GE IC693PWR331D Power Supply Module
Product Overview
The GE IC693PWR331D is a high-capacity DC power supply module designed for GE’s Series 90-30 PLC systems, a cornerstone platform in industrial automation. This module serves as the primary power source for Series 90-30 components, including CPUs, I/O modules, and communication cards, ensuring stable and reliable operation of automated processes. It converts incoming DC voltage into the precise DC outputs required by these modules, making it indispensable for maintaining continuous system functionality.
As part of the IC693 Series, the GE IC693PWR331D is engineered to fit seamlessly into Series 90-30 backplane racks, such as the IC693CHS393, where it occupies the dedicated leftmost slot for power supply modules. This placement ensures efficient power distribution across the entire system. The IC693PWR331D accepts a wide 38–56 V DC input voltage range and delivers three distinct outputs: 5 V DC (for logic components like CPUs), 24 V DC relay power (for driving output relay modules), and isolated 24 V DC (for internal module operations or external 24 V DC input modules). This tri-output design simplifies system architecture by consolidating power requirements into a single module.
Built to withstand harsh industrial environments, the GE IC693PWR331D operates reliably in temperatures ranging from -25°C to 85°C and humidity levels up to 95% (non-condensing) . Its rugged construction resists dust, vibrations, and electrical fluctuations, making it suitable for applications in manufacturing plants, wastewater treatment facilities, and automotive assembly lines. Despite being a discontinued model, the IC693PWR331D remains critical for retrofitting or maintaining legacy Series 90-30 systems, offering a cost-effective alternative to full-scale system upgrades.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | IC693PWR331D |
| Manufacturer | GE |
| Product Type | High-Capacity DC Power Supply Module (Series 90-30) |
| Series | IC693 (Series 90-30) |
| Input Voltage | 38–56 V DC |
| Output Voltages | 5 V DC (logic), 24 V DC relay, 24 V DC isolated |
| Output Power | Total: 30 W (5 V: 30 W max; 24 V relay: 15 W max; 24 V isolated: 20 W max) |
| Physical Dimensions | 152 mm (L) × 51 mm (W) × 28 mm (D) |
| Weight | 0.45 kg |
| Operating Temperature | -25°C to 85°C |
| Humidity Tolerance | 5%–95% (non-condensing) |
| Communication | RS485 serial port (supports SNP/SNP-X protocols) |
| Mounting Type | Backplane mount (leftmost slot in Series 90-30 racks) |
| Protection Features | Overcurrent protection, short-circuit protection |
