GE IS230TCISH6C Product Specification
Product Overview
The GE IS230TCISH6C is a high-performance discrete input/output (I/O) terminal board engineered for GE’s Mark VIe Speedtronic Turbine Control System, serving as a critical interface for real-time monitoring and control of industrial machinery. Designed to handle digital signals from switches, relays, and sensors, this module enables precise command execution and status feedback in gas turbines, steam turbines, and other mission-critical equipment across power generation, oil and gas, and heavy manufacturing.
As part of the Mark VIe distributed control architecture, the GE IS230TCISH6C supports 16 channels for simultaneous monitoring and control of discrete signals, with a nominal voltage rating of 28 VDC and compatibility with hazardous location applications (Class I, Division 2) . Its dual redundant 100 Mbps Ethernet ports ensure seamless communication with the Mark VIe controller, while the hot-swappable design allows module replacement without system downtime. The module’s rugged construction—featuring a triple-layer conformal coating and IP20-rated enclosure—ensures reliable operation in harsh environments with high vibration, humidity, and temperature fluctuations (-35°C to +65°C) .
In automation systems, the GE IS230TCISH6C acts as the backbone for discrete control loops, providing critical data for turbine valve actuation, safety interlock monitoring, and alarm triggering. Its compatibility with IS200STCIS1A/2A and IS400STCIS1A/2A terminal boards allows deployment in explosive atmospheres, adhering to industry standards for safety and reliability .
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IS230TCISH6C |
| Manufacturer | General Electric (GE) |
| Product Type | Discrete Contact I/O Terminal Board |
| Series | Mark VIe Speedtronic Turbine Control System |
| Input/Output Channels | 16 channels (8 inputs + 8 outputs) |
| Nominal Voltage | 28 VDC ±5% |
| Max Voltage Rating | 32 VDC |
| Contact Rating | 0.5 A per channel |
| Response Time | <5 ms |
| Communication Interface | Dual 100 Mbps Ethernet ports (IONET protocol) |
| Physical Dimensions | 240 mm (H) × 250 mm (W) × 55 mm (D) |
| Weight | 1.5 kg |
| Operating Temperature | -35°C to +65°C |
| Humidity | 5–95% non-condensing |
| Power Supply | 28 VDC (internal redundant power input) |
| Certifications | CE, UL 61010-1, IEC 60950-1, Class I, Division 2 (hazardous location compliant) |
Main Features and Advantages
Dual-Redundant Communication:
The GE IS230TCISH6C integrates dual Ethernet ports to ensure uninterrupted data transmission to the Mark VIe controller, with automatic failover in <10 ms. This redundancy minimizes downtime risks in safety-critical systems, such as turbine emergency shutdowns triggered by 异常离散信号波动 .
The GE IS230TCISH6C integrates dual Ethernet ports to ensure uninterrupted data transmission to the Mark VIe controller, with automatic failover in <10 ms. This redundancy minimizes downtime risks in safety-critical systems, such as turbine emergency shutdowns triggered by 异常离散信号波动 .
Hazardous Location Compliance:
Rated for Class I, Division 2 environments, the module is suitable for use in explosive atmospheres common in oil refineries and chemical plants. When paired with IS200STCIS1A terminal boards, it provides intrinsic safety barriers, ensuring compliance with ATEX and IECEx standards .
Rated for Class I, Division 2 environments, the module is suitable for use in explosive atmospheres common in oil refineries and chemical plants. When paired with IS200STCIS1A terminal boards, it provides intrinsic safety barriers, ensuring compliance with ATEX and IECEx standards .
High-Speed Signal Processing:
With a response time of <5 ms, the GE IS230TCISH6C enables rapid actuation of turbine control valves and solenoids, critical for maintaining operational stability during transient conditions like load changes or grid disturbances .
With a response time of <5 ms, the GE IS230TCISH6C enables rapid actuation of turbine control valves and solenoids, critical for maintaining operational stability during transient conditions like load changes or grid disturbances .
Rugged Industrial Design:
A triple-layer conformal coating protects against dust, moisture, and chemical exposure, while the module’s vibration resistance (10–2000 Hz, 10 G rms) and wide operating temperature range make it suitable for offshore platforms, power plants, and other harsh industrial settings .
A triple-layer conformal coating protects against dust, moisture, and chemical exposure, while the module’s vibration resistance (10–2000 Hz, 10 G rms) and wide operating temperature range make it suitable for offshore platforms, power plants, and other harsh industrial settings .
