GE IC694ALG392-CD | 8-channel analog output module | IC694BEM331 GE

Original price was: $900.00.Current price is: $697.00.

Brand model:GE
Product Name: IC694ALG392-CD
Warranty: 1 year
Weight:0.5kg
Origin:USA
Inventory: Spot/Futures
Goods condition: Brand new
Delivery time: 3-4days/1month

Category: Brand:

Description

GE IC694ALG392-CD is a high-performance 8-channel analog output module designed for GE Fanuc’s RX3i PACSystem, delivering precise control signals for industrial automation and process optimization. Engineered to convert digital data from PLCs into analog current or voltage outputs, the GE IC694ALG392-CD supports configurable ranges of 4–20 mA, 0–20 mA, 0–10 V, and –10–10 V, making it suitable for diverse actuators such as valves, motors, and temperature controllers. Its 15–16-bit resolution ensures fine-grained control, while an 8-millisecond update rate enables real-time adjustments in dynamic processes like chemical dosing or conveyor speed regulation. The module features optical isolation between field wiring and the backplane, protecting against electromagnetic interference (EMI) and voltage spikes up to 200V common-mode, ensuring stable operation in harsh industrial environments.



As part of GE’s RX3i platform, the GE IC694ALG392-CD integrates seamlessly with other modules in the series, including CPUs, communication cards, and input modules, to form scalable automation systems. Its compact design allows installation in any I/O slot of the RX3i backplane, with power requirements of 110 mA from the 5V DC backplane bus and 315 mA from an isolated 24V DC supply. The module’s dual-range capability, achieved via software configuration, simplifies setup for different actuator types, reducing the need for external signal conditioning. This flexibility, combined with its robust construction, makes the GE IC694ALG392-CD a preferred choice for industries requiring reliable analog control.

Technical Specifications

Product model GE IC694ALG392-CD
Manufacturer GE Fanuc
Product type 8-channel analog output module
Output signal range 4–20 mA, 0–20 mA (current); 0–10 V, –10–10 V (voltage)
Resolution 15–16 bits (varies by output range)
Update rate 8 milliseconds (all channels)
Isolation Optical isolation (250V AC continuous, 1500V DC for 1 minute)
Power consumption 110 mA @ +5V DC (backplane), 315 mA @ +24V DC (isolated)
Physical dimensions 1.1 in (W) × 5.1 in (H) × 4.9 in (D) (2.9 cm × 13.0 cm × 12.4 cm)
Weight 0.2 kg (5.6 oz)
Origin United States
Operating temperature 0°C to 60°C
Installation Single slot in RX3i backplane
Certifications COO (Certificate of Origin)
IC694ALG392-CD

IC694ALG392-CD

Related Products

  • GE IC694CHS392: A 10-slot serial expansion backplane that extends the GE IC694ALG392-CD’s connectivity by supporting remote I/O racks up to 15 meters away .
  • GE IC694PWR330: A high-capacity power supply module that provides stable 24V DC power to the GE IC694ALG392-CD and other RX3i modules .
  • GE IC695CPU351: A high-speed CPU module for the RX3i platform, which processes data from the GE IC694ALG392-CD to execute control logic in real time.
  • GE IC694MDL753: A 32-point discrete output module that works alongside the GE IC694ALG392-CD to coordinate analog and digital control signals in complex systems .
  • GE IC695ALG616: A 16-channel analog input module that complements the GE IC694ALG392-CD by providing comprehensive data acquisition for closed-loop control .
  • GE IC694CMM301: A Genius communication module that enhances the GE IC694ALG392-CD by enabling data exchange with HMIs or other PLCs over the Genius network .

Main Features and Advantages

Precision Control with High Resolution: The GE IC694ALG392-CD’s 15–16-bit resolution ensures accurate signal conversion, critical for applications like pharmaceutical batch processing or semiconductor manufacturing, where minor deviations can affect product quality. For example, in a chemical reactor, the module’s 0.5 µA resolution at 4–20 mA allows precise adjustment of reagent flow rates to meet exact formulation requirements.



