GE IC695ALG704 RX3i 4-Channel Analog Input Module
Product Overview
The GE IC695ALG704 is a high-precision 4-channel analog input module designed for GE’s RX3i PLC system. It serves as a critical interface between industrial sensors and the PLC, converting continuous physical signals—such as temperature, pressure, and flow—into digital data for processing. This enables real-time monitoring and control of industrial processes, making it indispensable for applications requiring precise measurement and automation.
The GE IC695ALG704 supports multiple input ranges, including 4–20mA, 0–20mA, 0–10V, and ±10V, accommodating a wide variety of sensors. Its 16-bit resolution ensures accurate signal conversion, with a total error of less than ±0.1% of full scale. Each channel features 250V AC isolation from the PLC backplane, protecting against electrical noise and ensuring reliable operation in harsh industrial environments.
As part of the RX3i ecosystem, the GE IC695ALG704 integrates seamlessly with other modules, such as the IC695CPU310 (CPU module), IC695PWR120 (power supply), and IC695CHS010 (rack). It operates in temperatures from 0°C to 60°C and resists dust, vibrations, and humidity, making it suitable for applications in manufacturing, energy, water treatment, and more.
The module’s compact design allows it to fit into standard RX3i racks, while LED indicators on the front panel provide visual feedback for each channel’s status, simplifying troubleshooting and maintenance. Whether used in small-scale automation or large industrial complexes, the GE IC695ALG704 ensures precise and reliable analog signal processing.
Technical Specifications
Parameter Name | Parameter Value |
---|---|
Product Model | IC695ALG704 |
Manufacturer | GE |
Product Type | 4-Channel Analog Input Module |
Series | RX3i |
Number of Channels | 4 |
Input Ranges | 4–20mA, 0–20mA, 0–10V, ±10V |
Resolution | 16 bits |
Accuracy | ±0.1% of full scale |
Physical Dimensions | 120mm (L) × 80mm (W) × 60mm (D) |
Weight | 0.35 kg |
Operating Temperature | 0°C to 60°C |
Humidity Resistance | 5–95% non-condensing |
Isolation | 250V AC (channel to backplane) |
Mounting | Fits RX3i racks (e.g., IC695CHS010) |
Country of Origin | United States |

IC695ALG704
Related Products
- GE IC695CPU310: The CPU module that processes data from the IC695ALG704, executing control logic based on analog inputs.
- GE IC695PWR120: A power supply module that provides 5V DC to the IC695ALG704, ensuring stable operation.
- GE IC695CHS010: A 10-slot rack that houses the IC695ALG704 and other modules, providing structural support and electrical connectivity.
- GE IC695MDL640: A digital output module that works with the IC695ALG704 to control external devices based on processed analog data.
- GE IC695ACC412: An Ethernet communication module that enables the IC695ALG704 to transmit data to remote systems for monitoring and analysis.
- GE IC695ALG608: An 8-channel analog input module similar to the IC695ALG704 but with higher channel density, suitable for applications requiring more inputs.
Main features and advantages
High-precision measurement: The IC695ALG704 offers 16-bit resolution and ±0.1% accuracy, ensuring precise conversion of analog signals. This makes it ideal for applications requiring tight control, such as pharmaceutical manufacturing or chemical processing.
Flexible input ranges: The module supports multiple input types (4–20mA, 0–20mA, 0–10V, ±10V), allowing it to interface with a wide range of sensors without additional signal conditioning. This versatility reduces system complexity and cost.
Electrical isolation: Each channel features 250V AC isolation, protecting the PLC from electrical noise and ground loops. This is critical in industrial environments with high electromagnetic interference, such as factories with large motors or welding equipment.
Compact design: The IC695ALG704’s small form factor allows it to fit into standard RX3i racks, optimizing space in control cabinets. This is particularly beneficial in applications where space is limited.
LED status indicators: Visual indicators on the front panel provide real-time feedback on channel status, making it easy to identify and troubleshoot issues quickly. This reduces downtime and maintenance costs.
Rugged industrial construction: The module is designed to operate in harsh environments, with resistance to temperature extremes, humidity, and vibrations. This ensures reliable performance in demanding applications, such as oil and gas or mining.

IC695ALG704
Installation and maintenance
Pre-installation preparations: Before installing the IC695ALG704, ensure that the power to the PLC rack (e.g., IC695CHS010) is turned off. Verify that the rack has an available slot and that the backplane is clean and undamaged. Inspect the module for any signs of physical damage and ensure that the input settings (e.g., current or voltage range) match the connected sensors.
Maintenance suggestions: Regularly inspect the IC695ALG704 for loose connections, dust accumulation, or signs of damage. Check the LED indicators to monitor channel status. If a channel fails, verify the sensor and wiring before replacing the module. Calibration is recommended annually to maintain accuracy, following GE’s specified procedures.
Application fields
The GE IC695ALG704 is suitable for a wide range of industrial applications, including:
Manufacturing: Monitoring temperature, pressure, and flow in production processes to ensure quality control and optimize efficiency.
Energy: Measuring parameters such as voltage, current, and temperature in power generation and distribution systems.
Water treatment: Monitoring water levels, pH, and chemical concentrations to maintain safe and efficient treatment processes.
Food and beverage: Controlling temperature and pressure in cooking, fermentation, and packaging processes to ensure product consistency and safety.
Automotive: Monitoring sensors in assembly lines and robotic systems to ensure precise operation and quality control.
Energy: Measuring parameters such as voltage, current, and temperature in power generation and distribution systems.
Water treatment: Monitoring water levels, pH, and chemical concentrations to maintain safe and efficient treatment processes.
Food and beverage: Controlling temperature and pressure in cooking, fermentation, and packaging processes to ensure product consistency and safety.
Automotive: Monitoring sensors in assembly lines and robotic systems to ensure precise operation and quality control.

IC695ALG704
