Product Overview
The ABB 500PB101 1MRB178009R0001 1MRB200064/C power distribution module is a high-performance component designed for industrial automation systems, specifically engineered to deliver reliable power management and distribution within ABB’s AC500 PLC platform. As part of the AC500 series, this module ensures stable power supply to critical control and I/O modules, making it an essential asset for applications requiring precision and uptime in industries such as power generation, manufacturing, and water treatment.
With a 24V DC input voltage and 12-channel output configuration, the 500PB101 provides redundant power paths to minimize downtime in mission-critical operations. Its compact design (120 x 100 x 80 mm) and DIN rail mounting compatibility allow seamless integration into existing control cabinets, reducing installation complexity. The module features LED indicators for real-time monitoring of power status and fault conditions, enabling proactive maintenance and troubleshooting.Whatsapp:+86 18859254943.
In automation systems, the 500PB101 acts as a central hub for power distribution, connecting PLC controllers, communication modules, and field devices. Its galvanic isolation protects downstream components from voltage spikes and electromagnetic interference (EMI), ensuring signal integrity and system reliability. By supporting hot-swap functionality, the module allows for maintenance without interrupting system operation, enhancing operational efficiency.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | 500PB101 1MRB178009R0001 1MRB200064/C |
| Manufacturer | ABB |
| Product Type | Power Distribution Module |
| Input Voltage | 24V DC (±10%) |
| Output Channels | 12 x 2A |
| Voltage Regulation | ±2% nominal |
| Power Consumption | <5W |
| Physical Dimensions | 120 x 100 x 80 mm |
| Mounting Type | DIN rail (35 mm) |
| Weight | 0.6 kg |
| Operating Temperature | -20°C to +60°C |
| Humidity | 5–95% non-condensing |
| Protection Rating | IP20 |
| Communication Interface | Modbus RTU (optional) |
500PB101 1MRB178009R0001 1MRB200064/C
Key Features and Advantages
Redundant Power Architecture: The 500PB101 incorporates dual power input channels, ensuring continuous operation even if one path fails. This redundancy is critical for applications where downtime is costly, such as power plants and petrochemical facilities.Whatsapp:+86 18859254943.
Precision Voltage Regulation: With ±2% voltage regulation, the module maintains stable power output to sensitive components, preventing performance degradation due to voltage fluctuations.
Hot-Swap Capability: The module supports hot-swap functionality, allowing replacement of faulty components without shutting down the entire system. This feature reduces maintenance time and enhances operational continuity.
Compact Design: The 500PB101’s compact size and lightweight construction (0.6 kg) simplify installation in space-constrained environments, while its DIN rail mounting ensures compatibility with standard industrial cabinets.
Comprehensive Monitoring: Built-in LED indicators provide real-time status updates for power supply, output channels, and fault conditions, enabling quick identification and resolution of issues.
Application Areas
The ABB 500PB101 1MRB178009R0001 1MRB200064/C power distribution module is ideally suited for industries requiring reliable power management:
- Power Generation: Integrates with ABB’s AC500 PLC to manage power distribution in gas and steam turbine control systems, ensuring stable energy output and grid synchronization.
- Manufacturing: Powers production lines, robotics, and conveyor systems in automotive, food & beverage, and pharmaceutical industries, optimizing efficiency and reducing downtime.
- Water Treatment: Provides stable power to pumps, valves, and monitoring equipment in wastewater treatment plants, ensuring compliance with environmental standards.
- Oil & Gas: Supports power distribution for offshore platforms, refineries, and pipeline systems, where uninterrupted operation is essential for production continuity.
- Mining: Reliably distributes power to ventilation systems, crushers, and conveyor belts in mining operations, enhancing safety and productivity.
500PB101 1MRB178009R0001 1MRB200064/C
Related Products
- AC500-ECO CPU 315: A compact PLC controller that pairs with the 500PB101 for small to medium-scale automation systems, offering basic control and communication capabilities.
- AC500-XC 320: A ruggedized PLC controller designed for extreme environments, compatible with the 500PB101 for applications in mining, oil & gas, and outdoor infrastructure.
- AC500-S Safety PLC: A safety-rated controller that works alongside the 500PB101 to provide fail-safe automation solutions in high-risk industries like chemicals and pharmaceuticals.
- AI810 Analog Input Module: An I/O module that interfaces with the 500PB101 to process analog signals from sensors and transmit data to the PLC controller.
- DI810 Digital Input Module: A digital I/O module that connects to the 500PB101 for monitoring and controlling discrete signals in industrial processes.
- DO810 Digital Output Module: A digital output module that pairs with the 500PB101 to drive actuators and relays in automation systems.
- CM810 Communication Module: A communication module that enables the 500PB101 to connect with other devices via protocols like Profibus, Ethernet/IP, or Modbus.
- PS501 Power Supply: A redundant power supply unit that complements the 500PB101 by providing backup power in critical applications.
Installation and Maintenance
Installation Preparation:
Before installing the 500PB101, verify the input voltage (24V DC) matches the power supply. Clean the DIN rail and ensure proper grounding to minimize electromagnetic interference. Align the module with the rail and secure it using the provided mounting clips. Connect the power cables to the terminal blocks, ensuring torque specifications (2.5 N·m) are met. Finally, link the module to adjacent I/O modules via the Modbus RTU interface (if enabled), following ABB’s wiring guidelines.Whatsapp:+86 18859254943.
Maintenance Recommendations:
- Routine Inspections: Regularly check for loose connections, blown fuses, or signs of overheating. Clean the module’s surface quarterly to prevent dust accumulation.
- Output Channel Testing: Periodically test each output channel using a multimeter to ensure voltage regulation and current capacity meet specifications.
- Firmware Updates: Download and install the latest firmware from ABB’s official website to address compatibility issues and enhance performance.
- Spare Parts Inventory: Maintain a stock of 500PB101 modules to replace faulty units promptly, especially for discontinued models or critical applications.
500PB101 1MRB178009R0001 1MRB200064/C
Product Warranty
We provide a 12-month quality warranty for the ABB 500PB101 1MRB178009R0001 1MRB200064/C power distribution module, covering hardware defects caused by non-human factors. During the warranty period, we will replace any malfunctioning module free of charge. For discontinued models or urgent requirements, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting continuous operation of industrial systems.
With 17 years of expertise in industrial control parts distribution, we guarantee competitive pricing, fast delivery, and reliable technical support. Contact us today to optimize your automation system with the 500PB101 power distribution module.
Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and installation guidelines.E-mail :sales@ygplc.com.
