TeIKOOR CPCIAC-6U-500 900-7002-10 CompactPCI Power Supply Module
Product Overview：TeIKOOR CPCIAC-6U-500 900-7002-10
The TeIKOOR CPCIAC-6U-500 900-7002-10 is a high-reliability CompactPCI (CPCI) Power Supply Module designed for mission-critical industrial automation, telecommunications, and defense systems. As part of TeIKOOR’s ruggedized CPCI Power Series, this module delivers robust power management for 6U CompactPCI systems, ensuring stable operation in harsh environments. Engineered to meet the PICMG 2.11 standard for hot-swappable power supplies, the CPCIAC-6U-500 900-7002-10 provides 500W of regulated power with advanced features like redundancy support and real-time health monitoring, making it indispensable for applications requiring 24/7 uptime.
Featuring a modular design, the TeIKOOR CPCIAC-6U-500 900-7002-10 integrates the latest digital power control technology to deliver precise voltage regulation (±1% tolerance) for +3.3V, +5V, and ±12V rails. Its wide input voltage range (90–264V AC) accommodates global power sources, while active power factor correction (PFC) ensures compliance with energy efficiency standards. The module’s intelligent thermal management system, including variable-speed fans and temperature sensors, minimizes noise and prevents overheating, even in densely packed CPCI chassis.
In automation ecosystems, the CPCIAC-6U-500 900-7002-10 serves as the backbone of reliable power distribution, supporting redundant configurations to eliminate single points of failure. Its compatibility with TeIKOOR’s CPCI backplanes and I/O modules enables seamless integration into industrial control systems, communication networks, and military-grade platforms. By combining high power density with rugged construction, this module ensures continuous operation in extreme conditions, reducing maintenance costs and enhancing system reliability.
Technical Specifications：TeIKOOR CPCIAC-6U-500 900-7002-10
| Parameter Name | Parameter Value |
|---|---|
| Product Model | CPCIAC-6U-500 900-7002-10 |
| Manufacturer | TeIKOOR |
| Product Type | CompactPCI Power Supply Module |
| Form Factor | 6U CompactPCI (233.35 mm × 160 mm × 80 mm) |
| Weight | 3.2 kg |
| Input Voltage | 90–264V AC (47–63 Hz), 120–370V DC |
| Output Power | 500W (combined +3.3V, +5V, ±12V rails) |
| Efficiency | Up to 92% at full load |
| Redundancy | N+1 hot-swappable redundancy support |
| Communication | I2C interface for status monitoring |
| Operating Temperature | 0°C to +55°C (with derating up to +70°C) |
| Certifications | CE, FCC Class A, RoHS, PICMG 2.11 compliant |
| Mounting | Front-mounted in 6U CPCI chassis |
TeIKOOR CPCIAC-6U-500 900-7002-10
Key Features and Advantages：TeIKOOR CPCIAC-6U-500 900-7002-10
High-Power Redundancy: The CPCIAC-6U-500 900-7002-10 supports N+1 redundancy, allowing multiple power supplies to operate in parallel for enhanced system reliability. In the event of a failure, the remaining modules seamlessly take over, ensuring uninterrupted power delivery without downtime.
Intelligent Thermal Design: Built-in temperature sensors and variable-speed fans adjust cooling based on load, optimizing noise levels and energy consumption. The module’s aluminum heatsink and conformal coating protect against dust, moisture, and vibration, making it suitable for harsh industrial environments.
Hot-Swappable Design: Compliant with PICMG 2.11, the module can be inserted or removed from a live system without disrupting operation, simplifying maintenance and upgrades. This feature is critical for applications requiring minimal downtime, such as telecommunications switches or industrial control systems.
Comprehensive Diagnostics: Real-time monitoring via I2C interface provides detailed status information, including voltage/current levels, temperature, and fan speed. Alarms for overvoltage, overcurrent, and overtemperature conditions are transmitted to the system manager, enabling proactive fault resolution.
Global Power Compatibility: With a wide input voltage range and universal AC/DC compatibility, the TeIKOOR CPCIAC-6U-500 900-7002-10 eliminates the need for region-specific power supplies, reducing inventory complexity for multinational deployments.
TeIKOOR CPCIAC-6U-500 900-7002-10
Application Areas：TeIKOOR CPCIAC-6U-500 900-7002-10
The TeIKOOR CPCIAC-6U-500 900-7002-10 is ideally suited for industries demanding high-reliability power solutions:
- Industrial Automation: Powers CPCI-based PLCs, motion controllers, and distributed control systems (DCS) in manufacturing plants, ensuring stable operation of robotics, conveyor systems, and process control equipment.
