GE IC694ALG442 Analog I/O Module
Product Overview
The GE IC694ALG442 is a mixed analog input/output module designed for GE’s RX3i PACSystems, a robust platform used in industrial automation. This module plays a crucial role in industrial control systems by converting real-world analog signals, such as temperature and pressure, into digital data that can be processed by a PLC. It also sends digital commands back to the field to control devices like valves and motors. As part of the IC694 Series, the GE IC694ALG442 integrates seamlessly with RX3i backplanes, such as the IC694CHS790, and works alongside CPUs like the IC694CPU331 to enable precise automation.
The GE IC694ALG442 features 4 analog input channels and 2 analog output channels, offering a balanced solution for systems requiring both signal acquisition and control. The input channels support various signal types, including ±10 V DC, ±5 V DC, ±1 V DC, ±0.5 V DC, ±0.2 V DC, and 4–20 mA, while the output channels can provide ±10 V DC or 4–20 mA signals. Each channel offers 16-bit resolution, ensuring high precision in both measurement and control. The module also includes optical isolation (250 V AC continuous) to protect against electrical noise, a critical feature in industrial environments with heavy machinery.
Designed for flexibility, the GE IC694ALG442 can be installed in any I/O slot of an RX3i rack. It requires an external +24 V DC power supply (connected via the backplane’s TB1 terminal block) and supports configuration through GE’s Proficy Machine Edition software. This module is particularly useful for retrofitting legacy systems, as it maintains compatibility with earlier GE platforms while leveraging the RX3i’s advanced communication capabilities.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC694ALG442 |
| Manufacturer | GE |
| Product Type | Mixed Analog I/O Module (RX3i PACSystems) |
| Input Channels | 4 channels (configurable for voltage or current) |
| Output Channels | 2 channels (configurable for voltage or current) |
| Input Ranges | ±10 V DC, ±5 V DC, ±1 V DC, ±0.5 V DC, ±0.2 V DC, 4–20 mA |
| Output Ranges | ±10 V DC, 4–20 mA |
| Resolution | 16-bit (both inputs and outputs) |
| Accuracy | ±0.05% of full scale (inputs); ±0.1% of full scale (outputs) |
| Isolation | 250 V AC continuous (field to backplane) |
| Power Consumption | 200 mA @ +5 V DC (backplane); 250 mA @ +24 V DC (external) |
| Physical Dimensions | 136 mm (L) × 35 mm (W) × 133 mm (D) |
| Weight | 0.48 kg |
| Operating Temperature | 0°C to 60°C |
| Humidity Tolerance | 5%–95% (non-condensing) |
| Mounting Type | RX3i backplane mount (any I/O slot) |
IC694ALG442
Related Products
- GE IC694ALG220A: A 4-channel analog input module with 12-bit resolution. It is suitable for applications requiring fewer input channels but shares software compatibility with the IC694ALG442.
- GE IC694ALG233: A 16-channel analog input module with 16-bit resolution. It provides higher channel density for systems needing extensive analog signal monitoring.
- GE IC694ALG392: An 8-channel analog output module with 16-bit resolution. It complements the IC694ALG442 in systems requiring more output channels for controlling multiple devices.
- GE IC694MDL645A: A 16-point digital input module that works alongside the IC694ALG442 to integrate analog and discrete signals in hybrid automation systems.
- GE IC694CPU331: A high-performance CPU for RX3i systems. It processes data from the IC694ALG442 to execute complex control logic in industrial settings.
- GE IC694CHS790: A 9-slot backplane that provides mechanical and electrical support for the IC694ALG442 and other RX3i modules.
Main features and advantages
Balanced I/O configuration: The IC694ALG442 offers a mix of 4 input and 2 output channels, making it ideal for applications requiring both signal monitoring and control, such as regulating temperature based on sensor readings. This balanced design reduces the number of modules needed in a system, saving rack space and simplifying wiring.
Wide range of input/output configurations: The module supports multiple voltage and current ranges for both inputs and outputs, allowing it to interface with various sensors and actuators without additional signal conditioning. This flexibility reduces hardware costs and simplifies system design.
High precision and accuracy: The 16-bit resolution and ±0.05% input accuracy ensure precise measurement of critical parameters, such as pressure in hydraulic systems or flow rates in chemical processes. The ±0.1% output accuracy enables precise control of devices like servo motors or variable frequency drives.
Robust isolation: Optical isolation protects the module from electrical noise and ground loops, ensuring reliable operation in noisy industrial environments. This feature is particularly important in facilities with large motors or high-power equipment.
Easy configuration and integration: The module can be configured using GE’s Proficy Machine Edition software, which provides a user-friendly interface for setting input/output ranges, scaling, and filtering. It integrates seamlessly with other RX3i modules, simplifying system integration and maintenance.
Installation and maintenance
Pre-installation preparations: Verify compatibility with your RX3i backplane (e.g., IC694CHS790) and ensure an available I/O slot. Power off the system and disconnect all power sources. Align the IC694ALG442 with the slot and push firmly until it clicks into place. Connect the +24 V DC power cable to the backplane’s TB1 terminal block, ensuring proper polarity. Use shielded twisted-pair cables for analog signals, grounding the shield to minimize noise.
Maintenance suggestions: Inspect the IC694ALG442 quarterly for loose connections or physical damage. Clean dust from vents using a dry cloth to prevent overheating. If the module’s status LED indicates a fault, power off the system and reseat the module. For persistent issues, replace it with a spare from your inventory. Store spare modules in a dry, cool environment (10–30°C) to maintain their integrity. Regularly calibrate the module using GE’s Proficy Machine Edition software to ensure accuracy over time.
IC694ALG442
Application fields
The GE IC694ALG442 is well-suited for industries requiring both analog signal monitoring and control:
- Chemical processing: The module monitors temperature and pressure in reactors (using 4–20 mA sensors) and controls valve positions (using ±10 V outputs) to maintain optimal reaction conditions. Its high precision ensures product quality and safety.
- Power generation: In power plants, the IC694ALG442 measures steam pressure and turbine speed (using voltage inputs) and adjusts generator excitation (using 4–20 mA outputs) to maintain grid stability.
- Water treatment: The module integrates with pH sensors and flow meters (using various input ranges) to monitor water quality and controls chemical dosing pumps (using 4–20 mA outputs) to adjust treatment levels.
- Manufacturing: In automotive assembly lines, the IC694ALG442 monitors hydraulic pressure in robotic arms (using ±5 V inputs) and controls servo motors (using ±10 V outputs) to ensure precise movements and consistent weld quality.
- Oil and gas: The module measures pipeline pressure and temperature (using voltage inputs) and controls valve actuators (using 4–20 mA outputs) to regulate flow and prevent leaks in extraction and refining processes.
IC694ALG442
Product guarantee
Our company offers a one-year quality warranty for the IC694ALG442, covering hardware malfunctions unrelated to misuse or improper installation. During the warranty period, we provide free replacement for modules exhibiting performance issues. For urgent or discontinued models, our global supply chain network ensures rapid delivery of scarce parts, minimizing downtime for critical systems.
