RELIANCE VZ3000G UVZC3455G Vibration Monitoring Module
Product Overview: RELIANCE VZ3000G UVZC3455G
The RELIANCE VZ3000G UVZC3455G is a high-precision vibration monitoring module designed to deliver advanced machinery health diagnostics for industrial automation systems. As a key component of Reliance’s VZ3000G Series, this module specializes in real-time vibration analysis, enabling predictive maintenance and early fault detection in rotating equipment such as turbines, compressors, and motors. The VZ3000G UVZC3455G integrates cutting-edge sensor technology with robust hardware to provide accurate measurements of vibration amplitude, frequency, and phase, ensuring optimal performance and reliability in mission-critical applications.
Engineered for industrial harshness, the VZ3000G UVZC3455G features a rugged IP67-rated enclosure that withstands dust, moisture, and mechanical shock. It supports multiple input types, including accelerometers and proximity probes, and offers configurable alarm thresholds to alert operators of abnormal vibration patterns. The module’s Modbus RTU/TCP communication interface enables seamless integration with PLCs, DCS systems, and SCADA platforms, allowing for centralized monitoring and data analytics. With a compact design and DIN rail mounting, the VZ3000G UVZC3455G simplifies installation in both new and retrofitted automation setups, making it an essential tool for industries prioritizing operational efficiency and equipment longevity.
In automation ecosystems, the VZ3000G UVZC3455G acts as a cornerstone of predictive maintenance strategies. By continuously monitoring machinery vibrations, it helps identify issues such as misalignment, bearing wear, or imbalance before they escalate into costly failures. Its high-resolution analog-to-digital conversion (16-bit ADC) and advanced signal processing algorithms ensure precise data acquisition, while its wide operating temperature range (-40°C to +85°C) guarantees reliability in extreme industrial environments.
RELIANCE VZ3000G UVZC3455G
Technical Specifications: RELIANCE VZ3000G UVZC3455G
| Parameter Name | Parameter Value |
|---|---|
| Product Model | VZ3000G UVZC3455G |
| Manufacturer | RELIANCE |
| Product Type | Vibration Monitoring Module |
| Input Channels | 2 analog inputs (accelerometer/proximity) |
| Measurement Range | 0–5000 mm/s² (vibration velocity) |
| Communication Protocol | Modbus RTU/TCP |
| Output Signals | 4–20 mA, 0–10 V DC, relay contacts |
| Physical Dimensions | 100 mm (H) × 80 mm (W) × 50 mm (D) |
| Weight | 0.6 kg |
| Operating Temperature | -40°C to +85°C |
| Humidity | 5–95% non-condensing |
| Protection Rating | IP67 |
| Mounting Type | DIN rail or panel-mounted |
| Country of Origin | United States |
- Power Generation: Monitors steam turbines, gas generators, and pumps in thermal and renewable energy plants. By detecting early signs of rotor imbalance or bearing degradation, it helps maintain uninterrupted power production.
- Oil and Gas: Deployed in offshore platforms and refineries to monitor compressors, motors, and rotating equipment in harsh, corrosive environments. Its IP67 rating ensures reliable operation in wet or dusty conditions.
- Manufacturing: Used in CNC machines, conveyor systems, and industrial robots to optimize performance and reduce unplanned downtime. The module’s spectral analysis aids in identifying mechanical issues that could affect product quality.
- Water Treatment: Installed in pumps and blowers to ensure consistent operation in wastewater treatment plants. Its ability to monitor vibration trends helps maintain compliance with environmental regulations.
- Aerospace and Defense: Supports condition monitoring of aircraft ground support equipment and military machinery, where precision and reliability are non-negotiable.
RELIANCE VZ3000G UVZC3455G
Related Products: RELIANCE VZ3000G UVZC3455G
- RELIANCE VZ3000G UVZC3456G: A multi-channel variant with 4 input channels, suitable for complex machinery requiring simultaneous monitoring of multiple vibration points.
- RELIANCE VZ3000G-EXT: An extended-temperature model (-55°C to +105°C) for extreme environmental applications, such as high-temperature furnaces or cryogenic systems.
- RELIANCE VZ3000G-WiFi: Features wireless connectivity (802.11b/g/n) for remote data access, ideal for hard-to-reach installations or retrofitted systems.
- RELIANCE VZ3000G-EX: A hazardous-area-certified version (ATEX/IECEx) for use in explosive atmospheres, common in chemical and petrochemical industries.
- RELIANCE VZ3000G-USB: Includes a USB interface for local data logging, suitable for standalone applications or temporary monitoring setups.
- RELIANCE VZ3000G-SENSOR KIT: A bundled solution with accelerometers and mounting brackets, providing a complete vibration monitoring package for quick deployment.
RELIANCE VZ3000G UVZC3455G
Installation and Maintenance: RELIANCE VZ3000G UVZC3455G
Pre-installation Preparations:
Before installing the VZ3000G UVZC3455G, verify the power supply (24V DC ±10%) and ensure the mounting surface is clean and free of debris. Use the provided DIN rail clips or panel-mounting brackets to secure the module in a control cabinet, leaving adequate space for ventilation. Connect the sensor cables to the designated input terminals, ensuring shielded wiring to minimize EMI interference. Configure the module’s communication address and baud rate using the built-in dip switches or software tool, and test connectivity with the host system.
Before installing the VZ3000G UVZC3455G, verify the power supply (24V DC ±10%) and ensure the mounting surface is clean and free of debris. Use the provided DIN rail clips or panel-mounting brackets to secure the module in a control cabinet, leaving adequate space for ventilation. Connect the sensor cables to the designated input terminals, ensuring shielded wiring to minimize EMI interference. Configure the module’s communication address and baud rate using the built-in dip switches or software tool, and test connectivity with the host system.
Maintenance Recommendations:
- Routine Inspections: Monthly visual checks for loose connections, damaged cables, or signs of environmental ingress (e.g., dust accumulation). Clean the enclosure with a dry cloth to maintain IP67 integrity.
- Calibration: Annually calibrate the module using a certified vibration calibrator to ensure measurement accuracy. Reference the user manual for step-by-step procedures.
- Firmware Updates: Periodically update the module’s firmware via the Modbus interface to access new features or bug fixes, as provided by Reliance’s support resources.
- Spare Parts Management: Keep a spare VZ3000G UVZC3455G on hand for quick replacement in case of failure, leveraging our global supply chain for rapid delivery of discontinued or urgent components.
RELIANCE VZ3000G UVZC3455G
Product Guarantee: RELIANCE VZ3000G UVZC3455G
Our company provides a 12-month quality warranty for the RELIANCE VZ3000G UVZC3455G vibration monitoring module, covering non-human-induced hardware defects. During the warranty period, we will replace any module experiencing abnormal performance, such as inconsistent readings or communication failures, at no additional cost. For discontinued models or urgent repair needs, our extensive inventory and global logistics network ensure prompt fulfillment of spare parts, minimizing downtime and supporting continuous operation of your industrial systems.
With 17 years of expertise in industrial control distribution, we are committed to delivering reliable, high-quality solutions. The VZ3000G UVZC3455G exemplifies our dedication to helping customers optimize machinery health and operational efficiency. Contact us today for technical support, pricing, or to explore how this module can enhance your predictive maintenance strategy.
Note: All product names, logos, and brands are the property of their respective owners. This document is for informational purposes only and does not substitute for Reliance’s official technical documentation. Always refer to the manufacturer’s guidelines for detailed installation, operation, and safety instructions.
