GE IC754VSF15CTD VersaMax 15-inch Color Touch Screen HMI
Product Overview
The GE IC754VSF15CTD is a high-performance 15-inch color touch screen HMI (Human-Machine Interface) designed for GE’s VersaMax automation platform, serving as a critical interface between operators and industrial control systems in manufacturing, energy, and infrastructure sectors. As a key component in the VersaMax series, the IC754VSF15CTD enables real-time monitoring, parameter adjustment, and alarm management for PLCs, DCS, and other control devices, bridging the gap between human operators and automated processes.
Featuring a 15-inch TFT LCD display with 1024×768 resolution and 256K colors, the IC754VSF15CTD delivers clear visualizations of process data, including trends, graphs, and dynamic mimic diagrams. Its resistive touch screen supports multi-touch gestures (tap, drag, zoom), ensuring intuitive operation even with gloves—essential for factory floors and industrial environments. The module supports Ethernet/IP, Modbus TCP, and Serial (RS-232/485) protocols, enabling seamless communication with GE’s VersaMax PLCs (e.g., IC200CPU001) and third-party devices like Rockwell Allen-Bradley controllers or Siemens S7 series.
Engineered for rugged use, the IC754VSF15CTD operates across 0°C to 50°C and withstands 5–95% non-condensing humidity, with a NEMA 4/IP65 front panel that resists dust, water splashes, and oil contamination—ideal for food processing plants, chemical facilities, and outdoor installations. Its compact design (381mm × 305mm × 51mm) and 2.7 kg weight allow flexible mounting (panel, wall, or arm) in space-constrained control cabinets.
Within the VersaMax ecosystem, the IC754VSF15CTD integrates with software tools like Proficy Machine Edition for screen design and firmware updates, supporting custom animations, historical data logging, and remote access via VNC. LED indicators provide real-time status for power, communication, and storage, simplifying diagnostics. Compliance with UL 508 and CE standards underscores its reliability in regulated industrial settings.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC754VSF15CTD |
| Manufacturer | GE |
| Product Type | 15-inch Color Touch Screen HMI |
| Series | VersaMax |
| Display | 15-inch TFT LCD, 1024×768 resolution, 256K colors |
| Touch Screen | Resistive, multi-touch capable |
| Communication Interfaces | 1× Ethernet (10/100Base-TX), 2× RS-232/485, 2× USB 2.0 |
| Supported Protocols | Ethernet/IP, Modbus TCP, Modbus RTU, SNP |
| Power Supply | 24V DC (±10%), 2.5A max |
| Physical Dimensions | 381mm (W) × 305mm (H) × 51mm (D) |
| Weight | 2.7 kg |
| Operating Temperature | 0°C to 50°C |
| Humidity | 5–95% non-condensing |
| Mounting Type | Panel, wall, or arm-mounted |
| Protection Rating | NEMA 4/IP65 (front panel); NEMA 1/IP20 (rear) |
| Storage Temperature | -20°C to 60°C |
| Compliance | UL 508, CE, RoHS |
Main Features and Advantages
High-Resolution Visualization
The IC754VSF15CTD’s 15-inch 1024×768 display renders process data with exceptional clarity, making it easy to monitor critical parameters like pressure, temperature, and flow rates. Its 256K color palette distinguishes alarms (red), warnings (yellow), and normal operations (green), enabling operators to quickly identify issues in complex systems such as chemical reactors or assembly lines.
Intuitive Operation
The resistive touch screen works reliably with gloves or styluses, supporting gestures like drag-and-drop for parameter adjustment and zoom for detailed trend analysis. Customizable widgets (buttons, sliders, gauges) allow users to design interfaces tailored to specific processes, reducing training time for new operators.
Versatile Connectivity
With Ethernet/IP, Modbus TCP, and Serial ports, the IC754VSF15CTD integrates seamlessly with GE’s VersaMax PLCs and third-party devices. This flexibility eliminates the need for proprietary gateways, simplifying retrofits of legacy systems—for example, connecting to a Siemens S7-1200 PLC via Modbus RTU or a Rockwell Micro800 via Ethernet/IP.
