GE IC755CSS06RDA Product Specification
Product Overview
The GE IC755CSS06RDA is a 6-inch QuickPanel+ Industrial Operator Interface designed for GE’s PACSystems RX3i/RX7i platforms, serving as a versatile human-machine interface (HMI) for industrial automation systems. Engineered to deliver intuitive control and real-time monitoring, this touchscreen panel integrates seamlessly with PLCs, SCADA systems, and field devices, enabling operators to manage processes, visualize data, and execute commands in manufacturing, energy, and process industries.
As part of GE’s QuickPanel+ series, the GE IC755CSS06RDA features a 6-inch color TFT LCD touchscreen with resistive touch technology, supporting 65,536 colors and a resolution of 320×240 pixels. Its compact design (192 x 137 x 36 mm) and 1.54 lb weight allow flexible mounting—either via panel cutout or VESA mount—making it suitable for space-constrained environments like control rooms or mobile equipment. The panel runs on Windows Embedded Compact 7, providing a familiar interface for operators while supporting advanced software applications for data logging, trending, and alarm management.
Key connectivity features include 1x 10/100 Mbps Ethernet, 1x RS-232 serial port, and 3x USB ports (2x host, 1x device), enabling integration with PLCs (e.g., GE IC695CPE330), HMIs, printers, and barcode scanners. The 512 MB RAM and 256 MB flash memory ensure smooth multitasking and reliable data storage, while 512 KB battery-backed SRAM retains critical configurations during power outages. With 24 VDC power supply and a rugged IP20-rated enclosure, the GE IC755CSS06RDA operates reliably in temperatures ranging from 0°C to +60°C, making it suitable for harsh industrial settings.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC755CSS06RDA |
| Manufacturer | General Electric (GE) |
| Product Type | Industrial Operator Interface (HMI) |
| Series | QuickPanel+ |
| Display | 6-inch TFT LCD, resistive touch, 320×240 resolution, 65,536 colors |
| Processor | ARM Cortex-A8, 1 GHz |
| Memory | 512 MB RAM, 256 MB flash, 512 KB battery-backed SRAM |
| Communication Ports | 1x Ethernet (10/100 Mbps), 1x RS-232, 3x USB (2x host, 1x device) |
| Operating System | Windows Embedded Compact 7 |
| Physical Dimensions | 192 mm (W) × 137 mm (H) × 36 mm (D) |
| Weight | 1.54 lb (0.7 kg) |
| Power Supply | 24 VDC ±10%, 15 W max |
| Operating Temperature | 0°C to +60°C |
| Humidity | 5–95% non-condensing |
| Certifications | CE, UL 508 |
| Mounting Options | Panel cutout (183.5×128.5 mm) or VESA 75×75 mm |
| Environmental Resistance | Vibration: 10–2000 Hz, 10 G rms; Shock: 50 G (11 ms duration) |
Main Features and Advantages
Intuitive Touchscreen Interface:
The GE IC755CSS06RDA’s 6-inch resistive touchscreen offers precise, glove-friendly operation, ideal for industrial environments where operators wear protective gear. Its TFT display ensures high visibility even in bright sunlight or low-light conditions, with adjustable brightness (375 nits) and LED backlighting for energy efficiency. The Windows Embedded OS provides a familiar interface for running custom applications, such as recipe management in food processing or real-time analytics in power plants.
The GE IC755CSS06RDA’s 6-inch resistive touchscreen offers precise, glove-friendly operation, ideal for industrial environments where operators wear protective gear. Its TFT display ensures high visibility even in bright sunlight or low-light conditions, with adjustable brightness (375 nits) and LED backlighting for energy efficiency. The Windows Embedded OS provides a familiar interface for running custom applications, such as recipe management in food processing or real-time analytics in power plants.
Versatile Communication Capabilities:
With Ethernet, RS-232, and USB ports, the GE IC755CSS06RDA integrates seamlessly with diverse industrial systems. For example, it communicates with GE IC695CPE330 PLCs via Ethernet/IP for process control, connects to HMIs like GE IC693HMI301 for centralized monitoring, and interfaces with barcode scanners via USB for inventory tracking. Its support for Modbus RTU/TCP enables compatibility with third-party devices, making it a flexible choice for hybrid automation setups.
With Ethernet, RS-232, and USB ports, the GE IC755CSS06RDA integrates seamlessly with diverse industrial systems. For example, it communicates with GE IC695CPE330 PLCs via Ethernet/IP for process control, connects to HMIs like GE IC693HMI301 for centralized monitoring, and interfaces with barcode scanners via USB for inventory tracking. Its support for Modbus RTU/TCP enables compatibility with third-party devices, making it a flexible choice for hybrid automation setups.
Rugged Industrial Design:
The panel’s IP20-rated enclosure and conformal coating protect against dust, moisture, and chemical splashes, while its vibration and shock resistance ensure reliability in harsh environments like mining or oil refineries. The wide operating temperature range (0°C to +60°C) adapts to extreme climates, from arctic power stations to desert solar farms. CE and UL certifications further validate its compliance with global safety standards.
The panel’s IP20-rated enclosure and conformal coating protect against dust, moisture, and chemical splashes, while its vibration and shock resistance ensure reliability in harsh environments like mining or oil refineries. The wide operating temperature range (0°C to +60°C) adapts to extreme climates, from arctic power stations to desert solar farms. CE and UL certifications further validate its compliance with global safety standards.
