TRICONEX 2000361-001 Product Specification
Product Overview
The TRICONEX 2000361-001 is a high-reliability power distribution module designed for TRICONEX’s Triple Modular Redundant (TMR) safety instrumented systems (SIS). It serves as a critical component in distributing stable DC power from redundant power supplies to other modules within the TMR system, such as digital input/output modules, communication modules, and main processors. This ensures that every part of the system receives consistent power, which is essential for maintaining safety and operational integrity in critical industrial processes.
The TRICONEX 2000361-001 operates on a TMR architecture, with three independent power distribution paths that work in parallel. If one path fails, the other two continue to supply power, preventing any disruption to connected modules. This redundancy is vital for industries like oil refineries and chemical plants, where a power distribution failure could disable emergency shutdown systems. As part of TRICONEX’s TMR platform, the TRICONEX 2000361-001 integrates seamlessly with power supply modules like the TRICONEX 3700A and main processor modules such as the TRICONEX 3008, connecting via the system backplane to ensure synchronized power delivery.
Built to withstand harsh industrial environments, the TRICONEX 2000361-001 operates in temperatures from -40°C to +70°C and handles humidity between 5% and 95% (non-condensing). Its compact design (230 mm × 155 mm × 85 mm) and lightweight structure (1.3 kg) make it easy to install in standard control cabinets. Whether in nuclear power plants, pharmaceutical facilities, or mining operations, the TRICONEX 2000361-001 delivers reliable power distribution to keep TMR systems running without interruption.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | TRICONEX 2000361-001 |
| Manufacturer | TRICONEX |
| Product Type | TMR Power Distribution Module |
| Compatible Systems | TRICONEX Triple Modular Redundant (TMR) Safety Instrumented Systems (SIS) |
| Input Voltage | 24 VDC (from redundant power supplies like TRICONEX 3700A) |
| Output Voltage | 24 VDC (distributed to connected modules) |
| Physical Dimensions | 230 mm (L) × 155 mm (W) × 85 mm (H) [9.06″ × 6.10″ × 3.35″] |
| Weight | 1.3 kg (2.87 lb) |
| Operating Temperature | -40°C to +70°C |
| Humidity | 5–95% non-condensing, no frost |
| Redundancy | Triple modular redundant (3 independent power paths) |
| Protection Features | Overcurrent protection, short-circuit protection, reverse polarity protection |
| Certifications | CE, UL 508, IEC 61508 (SIL 3 compliant) |
2000361-001
Related Products
- TRICONEX 3700A: A redundant power supply module that provides 24 VDC input to the TRICONEX 2000361-001 for distribution to other system components.
- TRICONEX 3008: A TMR main processor module that receives power from the TRICONEX 2000361-001, executing safety logic in critical processes.
- TRICONEX 3721: A digital input module powered by the TRICONEX 2000361-001, monitoring emergency stop buttons and safety interlocks.
- TRICONEX 8111: A communication module that relies on power distributed by the TRICONEX 2000361-001 to exchange data with external systems.
- TRICONEX 4351B: An analog output module that receives 24 VDC from the TRICONEX 2000361-001 to control valves in chemical processing lines.
- TRICONEX 2201: A communication baseplate that works with the TRICONEX 2000361-001 to ensure power reaches communication modules in the same rack.
Main Features and Advantages
Triple power paths: The TRICONEX 2000361-001 uses three independent power distribution paths. Each path delivers power to connected modules. If one path fails, the other two continue working. No module loses power, and the system remains operational. This is critical in nuclear power plants, where a power loss to a safety module could compromise reactor control.
Stable power delivery: The TRICONEX 2000361-001 regulates 24 VDC input to ensure consistent output. It minimizes voltage fluctuations, protecting sensitive components like TMR processors from damage. Stable power reduces the risk of data corruption or module malfunctions in high-precision systems.
Robust protection: Built-in safeguards shield the TRICONEX 2000361-001 and connected modules. Overcurrent protection triggers if a module draws too much power; short-circuit protection shuts down paths during faults. Reverse polarity protection prevents damage from incorrect wiring, a common issue during maintenance in busy industrial settings.
SIL 3 compliance: Designed to meet IEC 61508 SIL 3 standards, the TRICONEX 2000361-001 ensures power distribution meets the highest safety requirements. It minimizes the risk of power-related failures in safety-critical applications, such as emergency shutdown systems in oil refineries.
Easy integration: The TRICONEX 2000361-001 fits directly into TRICONEX TMR racks, connecting to the system backplane without extra wiring. Its compact size (230 mm × 155 mm × 85 mm) saves space in crowded control cabinets, while its standardized design simplifies retrofits in existing systems.