Rugged Industrial Design
The NEMA 4/IP65 front panel protects against water splashes, dust, and oil, ensuring durability in food processing plants (where washdowns are frequent) or steel mills (with high airborne particulates). Its wide operating temperature range (0°C to 50°C) suits both indoor control rooms and outdoor kiosks in utility substations.
Advanced Data Management
The HMI supports historical data logging (up to 2GB via USB or SD card), enabling operators to track process trends over hours, days, or months. Integration with Proficy Machine Edition allows remote firmware updates and screen design modifications, reducing on-site maintenance time.
Application Fields
The GE IC754VSF15CTD is integral to industries requiring intuitive interaction with automated systems:
- Manufacturing: Serves as the operator interface for assembly lines, monitoring robotic arm positions, conveyor speeds, and quality inspection results. Its touch screen allows quick adjustments to production parameters, minimizing downtime during changeovers.
- Energy Sector: Monitors turbine performance in power plants, displaying generator output, steam pressure, and vibration levels. Operators can acknowledge alarms or initiate shutdowns via the HMI, ensuring compliance with grid stability standards.
- Water Treatment: Controls pump stations and filtration systems, visualizing water flow rates, pH levels, and chemical dosing amounts. The rugged design withstands humid environments in wastewater facilities.
- Oil and Gas: Manages offshore platform equipment, including compressor status and pipeline pressure. Its multi-protocol support connects to both GE PLCs and third-party safety systems, enhancing operational visibility.
Related Products
- GE IC754VSF08CTD: 8-inch VersaMax HMI with similar functionality, ideal for space-constrained applications like small machine control panels.
- GE IC200CPU001: VersaMax PLC that pairs with the IC754VSF15CTD, executing control logic while the HMI provides operator feedback.
- GE IC200PWR102: 24V DC power supply for the IC754VSF15CTD and VersaMax PLCs, ensuring stable operation in noisy electrical environments.
- GE IC754VSL12CTD: 12-inch HMI with enhanced graphics processing, suitable for applications requiring 3D visualizations or video integration.
- GE IC200ALG260: VersaMax analog input module that sends sensor data to the IC754VSF15CTD for display and analysis.
- GE IC200MDL740: Digital output module controlled via the HMI, enabling operators to activate valves, motors, or alarms directly from the IC754VSF15CTD interface.
Installation and Maintenance
Pre-installation preparations: Ensure the mounting surface is flat and grounded to reduce EMI. Verify the 24V DC power supply meets ±10% tolerance and connect via shielded cables. For panel mounting, cut a 362mm × 286mm opening to fit the IC754VSF15CTD, securing it with the included brackets. Configure communication settings (IP address, protocol) using the HMI’s setup menu, matching parameters with connected PLCs or controllers.
Maintenance suggestions: Clean the touch screen weekly with a soft, dry cloth to remove dust; avoid harsh chemicals that may damage the protective coating. Monthly, inspect cable connections for tightness and check the rear vents for obstructions to prevent overheating. Quarterly, back up project files to a USB drive and update firmware via Proficy Machine Edition to ensure compatibility with new devices. If the screen becomes unresponsive, calibrate it using the built-in tool—accessible via the settings menu.
Product Guarantee
Our company offers a one-year quality warranty service for the IC754VSF15CTD, covering hardware malfunctions not caused by human factors. During the warranty period, if the product shows abnormal performance or functional failure, we will provide replacement services. In addition, for discontinued models or urgent demands, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts, and provide reliable services to support the continuous and stable operation of industrial systems. As a leading import and export trade distribution company established in 2007 with 17 years of experience, we maintain a large stock of IC754VSF15CTD and other VersaMax HMI models, ensuring 48-hour delivery for urgent requirements. Our technical team provides configuration support, including screen design templates and protocol setup guides, to streamline integration into your automation system.
