C |
| Mounting | Rack-mounted in Mark VIe enclosure |
| Certifications | CE, UL, IEEE 1131-2 |
Key Features and Advantages
Redundant Power Architecture: The IS200EPSMG1AED supports parallel redundancy, allowing two modules to operate in tandem for continuous power supply even if one fails. This feature is critical for maintaining system uptime in mission-critical applications.
Hot-Swap Capability: The module can be replaced without interrupting the system, enabling maintenance in live environments. This reduces downtime and enhances operational efficiency in 24/7 industrial processes.
High-Efficiency Power Conversion: With 85% energy efficiency, the IS200EPSMG1AED minimizes heat generation and energy loss, reducing cooling requirements and operational costs in industrial control rooms.
Comprehensive Protection Mechanisms: Built-in overvoltage, overcurrent, and thermal protection circuits safeguard the module and connected devices from damage, extending the lifespan of both the power supply and downstream components.
Wide Input Voltage Range: Supporting 100–240 V AC input, the module adapts to diverse global power grids, eliminating the need for region-specific adapters and simplifying installation in international projects.
Rugged Industrial Design: Engineered to withstand extreme temperatures, vibration, and electromagnetic interference, the IS200EPSMG1AED meets rigorous industrial standards, ensuring reliable performance in offshore platforms, refineries, and power plants.
Application Areas
The GE IS200EPSMG1AED is essential for powering industrial control systems in sectors where reliability is non-negotiable:
- Power Generation: Powers turbine control systems in thermal, hydro, and renewable energy plants, ensuring stable power output and grid synchronization.
- Oil & Gas: Supports control racks in refineries, pipeline compression stations, and offshore platforms, maintaining continuous operation of critical processes like wellhead control and gas separation.
- Manufacturing: Powers PLC and DCS systems in automotive, chemical, and food processing plants, enabling precise control of production lines and quality assurance systems.
- Water/Wastewater Treatment: Controls pumps, valves, and filtration systems in treatment plants, adapting to fluctuating demand while maintaining regulatory compliance.
Specific applications include:
- Turbine Control Systems: Powers Mark VIe racks in steam and gas turbines, ensuring uninterrupted operation of speed governors and safety interlocks.
- Process Automation: Supplies power to control modules in chemical reactors, maintaining optimal process parameters and preventing operational disruptions.
- Emergency Shutdown Systems (ESD): Ensures reliable power to safety-critical ESD systems in hazardous environments, supporting rapid response to emergencies.
Related Products
- IS200EPSMH1AED Power Supply Module: A higher-current variant (15 A) of the IS200EPSMG1AED, suitable for systems with higher power demands.
- IS200TCTGG1AED Turbine Control Module: Works in tandem with the IS200EPSMG1AED to manage turbine speed and load in power generation applications.
- IS200AAHAH2ADC Analog Input Module: Integrates with the IS200EPSMG1AED to acquire process data for control systems.
- IS200PWRPS1A Power Supply Base: Provides a mounting platform for the IS200EPSMG1AED, enhancing thermal management and rack organization.
- IS200COMM Communication Module: Relies on the IS200EPSMG1AED for power, enabling Ethernet connectivity for remote monitoring.
- IS200VCMAG1AED Valve Control Module: Uses power from the IS200EPSMG1AED to manage hydraulic valves in turbine control systems.
Installation and Maintenance
Pre-installation Preparations:
Before installing the GE IS200EPSMG1AED, ensure the Mark VIe rack is properly grounded and ventilated. Verify input voltage compatibility (100–240 V AC) and install redundant power cables for reliability. Mount the module in the rack using anti-vibration brackets, ensuring adequate spacing for heat dissipation. Connect input power using shielded cables and terminate them in the rack’s power distribution block, following GE’s wiring guidelines to minimize electromagnetic interference. For redundant configurations, install a second IS200EPSMG1AED in parallel, ensuring correct polarity and wiring.
Before installing the GE IS200EPSMG1AED, ensure the Mark VIe rack is properly grounded and ventilated. Verify input voltage compatibility (100–240 V AC) and install redundant power cables for reliability. Mount the module in the rack using anti-vibration brackets, ensuring adequate spacing for heat dissipation. Connect input power using shielded cables and terminate them in the rack’s power distribution block, following GE’s wiring guidelines to minimize electromagnetic interference. For redundant configurations, install a second IS200EPSMG1AED in parallel, ensuring correct polarity and wiring.
Maintenance Suggestions:
- Routine Inspections: Monthly visual checks of LED indicators to verify power output and fault status. Use a multimeter to measure output voltage and current, comparing readings against specifications.
- Cleaning and Cooling: Quarterly cleaning of the module’s vents to prevent dust accumulation, especially in dusty environments. Ensure the rack’s cooling fans operate efficiently to maintain optimal temperatures.
- Redundancy Testing: Annually simulate a power module failure to verify the redundant module switches on correctly, documenting test results for compliance.
- Spare Parts Management: Store spare IS200EPSMG1AED modules in a controlled environment (10–30°C, <50% humidity) to ensure rapid replacement during failures. Test spares periodically to maintain functionality.
Product Guarantee
Our company provides a 12-month quality warranty for the GE IS200EPSMG1AED, covering hardware defects under normal use. In the event of power output anomalies or functional failures, we offer prompt replacement services to minimize downtime. For legacy or urgent requirements, our global supply chain ensures rapid delivery of the IS200EPSMG1AED and related spares. Our technical support team assists with installation, redundancy configuration, and troubleshooting, ensuring reliable power supply for your industrial control systems.
For inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
