Name: PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24 | Isolated Power Supply Module | SUNSHINE XIHE
Brand: 其他
Price: 2128.00 USD
Availability: InStock

Description

PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24 Isolated Power Supply Module

Product Overview：PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

The PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24 isolated power supply module is a high-reliability industrial component engineered to deliver stable, noise-free power in demanding automation and control environments. As part of Pioneer Magnetics’ PM3398 Series, this module combines advanced magnetic isolation technology with rugged construction, making it a critical asset for systems requiring galvanic isolation and precise voltage regulation.

Designed to convert unregulated input power into clean, isolated DC outputs, the PM3398B-6-1-3-E 80026-172-24 supports a wide input voltage range (9–36 VDC) and provides multiple isolated output channels (6 VDC, 12 VDC, 24 VDC) with a total power rating of 150 W. Its core function is to eliminate ground loops, reduce electromagnetic interference (EMI), and protect sensitive electronic components from voltage fluctuations. The module’s compact form factor (120 mm x 60 mm x 35 mm) and DIN rail mounting capability enable easy integration into industrial control panels, while its -40°C to +85°C operating temperature range ensures consistent performance in harsh industrial settings.

In automation systems, the PM3398B-6-1-3-E 80026-172-24 serves as a foundational power management solution, supporting critical components such as PLCs, DCS modules, sensors, and communication gateways. By providing isolated power to different sub-systems, it enhances system stability and reduces the risk of data corruption or hardware damage caused by electrical noise. This module is particularly valuable in mission-critical applications where uninterrupted power supply and high electromagnetic compatibility (EMC) are essential for operational integrity.

Technical Specifications：PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

Parameter Name	Parameter Value
Product Model	PM3398B-6-1-3-E 80026-172-24
Manufacturer	PIONEER MAGNETICS
Product Type	Isolated Power Supply Module
Input Voltage Range	9–36 VDC
Output Voltage Channels	6 VDC (3 A), 12 VDC (5 A), 24 VDC (2.5 A)
Total Power Rating	150 W
Isolation Voltage	2.5 kV DC (input-output)
Efficiency	Up to 92%
Physical Dimensions	120 mm x 60 mm x 35 mm
Weight	0.35 kg
Mounting Type	DIN rail or panel mount
Operating Temperature	-40°C to +85°C
Humidity	5–95% non-condensing
Country of Origin	United States

PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

Key Features and Advantages：PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

Galvanic Isolation Excellence: The PM3398B-6-1-3-E 80026-172-24 features a 2.5 kV DC isolation barrier, effectively separating input and output circuits to eliminate ground loops and common-mode noise. This is critical for protecting sensitive control systems from voltage surges and ensuring accurate signal transmission in industrial environments prone to electrical interference.

Wide Input/Output Flexibility: With a 9–36 VDC input range and configurable output channels, the module adapts to diverse power supply scenarios. It supports both regulated and unregulated inputs, making it suitable for applications with fluctuating power sources, such as those powered by batteries, generators, or renewable energy systems.

High Efficiency and Low Noise: The module’s advanced switching topology achieves up to 92% energy efficiency, reducing power loss and heat generation. Its built-in EMI filters comply with international standards (CE, FCC Part 15), minimizing electromagnetic radiation and ensuring compatibility with noise-sensitive equipment like sensors and communication modules.

Rugged Industrial Design: Built with military-grade components and a reinforced aluminum casing, the PM3398B-6-1-3-E 80026-172-24 withstands vibration, shock, and extreme temperatures. Its IP20 protection rating safeguards against dust and accidental contact, while the DIN rail mounting design simplifies installation in space-constrained control cabinets.

Redundant Output Protection: Integrated over-voltage, over-current, and short-circuit protection mechanisms ensure safe operation under fault conditions. The module’s self-resetting fault protection reduces downtime by automatically recovering from transient errors without manual intervention.

PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

Application Areas：PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

The PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24 isolated power supply module excels in industries where clean, reliable power is non-negotiable:

Industrial Automation: Powers PLCs, HMIs, and motor drives in smart factories, ensuring stable operation of robotic arms, conveyor systems, and CNC machines. Its isolation features protect control networks from noise generated by high-power motors or welding equipment.
Energy and Utilities: Used in wind turbines, solar inverters, and substation automation to isolate control circuits from grid disturbances. Supports remote monitoring systems in power plants, where signal integrity is critical for real-time data transmission.
Medical Equipment: Provides isolated power for diagnostic devices (e.g., MRI machines, patient monitors), minimizing the risk of electrical shock and ensuring compliance with medical safety standards (IEC 60601).
Transportation: Installed in railway signaling systems, electric vehicles, and avionics to withstand voltage fluctuations and harsh environmental conditions, such as those encountered in locomotive or aerospace applications.
Telecommunications: Powers network routers, switches, and base stations, ensuring stable connectivity in remote or rugged locations. Its compact size and high efficiency make it ideal for distributed antenna systems (DAS) and edge computing nodes.

Related Products：PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

PM3398A-12-2-5-E 80026-171-23: A single-channel variant of the PM3398B-6-1-3-E 80026-172-24, offering 12 VDC output for simpler automation setups. Suitable for applications requiring basic isolation without multiple voltage channels.
PM3398C-24-4-2-E 80026-173-25: A high-power version with a 240 W rating, designed for heavy-duty industrial machinery and large control panels. Features enhanced thermal management for high-temperature environments.
PM3398D-5-3-1-E 80026-170-22: A low-voltage model optimized for 5 VDC output, ideal for powering microcontrollers, sensors, and low-power IoT devices in smart factory applications.
PM3398-ISOLATION-KIT: Including mounting brackets, EMI filters, and surge protectors, designed to enhance the installation and performance of the PM3398B-6-1-3-E 80026-172-24 in high-noise environments.
PM3398-TESTER: A diagnostic tool for verifying the module’s isolation integrity and output stability, recommended for maintenance teams to ensure ongoing performance compliance.
PM3398-EXT-CABLE: A customized interconnect cable for extending the module’s input/output connections, available in various lengths to accommodate complex control panel layouts.
PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

Installation and Maintenance：PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

Installation Preparation:
Before installing the PM3398B-6-1-3-E 80026-172-24, confirm the input voltage matches the module’s 9–36 VDC range and that the output channels are configured for the required voltages (6 VDC, 12 VDC, 24 VDC). Clean the DIN rail or mounting surface to remove debris, then secure the module using the provided clips or screws. Connect the input power cables to the terminal blocks (labeled “IN+” and “IN-”), ensuring proper polarity, and link the output cables to the respective load devices. For panel mounting, use the included brackets to attach the module to a flat surface, leaving adequate space for heat dissipation.

Maintenance Recommendations:

Routine Inspections: Monthly visual checks for loose connections, damaged cables, or signs of overheating (e.g., discolored casing). Use a multimeter to verify input/output voltages and ensure they remain within specified tolerances.
Thermal Management: Quarterly cleaning of ventilation slots to prevent dust accumulation, which can impede heat dissipation. In high-temperature environments, monitor the module’s surface temperature using an infrared thermometer to ensure it does not exceed 85°C.
Fault Resolution: In the event of a fault (e.g., output voltage drop), first disconnect the load to test for short circuits. If the issue persists, replace the module with a spare unit from your inventory, leveraging our rapid delivery service for urgent replacements.
Lifespan Optimization: Perform annual functional tests using the PM3398-TESTER to validate isolation voltage and efficiency. Replace the module after 10 years of operation or at the first sign of performance degradation, whichever comes first.
PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

Product Warranty：PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24

We provide a 12-month quality warranty for the PIONEER MAGNETICS PM3398B-6-1-3-E 80026-172-24 isolated power supply module, covering hardware defects caused by non-human factors. During the warranty period, if the module exhibits abnormal voltage output, excessive noise, or functional failure, we will promptly replace it at no charge. For discontinued models or urgent requirements, our global supply chain network—built over 17 years of industry expertise—ensures fast availability of even the rarest industrial control parts.

Our commitment extends beyond warranty: we offer 24/7 technical support to assist with installation, troubleshooting, and system integration, ensuring your automation infrastructure operates at peak efficiency. With a vast inventory of both current and legacy components, we specialize in solving supply chain challenges for critical spares, helping you minimize downtime and maintain production continuity. Trust in our proven track record to deliver the reliability and performance your industrial systems demand.

Note: All product names, logos, and brands are property of their respective owners. This document is for informational purposes only and does not constitute an official technical manual. Always refer to the manufacturer’s documentation for detailed specifications and safety guidelines.
