ICS TRIPLEX T8110B Tricon Tri-Plex Redundant Controller Module
Product Overview：ICS TRIPLEX T8110B
The ICS TRIPLEX T8110B Tricon Tri-Plex Redundant Controller Module is a high-reliability safety instrumented system (SIS) component designed for critical industrial applications requiring fail-safe operation. As the core controller of ICS Triplex’s Tricon Series, this module employs a unique triple modular redundancy (TMR) architecture, integrating three independent processor channels into a single unit to deliver unparalleled fault tolerance and diagnostic coverage.
Engineered to meet IEC 61508 Safety Integrity Level 3 (SIL 3) and ISA 84.00.07 standards, the T8110B ensures continuous operation by voting on data from its three identical channels, eliminating single points of failure. It supports real-time data processing, advanced control algorithms, and seamless integration with I/O modules (e.g., T9401B analog input module), making it ideal for emergency shutdown systems (ESD), burner management systems (BMS), and critical process control in hazardous environments. The module’s hot-swappable design and -40°C to 70°C operating range further enhance its suitability for harsh industrial settings, such as offshore platforms and petrochemical plants.
In automation systems, the T8110B acts as the brain of a triple-redundant control network, providing deterministic control with sub-millisecond cycle times. Its Tricon Configuration Studio software enables intuitive programming in ladder logic, structured text, or function block diagram (FBD), while built-in diagnostics continuously monitor channel health, ensuring compliance with international safety standards. By combining high-speed processing with robust redundancy, the T8110B minimizes downtime, protects personnel, and safeguards assets in mission-critical operations.
Technical Specifications：ICS TRIPLEX T8110B
| Parameter Name | Parameter Value |
|---|---|
| Product Model | T8110B |
| Manufacturer | ICS TRIPLEX |
| Product Type | Tri-Plex Redundant Controller Module |
| Redundancy Architecture | Triple Modular Redundancy (TMR) |
| Safety Integrity Level | SIL 3 (IEC 61508) |
| Processor Type | Three 32-bit RISC processors |
| Memory | 256 MB Flash, 512 MB RAM |
| Communication Interfaces | Ethernet (10/100 Mbps), RS485, Serial |
| Physical Dimensions | 221 mm (H) × 133 mm (W) × 203 mm (D) |
| Weight | 3.2 kg |
| Operating Temperature | -40°C to 70°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | Rack-mounted (19-inch standard) |
| Country of Origin | United States |
T8110B
Key Features and Advantages：ICS TRIPLEX T8110B
Triple Modular Redundancy (TMR): The T8110B’s core architecture ensures fault tolerance by comparing outputs from three independent channels. If a single channel fails, the module continues operating with the majority vote, preventing unexpected shutdowns and ensuring continuous process control. This design meets the highest safety requirements for industries where system failure could lead to catastrophic consequences.
Hot-Swappable Design: The module can be replaced without powering down the system, minimizing downtime during maintenance or upgrades. This feature is critical for live industrial environments, allowing technicians to service the controller without interrupting operations.
Advanced Diagnostics and Compliance: Built-in self-diagnostics monitor each channel’s health, providing real-time status updates via LED indicators and diagnostic software. The T8110B complies with ATEX, IECEx, and CSA standards for use in explosive atmospheres, ensuring regulatory compliance in global markets.
Scalable and Flexible Integration: Compatible with ICS Triplex’s extensive range of I/O modules (e.g., T9200B digital input/output modules) and communication gateways (e.g., T9861B Ethernet interface), the T8110B supports scalable system designs. It integrates seamlessly with SCADA and DCS systems, enabling centralized monitoring and remote diagnostics.
High-Speed Processing: With a maximum scan time of 1 ms for typical applications, the T8110B delivers rapid response to process changes, making it suitable for high-speed control loops and safety-critical shutdowns.
T8110B
Application Areas：ICS TRIPLEX T8110B
The ICS TRIPLEX T8110B Tricon Tri-Plex Redundant Controller Module is indispensable in industries where safety, reliability, and continuous operation are non-negotiable:
- Oil and Gas: Deployed in offshore platforms, refineries, and pipeline systems for emergency shutdown systems (ESD), fire and gas detection (F&G), and compressor control. The T8110B’s TMR architecture ensures safe operation in explosive environments, meeting strict industry standards like API 553 and ISO 10418.
- Chemical and Petrochemical: Manages critical processes such as reactor control, distillation columns, and storage tank safety. Its ability to handle complex logic and redundant communication makes it suitable for managing hazardous chemical reactions and preventing leaks or explosions.