Data Management and Redundancy:
The GE IC755CSS06RDA’s battery-backed SRAM retains critical data during power outages, ensuring no loss of configurations or alarms. Its 256 MB flash memory stores historical data for trend analysis, while USB ports enable easy data export to external drives or printers. For mission-critical applications, the panel can be paired with redundant PLCs (e.g., GE IC697CPU781) to ensure continuous operation.
The GE IC755CSS06RDA’s battery-backed SRAM retains critical data during power outages, ensuring no loss of configurations or alarms. Its 256 MB flash memory stores historical data for trend analysis, while USB ports enable easy data export to external drives or printers. For mission-critical applications, the panel can be paired with redundant PLCs (e.g., GE IC697CPU781) to ensure continuous operation.
Easy Integration and Customization:
Pre-installed with GE’s Cimplicity HMI software, the GE IC755CSS06RDA simplifies programming and configuration. Users can create custom dashboards, set up alarm notifications, and monitor KPIs without extensive coding. The panel’s modular design allows for easy firmware updates and hardware upgrades, extending its lifecycle in rapidly evolving automation systems.
Pre-installed with GE’s Cimplicity HMI software, the GE IC755CSS06RDA simplifies programming and configuration. Users can create custom dashboards, set up alarm notifications, and monitor KPIs without extensive coding. The panel’s modular design allows for easy firmware updates and hardware upgrades, extending its lifecycle in rapidly evolving automation systems.
Application Areas
-
Manufacturing:
- Food and Beverage: Monitors batch processes, displays recipe parameters, and logs production data for quality control.
- Automotive: Controls robotic assembly lines, tracks part counts, and interfaces with vision systems for defect detection.
-
Power Generation:
- Renewable Energy: Displays real-time solar panel efficiency, manages battery storage systems, and communicates with grid operators via Modbus TCP.
- Oil and Gas: Monitors offshore platform equipment status, triggers emergency shutdowns (ESD), and logs maintenance schedules.
-
Water/Wastewater:
- Treatment Plants: Visualizes sensor data (pH, turbidity), adjusts pump operations, and generates compliance reports.
- Distribution Networks: Monitors pressure levels in pipelines, predicts leaks, and alerts technicians via SMS integration.
-
Chemical Processing:
- Batch Reactors: Displays temperature/pressure trends, adjusts valve settings, and archives process data for regulatory audits.
- Safety Systems: Integrates with TRICONEX SIS systems to provide a redundant HMI layer for critical safety interlocks.
-
Mining:
- Ore Processing: Controls conveyor belt speeds, monitors crusher performance, and interfaces with SCADA systems for remote operation.
Related Products
- GE IC695CPE330: RX3i PLC CPU that communicates with GE IC755CSS06RDA via Ethernet/IP for real-time control.
- GE IC697CPU781: Series 90-70 PLC CPU compatible with GE IC755CSS06RDA for legacy system upgrades.
- GE IC693HMI301: 12-inch HMI panel that complements GE IC755CSS06RDA in multi-station control rooms.
- GE IC755CSS10CDA: 10-inch QuickPanel+ variant for larger display requirements in process visualization.
- GE IC755CSS12CDB: 12-inch panel with higher resolution (800×600) for detailed analytics in power plants.
- GE IC755CSS15CDA: 15-inch HMI ideal for central control rooms requiring wide-screen data presentation.
- GE IC755CSW07CDA: 7-inch panel with capacitive touch for applications needing multi-touch functionality.
Installation and Maintenance
Pre-installation preparations:
Verify the GE IC755CSS06RDA’s physical dimensions (192x137x36 mm) match the mounting location. Use an ESD wrist strap during handling to protect against electrostatic discharge. Connect the 24 VDC power supply via the terminal block, ensuring polarity is correct. For Ethernet communication, terminate cables with RJ45 connectors and test connectivity to the PLC (e.g., GE IC695CPE330). Mount the panel using the provided screws or VESA bracket, ensuring it is securely fastened to prevent vibration damage.
Verify the GE IC755CSS06RDA’s physical dimensions (192x137x36 mm) match the mounting location. Use an ESD wrist strap during handling to protect against electrostatic discharge. Connect the 24 VDC power supply via the terminal block, ensuring polarity is correct. For Ethernet communication, terminate cables with RJ45 connectors and test connectivity to the PLC (e.g., GE IC695CPE330). Mount the panel using the provided screws or VESA bracket, ensuring it is securely fastened to prevent vibration damage.
Maintenance suggestions:
- Daily: Check front-panel LEDs for power (green) and communication status (amber).
- Monthly: Clean the touchscreen with a non-abrasive cloth to maintain responsiveness.
- Quarterly: Update firmware via USB to access new features and security patches.
- Annually: Perform a full system backup to external storage and test battery-backed SRAM retention.
- As Needed: Replace the panel if touchscreen accuracy degrades or if the display shows dead pixels, ensuring compatibility with existing system configurations.
Product Guarantee
Our company offers a one-year quality warranty service for GE IC755CSS06RDA, covering hardware malfunctions not caused by human factors. During the warranty period, if GE IC755CSS06RDA exhibits issues like unresponsive touchscreens, communication failures, or display anomalies, we will provide replacement services. As a leading import/export trade distribution company established in 2007, we maintain extensive inventories of industrial control parts, including discontinued models like GE IC755CSS06RDA. Our global supply chain network ensures rapid delivery of scarce spare parts, supporting continuous system operation. For urgent demands or complex integration needs, our technical team provides 24/7 support to address installation and configuration challenges.
