TRICONEX 3664 Dual Digital Output Module
Product Overview
The TRICONEX 3664 is a high-reliability dual digital output module engineered for safety-critical industrial applications, particularly in Safety Instrumented Systems (SIS) and Emergency Shutdown (ESD) systems. As part of TRICONEX’s Trident series, this module leverages a 2oo3 (2-out-of-3) voting architecture to ensure fault tolerance and SIL 3 compliance, making it ideal for environments where system integrity is non-negotiable, such as oil refineries, chemical plants, and power generation facilities . Each of its two isolated output channels supports 2A of current, enabling direct control of high-power devices like solenoid valves, actuators, and motor starters, while maintaining precise signal integrity under extreme conditions .
Designed with hot-swappable capabilities, the TRICONEX 3664 allows for module replacement without system downtime, minimizing maintenance disruptions. Its compact form factor (120 mm x 80 mm x 60 mm) and lightweight construction (0.5 kg) facilitate easy integration into space-constrained control panels, while compliance with CE, UL, and SIL 3 certifications guarantees operation in hazardous and high-risk environments . The module’s advanced diagnostics continuously monitor channel health, detecting faults such as open circuits or voltage irregularities within milliseconds and triggering real-time alerts to prevent cascading failures .
By combining dual redundancy with TRICONEX’s proven Triple Modular Redundancy (TMR) technology, the 3664 achieves a Mean Time Between Failures (MTBF) exceeding 200,000 hours, ensuring long-term operational stability. Whether used in standalone safety loops or integrated into distributed control systems (DCS), this module delivers unparalleled performance, scalability, and ease of integration, making it a cornerstone of modern industrial automation .
Technical Specifications
| Parameter | Value |
|---|---|
| Manufacturer | TRICONEX |
| Product Type | Dual Digital Output Module (Safety-Critical I/O) |
| Channels | 2 isolated channels |
| Output Current | 2A per channel (nominal), 0.5–2A adjustable |
| Voltage Range | 24 VDC (nominal), 16–30 VDC operating range |
| Communication Protocols | Modbus TCP/IP, OPC UA, TRICON Proprietary Protocol |
| Physical Dimensions | 120 mm (W) x 80 mm (H) x 60 mm (D) |
| Weight | 0.5 kg |
| Working Temperature | -20°C to +60°C |
| Certifications | SIL 3 (IEC 61508), CE, UL |
| Redundancy | 2oo3 Voting Mechanism + Dual Redundant Circuits |
| Hot-Swap Capability | Yes |
3664
Related Products
- TRICONEX 3624: A 16-channel digital output module with optical isolation, suitable for non-hazardous environments.
- TRICONEX 3636R: A 32-channel relay output module with dry contact capability for high-power applications.
- TRICONEX 3625: A 16-channel digital output module with commoned supervision, designed for cost-sensitive projects.
- TRICONEX 3703E: An isolated analog input module for hybrid control systems requiring both analog and digital I/O.
- TRICONEX 4200 RMX: A fiber optic remote I/O module for extending the 3664’s reach in distributed installations.
- TRICONEX 3664X: An upgraded version with enhanced diagnostic features and faster response times.
Main Features and Advantages
Safety-Critical Redundancy: The TRICONEX 3664 employs a 2oo3 voting mechanism, where three independent processing channels continuously validate output signals. If one channel fails, the module automatically switches to a dual-channel configuration, ensuring uninterrupted operation. This architecture is certified for SIL 3 applications, meeting the strictest safety standards in industries like nuclear power and offshore drilling .
High-Power Output Capability: With 2A per channel, the module directly drives high-power devices without external amplifiers, reducing system complexity and costs. Its dual redundant output circuits further enhance reliability by providing backup paths for critical control signals .
Real-Time Diagnostics: Built-in self-testing monitors each channel for faults, including short circuits, open circuits, and voltage deviations. Faults are reported via status LEDs and integrated system diagnostics, enabling proactive maintenance and minimizing Mean Time to Repair (MTTR) .
Flexible Integration: The 3664 supports industry-standard communication protocols like Modbus TCP/IP and OPC UA, allowing seamless integration with existing DCS, SCADA, and HMIs. Its compatibility with TRICONEX’s TRICON CX platform ensures unified control and monitoring across distributed systems .
Hazardous Environment Compliance: Rated for operation in temperatures from -20°C to +60°C and humidity up to 95% non-condensing, the module is suitable for harsh industrial environments. Its CE and UL certifications further validate its robustness in challenging conditions .
3664
Installation and Maintenance
Pre-installation Preparations:
Before installing the TRICONEX 3664, verify the system’s power supply compatibility (24 VDC nominal) and ensure proper grounding. Clean the DIN rail and inspect the module for physical damage. Secure the module to the rail using a torque screwdriver set to 0.8–1.2 N·m. For redundant configurations, install two 3664 modules in adjacent slots and connect them via TRICONEX’s redundant communication cables .
Before installing the TRICONEX 3664, verify the system’s power supply compatibility (24 VDC nominal) and ensure proper grounding. Clean the DIN rail and inspect the module for physical damage. Secure the module to the rail using a torque screwdriver set to 0.8–1.2 N·m. For redundant configurations, install two 3664 modules in adjacent slots and connect them via TRICONEX’s redundant communication cables .
Maintenance Suggestions:
- Routine Checks: Perform monthly visual inspections to check for loose connections, damaged cables, or overheating. Use TRICONEX’s TriStation software to review diagnostic logs and identify potential issues.
- Firmware Updates: Regularly update the module’s firmware to access the latest security patches and performance optimizations.
- Spare Parts Management: Maintain a spare 3664 module to minimize downtime in case of failure. TRICONEX’s global supply chain ensures rapid delivery of discontinued or hard-to-find components.
- Environmental Monitoring: Ensure the operating temperature remains within -20°C to +60°C and humidity levels do not exceed 95% non-condensing .
Application Fields
The TRICONEX 3664 excels in a wide range of safety-critical applications:
- Emergency Shutdown (ESD) Systems: Triggers rapid shutdowns in oil refineries and chemical plants to prevent explosions or leaks.
- Burner Management Systems (BMS): Controls burner ignition, flame monitoring, and fuel supply in power plants and industrial boilers.
- High-Integrity Pressure Protection Systems (HIPPS): Manages pressure levels in pipelines and storage tanks to avoid overpressure events.
- Turbomachinery Control: Regulates steam turbines and gas generators in power plants, ensuring safe startup, operation, and shutdown.
- Process Automation: Manages valves, pumps, and alarms in pharmaceutical manufacturing and food processing, where precision and safety are paramount.
In each scenario, the 3664’s redundancy, diagnostics, and high-power capabilities mitigate risks, reduce operational costs, and ensure compliance with international safety standards .
3664
Product Guarantee
Our company, a leading industrial control parts distributor with 17 years of experience, offers a 1-year quality warranty for the TRICONEX 3664, covering hardware malfunctions unrelated to misuse or improper installation. During the warranty period, we provide free replacement for modules exhibiting performance irregularities or functional failures. For urgent or discontinued models, our global supply chain network ensures rapid delivery of scarce spare parts, supported by 24/7 technical assistance. We stand behind the 3664’s reliability and are committed to ensuring seamless integration and long-term system stability for our clients.
For inquiries, contact us via WhatsApp (+86 18859254943) or email (sales@ygplc.com).