- Power Generation: Used in thermal, nuclear, and renewable energy plants for turbine control, boiler safety systems, and grid synchronization. The module’s high-speed processing supports real-time adjustments to power output and fault mitigation.
- Pharmaceuticals and Food Processing: Ensures compliance with GMP and HACCP standards by providing reliable control for sterile environments, batch processing, and safety interlocks. The T8110B’s hygienic design and low-maintenance features are ideal for sensitive production lines.
- Marine and Offshore: Installed in marine propulsion systems, shipboard safety systems, and offshore rigs, where its rugged construction and resistance to vibration and corrosion are essential.
Related Products：ICS TRIPLEX T8110B
- T8310 Tricon Power Supply Module: A redundant power supply sets with the T8110B, providing stable 24V DC power to the Tricon rack and ensuring uninterrupted operation during power fluctuations.
- T9401B Analog Input Module: An SIL 3-certified module that interfaces with the T8110B to process analog signals from sensors (e.g., temperature, pressure transmitters) in safety-critical loops.
- T9200B Digital Input/Output Module: Offers high-density digital I/O for connecting switches, valves, and actuators to the T8110B, supporting both discrete control and status monitoring.
- T9861B Ethernet Interface Module: Enables high-speed Ethernet communication between the T8110B and external systems (e.g., SCADA, HMIs), facilitating remote monitoring and data logging.
- T8403 Tricon Expansion Interface Module: Extends the T8110B’s I/O capacity by connecting additional racks, allowing system expansion without reconfiguring the core controller.
- T9300B High-Speed Counter Module: Supports high-frequency pulse counting for applications like turbine speed monitoring, integrating with the T8110B for precise rotational control.
- Tricon AX Controller (T8151): An upgraded version of the T8110B with enhanced processing power and advanced cybersecurity features, suitable for modern industrial IoT (IIoT) applications.
T8110B
Installation and Maintenance：ICS TRIPLEX T8110B
Installation Preparation:
Before installing the T8110B, ensure the Tricon rack is properly grounded and powered by a redundant supply (e.g., T8310 power module). Verify the rack’s environmental conditions (temperature, humidity) meet the module’s specifications. Align the T8110B with the rack’s guide rails, push it firmly into place, and secure it with the provided screws. Connect the power cables and communication links (Ethernet/RS485) according to the wiring diagram, ensuring all connections are tight to prevent signal loss.
Before installing the T8110B, ensure the Tricon rack is properly grounded and powered by a redundant supply (e.g., T8310 power module). Verify the rack’s environmental conditions (temperature, humidity) meet the module’s specifications. Align the T8110B with the rack’s guide rails, push it firmly into place, and secure it with the provided screws. Connect the power cables and communication links (Ethernet/RS485) according to the wiring diagram, ensuring all connections are tight to prevent signal loss.
Maintenance Recommendations:
- Routine Inspections: Monthly checks should include verifying LED status indicators (e.g., power, communication, fault lights) and ensuring no loose connections or physical damage. Clean the module’s ventilation slots quarterly to prevent dust accumulation that could cause overheating.
- Firmware Updates: Periodically update the T8110B’s firmware using ICS Triplex’s Tricon Configuration Studio to access new features, security patches, and compatibility improvements with other modules.
- Redundancy Testing: Conduct annual tests of the TMR architecture by simulating single-channel faults to ensure proper voting and failover functionality. Replace any faulty components immediately to maintain system integrity.
- Environmental Monitoring: Regularly inspect the installation environment for extreme temperatures, moisture, or vibrations that could affect module performance. Ensure the rack’s cooling system is operational to maintain optimal operating conditions.
T8110B
Product Warranty：ICS TRIPLEX T8110B
We provide a 12-month quality warranty for the ICS TRIPLEX T8110B module, covering hardware defects arising from non-human causes. During the warranty period, we will replace any defective module at no cost. For discontinued models or urgent needs, our global supply chain network ensures rapid delivery of scarce components, minimizing downtime and supporting the long-term reliability of your industrial systems.
With 17 years of expertise in industrial control distribution, we offer competitive pricing, extensive inventory of both current and legacy parts, and dedicated technical support to help you maintain optimal system performance. Contact us today to discuss how the T8110B can enhance the safety and efficiency of your critical processes.
Note: All product names, logos, and brands are the property of their respective owners. This document is for informational purposes only and does not substitute for official technical documentation. Always refer to ICS Triplex’s manuals for detailed installation and configuration guidelines.