Hot-Swappable Operation:
The GE IS230TCISH6C supports hot swapping, allowing replacement of a faulty unit without powering down the control system. This feature reduces mean time to repair (MTTR) to under 15 minutes, critical for maintaining uptime in mission-critical applications .
The GE IS230TCISH6C supports hot swapping, allowing replacement of a faulty unit without powering down the control system. This feature reduces mean time to repair (MTTR) to under 15 minutes, critical for maintaining uptime in mission-critical applications .
Application Areas
-
Power Generation:
- Controls turbine bypass valves to regulate steam flow during startup and shutdown.
- Monitors breaker status in generator protection systems to ensure grid synchronization.
-
Oil and Gas:
- Manages emergency shutdown (ESD) signals in offshore platforms to prevent hydrocarbon leaks.
- Controls compressor anti-surge valves to maintain optimal flow rates in pipeline systems.
-
Manufacturing:
- Automates conveyor belt movement in automotive assembly lines via proximity sensor inputs.
- Triggers alarms in chemical reactors based on pressure switch outputs.
-
Renewable Energy:
- Activates pitch control systems in wind turbines during high-wind conditions.
- Monitors solar panel tracker positions via limit switch inputs for optimal energy capture.
Related Products
- GE IS200STCIS1A: Terminal board compatible with IS230TCISH6C, providing signal conditioning and isolation for hazardous locations.
- GE IS220PDIOH1B: Discrete I/O module often paired with IS230TCISH6C for integrated turbine control and monitoring.
- GE IS220PPROS1B: Redundant power supply module that powers the IS230TCISH6C, ensuring stable operation in mission-critical systems.
- GE IS220VCMIH1A: Communication module ensuring seamless data transmission between IS230TCISH6C and the Mark VIe controller.
- GE IS220PAICH1A: Analog input module used alongside IS230TCISH6C to handle additional process variables like temperature and pressure.
- GE IS220PVIBH1A: Vibration monitoring module often deployed with IS230TCISH6C for comprehensive machinery health assessment.
Installation and Maintenance
Pre-installation Preparation:
Before installing the GE IS230TCISH6C, verify the input voltage matches the module’s requirements (28 VDC ±5%) and ensure the control cabinet is properly grounded to prevent electrostatic discharge (ESD). Use an ESD wrist strap during handling. Mount the module in a 3U VME rack with at least 50 mm clearance for airflow, securing it with anti-vibration brackets to minimize mechanical stress. Connect the IS200STCIS1A terminal board to the module, ensuring proper wiring for discrete inputs/outputs and Ethernet links to the Mark VIe controller .
Before installing the GE IS230TCISH6C, verify the input voltage matches the module’s requirements (28 VDC ±5%) and ensure the control cabinet is properly grounded to prevent electrostatic discharge (ESD). Use an ESD wrist strap during handling. Mount the module in a 3U VME rack with at least 50 mm clearance for airflow, securing it with anti-vibration brackets to minimize mechanical stress. Connect the IS200STCIS1A terminal board to the module, ensuring proper wiring for discrete inputs/outputs and Ethernet links to the Mark VIe controller .
Maintenance Recommendations:
Perform monthly visual inspections to confirm front-panel LEDs (Power, Ethernet Link, Fault) indicate normal operation. Clean dust from ventilation slots using compressed air to maintain cooling efficiency. Quarterly, use a multimeter to verify output voltage (28 VDC ±5%) and check terminal connections for corrosion. Annually, update firmware via GE’s Proficy software to access bug fixes and compatibility enhancements. Test redundancy by disconnecting one Ethernet port and confirming seamless switchover to the secondary channel .
Perform monthly visual inspections to confirm front-panel LEDs (Power, Ethernet Link, Fault) indicate normal operation. Clean dust from ventilation slots using compressed air to maintain cooling efficiency. Quarterly, use a multimeter to verify output voltage (28 VDC ±5%) and check terminal connections for corrosion. Annually, update firmware via GE’s Proficy software to access bug fixes and compatibility enhancements. Test redundancy by disconnecting one Ethernet port and confirming seamless switchover to the secondary channel .
Product Warranty
Our company offers a one-year quality warranty for the GE IS230TCISH6C, covering hardware malfunctions not caused by human factors. During the warranty period, if the module exhibits abnormal signal transmission, communication failures, or functional defects, we will provide replacement services. For discontinued models or urgent demands, our global supply chain network ensures rapid fulfillment of scarce spare parts, supporting the continuous operation of your industrial systems. As a leading import-export distributor with 17 years of experience, we maintain large inventories of industrial control parts, including hard-to-find models, to meet your urgent needs .
