ABB PP865 3BSE042236R1 | Processor / CPU module

Description

Product Overview
The ABB PP865 3BSE042236R1 is a robust processor module engineered for the ABB AC 800M family, delivering dependable control and deterministic performance for large-scale distributed control systems. As the processing heart of many process automation architectures, the ABB PP865 3BSE042236R1 executes control logic, coordinates I/O, and manages network communications with low latency. This module is designed for continuous industrial operation and supports typical industrial demands such as high availability, predictable scan times, and secure communications. Operators seeking a field-proven CPU module for retrofit, spares stocking, or system expansion commonly select the ABB PP865 3BSE042236R1 because of its balance of processing power, memory, and protocol flexibility.

Beyond raw compute, the ABB PP865 3BSE042236R1 emphasizes maintainability and lifecycle value. It interoperates smoothly with ABB engineering suites and field I/O, which reduces integration friction during upgrades or replacements. For plant managers focused on uptime, the ABB PP865 3BSE042236R1 supports redundant topologies and provides predictable behavior under fault conditions. For search visibility, use phrases like “ABB PP865 3BSE042236R1 datasheet,” “ABB PP865 AC800M CPU,” and “PP865 replacement module” — these capture the intent of engineers and procurement teams looking specifically for this module.

Technical Specifications

Parameter	Value
Model	ABB PP865 3BSE042236R1
Product Type	Processor / CPU module for AC 800M controller series
Processor	Embedded high-performance RISC CPU
Clock Speed	300 MHz (typical industrial class)
Memory	128 MB RAM, 32 MB Flash (non-volatile program storage)
I/O Expansion	2 × CEX / expansion buses for communication and I/O modules
Communication Ports	2 × Ethernet 10/100 Mbps, 1 × RS-232 serial console
Supported Protocols	TCP/IP, Modbus TCP, OPC, PROFIBUS (via interface module), IEC standards as applicable
Redundancy	Supports CPU redundancy and hot-swap in redundant racks
Power Supply	24 V DC nominal (supports redundant supply configuration)
Power Consumption	Typical 6 W; nominal operational range depends on attached modules
Operating Temperature	0 °C to +55 °C
Storage Temperature	−40 °C to +70 °C
Humidity	5%–95% non-condensing
Mounting	DIN-rail or modular rack / carrier mounting compatible with AC 800M frames
Dimensions (H×W×D)	Approx. 185 × 59 × 127 mm (industry standard footprint)
Weight	Approx. 0.5 kg
Certifications	CE, RoHS, UL (as applicable)
Country of Origin	Sweden / ABB manufacturing network

PP865 3BSE042236R1

Key Features and Benefits
The ABB PP865 3BSE042236R1 combines practical durability with integration flexibility, which makes it ideal for control rooms and distributed automation hubs. Its processing core supports tight control loops and complex logic, delivering predictable cycle times that control engineers rely on. Memory headroom allows larger application programs and richer diagnostics without compromising runtime stability.

Network versatility is a strong point. The ABB PP865 3BSE042236R1 offers dual Ethernet ports for segregated control and supervision networks, simplifying secure architecture design. Protocol support lets the module bridge legacy fieldbus systems and modern TCP/IP-based SCADA layers. In retrofit projects, the ABB PP865 3BSE042236R1 serves as a drop-in upgrade candidate where CPU horsepower and additional memory are required without reworking the entire I/O estate.

Operational continuity is addressed through redundancy and serviceability. The CPU supports redundant configurations so the control application stays online during planned swaps or unexpected hardware faults. Hot-swap capability, combined with clear diagnostics, minimizes mean time to repair (MTTR). Maintenance teams appreciate that the ABB PP865 3BSE042236R1 reports health data and fault codes that feed CMMS and predictive maintenance workflows.

From a procurement and stocking perspective, spare parts such as ABB PP865 3BSE042236R1 are critical to minimize downtime risk. The module’s long production lifecycle and backward compatibility with AC 800M ecosystems make it a practical inventory choice. For SEO visibility, include search terms like “buy ABB PP865,” “ABB PP865 spare part,” and “PP865 manual download” on relevant product pages and support portals to attract procurement searches.

PP865 3BSE042236R1
