GE IC693PWR331 Product Specification
Product Overview
The GE IC693PWR331 is a high-capacity power supply module designed for GE’s Series 90-30 PLC systems. It serves as the primary energy source, converting incoming DC voltage into stable outputs that power CPUs, I/O modules, and communication devices. With a compact design and robust performance, this module ensures reliable operation in industrial environments.
Rated for 24 VDC nominal input, the GE IC693PWR331 supports a wide input range of 2–30 VDC (with an 8 VDC minimum for startup) . It delivers three distinct outputs: 5 VDC (30 W max), 24 VDC relay power (15 W max), and isolated 24 VDC (20 W max), totaling 30 W of combined power . These outputs cater to diverse needs, such as powering logic circuits (5 VDC) and external devices like sensors and actuators (24 VDC). The module integrates seamlessly with Series 90-30 racks (e.g., IC693CHS391M) and must be installed in the leftmost slot for proper functionality .
Built for durability, the GE IC693PWR331 operates in temperatures from 0°C to 60°C and withstands 5–95% humidity (non-condensing) . Its RS485 serial port enables diagnostic monitoring and communication with external systems, while CE and UL certifications ensure compliance with safety standards . Whether in manufacturing lines, power plants, or water treatment facilities, this module provides stable power to maintain PLC system continuity.
Technical Specifications
| Parameter Name | Parameter Value |
|---|---|
| Product Model | GE IC693PWR331 |
| Manufacturer | General Electric (GE) |
| Product Type | High-Capacity Power Supply Module |
| Series | Series 90-30 |
| Input Voltage | 2–30 VDC (8 VDC min for startup) |
| Output Voltages | 5 VDC (30 W max), 24 VDC relay (15 W max), 24 VDC isolated (20 W max) |
| Physical Dimensions | 135 mm (L) × 130 mm (W) × 70 mm (H) [5.31″ × 5.12″ × 2.76″] |
| Weight | 0.5 kg (1.1 lb) |
| Operating Temperature | 0°C to +60°C |
| Humidity | 5–95% non-condensing |
| Protection Features | Overvoltage, overcurrent, and short-circuit protection |
| Communication | RS485 serial port |
| Certifications | CE, UL 508 |
IC693PWR331
Main Features and Advantages
Flexible Power Distribution: The GE IC693PWR331 prioritizes 5 VDC output, allowing all 30 W to be allocated to logic circuits when needed, which is ideal for applications requiring high CPU or communication module power . Its dual 24 VDC outputs (relay and isolated) support both internal module operations and external field devices.
Wide Input Compatibility: With a 2–30 VDC input range, the module adapts to unstable or variable power sources, making it suitable for global industrial settings. It maintains output stability even at input voltages as low as 2 VDC, though startup requires at least 8 VDC .
Reliable Protection: Built-in safeguards prevent damage from voltage spikes, overloads, and short circuits. The module automatically shuts down during faults and resumes operation once issues are resolved, minimizing downtime .
Compact Design: Weighing just 0.5 kg and measuring 135×130×70 mm, the GE IC693PWR331 fits seamlessly into space-constrained control cabinets. Its plug-and-play design simplifies installation in Series 90-30 racks, with no additional wiring beyond the AC/DC input connection .
Diagnostic Capabilities: The RS485 port enables real-time monitoring of power status and fault detection, enhancing predictive maintenance and system reliability .
Related Products
- GE IC693CHS391M: A 10-slot rack that houses the GE IC693PWR331 and other Series 90-30 modules, ensuring proper power distribution .
- GE IC693CPU350: A CPU module that relies on the GE IC693PWR331’s 5 VDC output to execute control programs .
- GE IC693MDL240: A 16-channel discrete input module powered by the GE IC693PWR331’s 24 VDC isolated output .
- GE IC693BEM331M: A communication module that uses the GE IC693PWR331’s 5 VDC to enable PLC connectivity with HMIs or SCADA systems .
- GE IC693PWR330: A sister model with AC input compatibility, suitable for applications requiring mixed power sources .
IC693PWR331
Installation and Maintenance
Pre-Installation Preparations:
- Verify the input voltage matches the GE IC693PWR331’s 2–30 VDC range.
- Ensure the rack (e.g., IC693CHS391M) is grounded and free of debris.
- Slide the module into the leftmost slot of the rack until it clicks, then secure it with the front screw. Connect the input power wires to the terminal block, ensuring tight connections .
Maintenance Suggestions:
- Inspect monthly for physical damage, loose connections, or signs of overheating (e.g., discoloration).
- Clean dust from the module’s vents to maintain airflow and prevent thermal stress.
- Every three months, check the input voltage and output stability using a multimeter. If the GE IC693PWR331 fails to power up or shows voltage irregularities, replace it promptly to avoid system disruptions .
Application Areas
Manufacturing: The GE IC693PWR331 powers PLCs in assembly lines, delivering 5 VDC to CPUs for program execution and 24 VDC to sensors that monitor conveyor belt speeds or product positioning .
Power Generation: In turbine control systems, it supplies stable power to modules that monitor pressure and temperature, ensuring efficient and safe energy production .
Water Treatment: The module supports PLCs in pump stations, using 24 VDC to actuate valves and 5 VDC to control chemical dosing systems, ensuring consistent water quality .
Smart Buildings: It drives automation systems for HVAC, lighting, and security, providing reliable power to I/O modules that interface with actuators and sensors .
IC693PWR331
Product Guarantee
Our company offers a one-year quality warranty for the GE IC693PWR331, covering hardware malfunctions unrelated to misuse. During the warranty period, defective units will be replaced promptly to minimize downtime. For discontinued models or urgent needs, our global supply chain ensures rapid delivery of scarce spare parts, supporting continuous industrial operations.
Established in 2007, our company is a leading industrial control parts distributor with 17 years of experience. We specialize in sourcing hard-to-find and obsolete components, maintaining a large inventory to meet urgent customer demands. Our expertise in GE Series 90-30 systems ensures reliable solutions for your automation needs.