Dual-Range Flexibility: With software-configurable output ranges (current/voltage), the module adapts to various actuators without hardware modifications. This reduces inventory complexity, as a single module can interface with both standard industrial valves (4–20 mA) and precision voltage-controlled motors (0–10 V).



Fast Update Rate: The 8-millisecond update rate ensures rapid response to changing process conditions, making the GE IC694ALG392-CD ideal for high-speed applications like packaging lines or turbine control systems. For instance, in a bottling plant, the module can adjust conveyor speed in real time to maintain production efficiency.



Robust Isolation and Protection: Optical isolation safeguards against EMI and voltage transients, while 200V common-mode protection prevents damage from ground loops or faulty sensors. This reliability is crucial in environments with high electrical noise, such as power plants or automotive assembly lines.



Seamless Integration: As a native RX3i module, the GE IC694ALG392-CD plugs directly into the backplane without compatibility issues, simplifying system expansion. Its low power consumption minimizes strain on the power supply, even in densely populated racks.



Comprehensive Diagnostics: The module provides real-time status indicators and fault reporting, such as open-wire detection in current mode, enabling technicians to quickly identify and resolve issues. This proactive approach reduces downtime and maintenance costs.

IC694ALG392-CD

IC694ALG392-CD

Installation and Maintenance

Pre-installation Preparations: Before installing the GE IC694ALG392-CD, ensure the RX3i backplane is powered off and securely mounted. Verify that the output signal type (current/voltage) matches the actuator requirements and configure the module using GE’s ProfiCy Machine Edition software. Connect shielded twisted-pair cables to the module’s terminals to minimize noise, grounding the shield to either the COM or GND terminal. Confirm that the total power consumption of all modules in the rack does not exceed the capacity of the connected power supply (e.g., GE IC694PWR330) .



Maintenance Suggestions: Regularly inspect the GE IC694ALG392-CD for loose connections or physical damage. Use a multimeter to check the 5V DC backplane voltage and the isolated 24V DC supply. Clean the module and terminal blocks to prevent dust accumulation, which can affect heat dissipation. Monitor the module’s LED indicators for status updates—solid green indicates normal operation, while red signals a fault. For persistent issues, consult the diagnostic logs in the PLC software. Avoid internal repairs, as this may void the warranty; instead, contact GE’s technical support for replacement or repair.

Application Fields

The GE IC694ALG392-CD is widely used in industries requiring precise analog control:



  • Manufacturing: In automotive plants, the module adjusts robotic arm movements by controlling servo motors, ensuring precision in welding or painting processes. Its fast update rate supports real-time adjustments to production parameters.
  • Power Generation: The module controls turbine inlet valves in power plants, optimizing energy output based on grid demand. Its high resolution ensures smooth transitions between load levels, reducing wear on mechanical components.
  • Water Treatment: In wastewater facilities, the GE IC694ALG392-CD regulates chemical dosing pumps by adjusting voltage outputs, ensuring compliance with environmental standards for pH and chlorine levels.
  • Oil and Gas: In offshore platforms, the module controls pressure relief valves and flow meters in pipeline systems, maintaining safe operating conditions. Its robust design withstands harsh offshore environments, including salt spray and temperature fluctuations.
  • Pharmaceuticals: The module’s precision supports sterile filling lines by controlling piston pumps to dispense exact volumes of liquid medications, ensuring compliance with strict quality control regulations.
    IC694ALG392-CD

    IC694ALG392-CD

Product Guarantee

Our company offers a one-year quality warranty service for the GE IC694ALG392-CD, covering hardware malfunctions not caused by human factors. During the warranty period, if the module shows abnormal performance or functional failure, we will provide replacement services. For discontinued models or urgent demands, our global supply chain network ensures quick response to procurement needs for scarce spare parts, supporting the continuous and stable operation of industrial systems.