- Telecommunications: Supports redundant power systems in network infrastructure, including routers, switches, and server farms, where uninterrupted connectivity is critical.
- Defense and Aerospace: Used in military-grade CPCI systems for radar stations, avionics, and ruggedized computing platforms, meeting stringent environmental and reliability standards.
- Energy and Utilities: Manages power distribution in smart grids, renewable energy control systems, and oil & gas monitoring applications, where harsh conditions and long operational lifespans are required.
Specific applications include:
- Redundant Power Systems: Deployed in pairs or clusters to support mission-critical applications like air traffic control systems or medical imaging equipment.
- Edge Computing Nodes: Provides reliable power for CPCI-based edge servers in remote locations, ensuring data processing and communication in IoT networks.
- Test and Measurement Systems: Powers CPCI-based instrumentation racks in semiconductor testing and aerospace validation labs, where precision and stability are non-negotiable.
Related Products：TeIKOOR CPCIAC-6U-500 900-7002-10
- CPCIAC-6U-300 900-7002-05: A 300W variant of the CPCIAC-6U-500 900-7002-10, suitable for smaller CPCI systems with lower power requirements.
- CPCIAC-6U-750 900-7002-15: A high-power version offering 750W, designed for advanced computing or graphics-intensive applications.
- CPCI-BP-6U-14: TeIKOOR’s 14-slot 6U CPCI backplane, compatible with the CPCIAC-6U-500 900-7002-10 for complete system integration.
- CPCIAC-RM-1U: Redundancy manager module that coordinates multiple CPCIAC-6U-500 900-7002-10 units, enhancing system-level fault tolerance.
- CPCIAC-6U-500-HS: A high-efficiency variant with extended temperature range (-20°C to +85°C), ideal for extreme environmental applications.
- CPCI-PSU-MON: A remote power monitoring module that interfaces with the CPCIAC-6U-500 900-7002-10 via I2C for centralized diagnostics.
- CPCI-CBL-6U-PWR: Dedicated power cables for secure connection between the CPCIAC-6U-500 900-7002-10 and backplane, ensuring low impedance and high reliability.
TeIKOOR CPCIAC-6U-500 900-7002-10
Installation and Maintenance：TeIKOOR CPCIAC-6U-500 900-7002-10
Installation Preparation:
Before installing the TeIKOOR CPCIAC-6U-500 900-7002-10, ensure the CPCI chassis is grounded and the backplane supports PICMG 2.11 power specifications. Verify the input voltage matches the module’s rating and that the chassis has adequate airflow for cooling. Slide the module into the designated slot until the front panel aligns with the chassis, then secure it with the provided screws. Connect the input power cable and I2C communication cable (if used) to complete the installation.
Before installing the TeIKOOR CPCIAC-6U-500 900-7002-10, ensure the CPCI chassis is grounded and the backplane supports PICMG 2.11 power specifications. Verify the input voltage matches the module’s rating and that the chassis has adequate airflow for cooling. Slide the module into the designated slot until the front panel aligns with the chassis, then secure it with the provided screws. Connect the input power cable and I2C communication cable (if used) to complete the installation.
Maintenance Recommendations:
- Routine Checks: Perform quarterly inspections to clean dust from the fan filters and verify LED status indicators. Use a soft brush or compressed air to remove debris from the module’s vents.
- Redundancy Testing: Annually simulate a power supply failure to ensure the redundant configuration switches seamlessly. Document test results to validate system reliability.
- Firmware Updates: Periodically update the module’s firmware via the I2C interface to access new features or bug fixes, following TeIKOOR’s official guidelines.
- Spare Parts Storage: Keep spare CPCIAC-6U-500 900-7002-10 modules in anti-static packaging at room temperature (20–25°C) with low humidity to preserve component integrity.
TeIKOOR CPCIAC-6U-500 900-7002-10
Product Warranty：TeIKOOR CPCIAC-6U-500 900-7002-10
Our company provides a 12-month quality warranty for the TeIKOOR CPCIAC-6U-500 900-7002-10, covering hardware defects under normal use. In the event of unexpected failures, we offer prompt replacement services to minimize downtime. For legacy or hard-to-find models, our global supply chain network specializes in sourcing rare industrial components, ensuring quick delivery for urgent needs. Our technical support team is available 24/7 to assist with installation, configuration, and troubleshooting, delivering tailored solutions to keep your systems operating at peak performance.
For sales inquiries, contact us via WhatsApp at +86 18859254943 or email at sales@ygplc.com.
