ProSoft MVI56-MBP Modbus Master/Slave Communication Module for ControlLogix

Product Overview：ProSoft MVI56-MBP

The ProSoft MVI56-MBP is a high-performance Modbus Master/Slave Communication Module designed to enable seamless integration between Rockwell Automation’s ControlLogix platform and Modbus RTU/ASCII devices, making it a critical component in industrial automation ecosystems. As part of ProSoft’s MVI56 Series of communication gateways, this module bridges the gap between legacy Modbus equipment (e.g., sensors, drives, and PLCs) and modern Ethernet-based control systems, facilitating real-time data exchange and centralized monitoring. The MVI56-MBP supports both master and slave operations, allowing it to initiate communication with up to 31 Modbus slaves or respond to requests from a Modbus master, ensuring flexibility in diverse industrial setups.

Engineered for reliability, the ProSoft MVI56-MBP features a rugged design that complies with industrial standards for shock, vibration, and temperature tolerance. Its plug-and-play compatibility with ControlLogix 1756 I/O racks eliminates the need for custom programming, reducing integration time and minimizing errors. The module’s advanced diagnostics, accessible via Rockwell’s Studio 5000 software, provide real-time insights into communication health, packet statistics, and device status, enabling proactive maintenance and reducing downtime. Whether deployed in manufacturing plants, energy facilities, or water treatment systems, the MVI56-MBP enhances operational efficiency by enabling seamless interoperability between disparate systems.

In automation architectures, the ProSoft MVI56-MBP serves as a vital communication hub, translating ControlLogix tag data into Modbus registers and vice versa. Its dual-channel capability (RS-232/485) supports simultaneous communication on two independent networks, expanding system scalability. By consolidating Modbus devices into the ControlLogix ecosystem, this module streamlines data management, improves process visibility, and supports compliance with industry standards for remote monitoring and control.

Technical Specifications：ProSoft MVI56-MBP *

Parameter Name	Parameter Value
Product Model	MVI56-MBP
Manufacturer	ProSoft Technology
Product Type	Communication Module (Modbus RTU/ASCII Gateway)
Compatibility	Rockwell ControlLogix 1756 Series
Communication Protocols	Modbus RTU Master/Slave, Modbus ASCII Master/Slave
Physical Dimensions	100 mm (H) × 175 mm (W) × 30 mm (D)
Weight	0.45 kg
Input Voltage	24 V DC (±10%) from ControlLogix rack
Operating Temperature	-40°C to +70°C
Mounting	Directly installed in ControlLogix 1756 rack
Certifications	CE, UL, cUL, Class I Div 2 (hazardous locations)
Data Rate	Up to 115.2 kbps
Number of Devices	Supports up to 31 Modbus slaves per channel

MVI56-MBP

Key Features and Advantages：ProSoft MVI56-MBP

Dual-Mode Communication: The MVI56-MBP operates as both a Modbus master and slave, offering flexibility to either poll field devices for data or act as a slave responding to commands from a higher-level system. This dual functionality makes it suitable for the most complex industrial networks.

Seamless ControlLogix Integration: Designed specifically for Rockwell’s ControlLogix platform, the module integrates natively with Studio 5000, allowing users to configure communication parameters, map tags, and monitor diagnostics through a familiar interface. No additional software licenses are required, reducing total cost of ownership.

Rugged Industrial Design: Built to withstand harsh environments, the MVI56-MBP features a metal enclosure, conformal coating, and wide temperature range, ensuring reliable operation in factories, oil refineries, and outdoor installations. Its compliance with Class I Div 2 standards further extends its usability in hazardous areas.

Advanced Diagnostics: Real-time LED indicators and detailed fault logging provide instant feedback on communication status, baud rate, and error conditions. The module’s built-in web server (accessible via Ethernet) allows remote monitoring and configuration, enhancing troubleshooting efficiency.

Scalable Architecture: With support for up to 31 Modbus devices per channel and dual independent serial ports, the MVI56-MBP can handle large-scale deployments without compromising performance. Its modular design also allows easy expansion in ControlLogix racks alongside other I/O modules.

Protocol Flexibility: In addition to Modbus RTU and ASCII, the module supports custom protocols via ProSoft’s MVI56-EIP (EtherNet/IP) companion modules, enabling hybrid network setups and future-proofing against technological upgrades.

MVI56-MBP

Application Areas：ProSoft MVI56-MBP

The ProSoft MVI56-MBP is widely applied in industries requiring integration of Modbus-compatible devices into modern automation systems:

Manufacturing: Connects legacy CNC machines, robotics, and conveyor systems to ControlLogix PLCs, enabling real-time production data monitoring and predictive maintenance.
Energy and Utilities: Facilitates communication between Modbus-based power meters, variable frequency drives (VFDs), and control systems in solar farms, wind turbines, and smart grid applications.
Oil and Gas: Used in upstream and downstream operations to integrate flow meters, pressure sensors, and safety systems with ControlLogix-based distributed control systems (DCS), ensuring compliance with safety standards.
Water/Wastewater Treatment: Links Modbus-enabled pumps, valves, and analyzers to central control systems, optimizing process efficiency and regulatory reporting.

Specific use cases include:

Retrofit Projects: Upgrades legacy Modbus systems to modern ControlLogix platforms without replacing field devices, saving costs and downtime.
Multi-Vendor Environments: Bridges communication gaps between Rockwell and non-Rockwell equipment (e.g., Schneider, Siemens), creating unified control ecosystems.
Remote Monitoring: Enables secure data transmission from remote sites to central control rooms via Modbus-to-Ethernet gateways, supporting remote diagnostics and asset management.
MVI56-MBP

Installation and Maintenance：ProSoft MVI56-MBP

Installation Preparation:
Before installing the ProSoft MVI56-MBP, ensure the ControlLogix rack is properly grounded and powered. Verify compatibility with the existing ControlLogix CPU firmware (v20 or later). Mount the module in an empty 1756 rack slot, securing it with the provided screws. Use Rockwell’s Studio 5000 to detect the module and configure communication parameters (e.g., baud rate, parity, Modbus device addresses). Connect the serial cable to the field device, ensuring correct wiring for RS-232 or RS-485 communication.

Maintenance Recommendations:

Routine Checks: Inspect the module monthly for loose connections or abnormal LED indicators. Use Studio 5000 to review communication error logs and ensure data transmission accuracy.
Firmware Updates: Periodically update the module’s firmware via ProSoft’s MVI56-CFM or Studio 5000 to access new features and security patches, following ProSoft’s official guidelines.
Environmental Maintenance: Clean the module’s ventilation slots annually to prevent dust accumulation, especially in high-dust environments. Ensure the rack’s cooling system operates efficiently to maintain optimal operating temperatures.
Spare Parts Management: Keep a spare MVI56-MBP on hand for critical applications. Store it in a static-free bag at room temperature to preserve component integrity.
MVI56-MBP

Product Warranty：ProSoft MVI56-MBP

Our company provides a 12-month quality warranty for the ProSoft MVI56-MBP, covering hardware defects under normal use. In the event of performance issues, we offer prompt replacement services to minimize downtime. For discontinued or hard-to-find models, our global supply chain network specializes in sourcing rare industrial control components, ensuring quick fulfillment of urgent orders. Our technical support team is available 24/7 to assist with installation, configuration, and troubleshooting, delivering tailored solutions to keep your automation systems running smoothly.
