GE IC693PTM101A Series 90-30 Power Supply Module
Product Overview
The GE IC693PTM101A is a dedicated power supply module designed for GE’s Series 90-30 PLC system, serving as a critical component to provide stable power to connected automation modules. It converts AC input voltage into the DC power required by PLC components such as CPUs, I/O modules, and communication units, ensuring consistent operation of industrial control systems.
As a key part of the Series 90-30 ecosystem, the GE IC693PTM101A is engineered to deliver reliable power in harsh industrial environments. It accepts a wide range of AC input voltages (85–264V AC), making it adaptable to different regional power grids. This flexibility is essential for factories, power plants, and water treatment facilities operating across various locations.
The GE IC693PTM101A provides 5V DC and 24V DC outputs, with maximum currents of 10A and 2A respectively, sufficient to power multiple modules in a standard Series 90-30 rack (such as the IC693CHS397). Its rugged design allows operation in temperatures from 0°C to 60°C and resists dust, vibrations, and electrical noise, ensuring durability in demanding settings. Whether used in new installations or as a replacement in existing systems, the GE IC693PTM101A integrates seamlessly with other Series 90-30 components, contributing to the overall stability of automation systems.
Technical Specifications
| Parameter Name | Parameter Value |
| Product Model | IC693PTM101A |
| Manufacturer | GE |
| Product Type | AC-DC Power Supply Module |
| Series | Series 90-30 |
| Input Voltage | 85–264V AC (50/60 Hz) |
| Output Voltage | 5V DC (10A max), 24V DC (2A max) |
| Efficiency | ≥85% at full load |
| Physical Dimensions | 110mm (L) × 64mm (W) × 30mm (D) |
| Weight | 0.4 kg |
| Operating Temperature | 0°C to 60°C |
| Humidity Resistance | 5–95% non-condensing |
| Protection Features | Overcurrent, overvoltage, short-circuit protection |
| Mounting | Fits Series 90-30 racks (e.g., IC693CHS397) |
| Country of Origin | United States |
IC693PTM101A
Related Products
- GE IC693PWR330: A higher-power Series 90-30 power supply, offering 5V DC (12A) and 24V DC (3A) outputs, suitable for larger systems with more modules than the IC693PTM101Acan support.
- GE IC693CHS397: A 10-slot rack that houses the IC693PTM101Aand other Series 90-30 modules, providing structural support and backplane connectivity.
- GE IC693CPU374: A high-performance CPU module powered by the IC693PTM101A, serving as the “brain” of the PLC system.
- GE IC693MDL740K: A digital input module that draws power from the IC693PTM101A, converting sensor signals into data for the PLC.
- GE IC693BEM331: An Ethernet communication module compatible with the IC693PTM101A, enabling network connectivity for the PLC system.
- GE IC693ALG220: An analog input module that relies on the IC693PTM101Afor power, monitoring variables like temperature and pressure.
- GE IC693ACC302B: A backup battery module that works with systems powered by the IC693PTM101A, preserving data during power outages.
Main features and advantages
Wide input voltage range: The IC693PTM101A accepts 85–264V AC input, making it suitable for use in regions with different power grid standards. This eliminates the need for additional voltage converters, simplifying installation in global industrial facilities.
Dual DC outputs: The module provides 5V DC (10A) and 24V DC (2A) outputs, meeting the power needs of most Series 90-30 components. The 5V output powers core modules like CPUs and communication units, while the 24V output supports I/O modules and sensors, reducing the need for multiple power supplies.
Robust protection mechanisms: The IC693PTM101A includes overcurrent, overvoltage, and short-circuit protection. These features prevent damage to connected modules during electrical faults, such as a shorted I/O module, enhancing system reliability.
Industrial-grade durability: Built to operate in temperatures from 0°C to 60°C, the IC693PTM101A resists dust, vibrations, and humidity. This durability ensures stable performance in harsh environments, from factory floors with heavy machinery to outdoor control cabinets.
Seamless Series 90-30 integration: The IC693PTM101A fits perfectly into Series 90-30 racks (e.g., IC693CHS397) and works with all Series 90-30 modules. This compatibility allows users to build or expand systems without worrying about power supply mismatches, saving time and costs.
Compact design: With dimensions of 110mm × 64mm × 30mm, the module occupies minimal space in control racks, leaving room for additional I/O or communication modules. This is particularly valuable in space-constrained cabinets.
IC693PTM101A
Installation and maintenance
Pre-installation preparations: Power off the Series 90-30 rack (such as the IC693CHS397) before installing the IC693PTM101A. Check that the rack has an open slot for the power supply. Verify the input voltage (85–264V AC) matches the local power grid. Inspect the module for physical damage, ensuring connectors are clean. Use a screwdriver to secure the module in the rack, then connect the AC input cable to the terminal block.
Maintenance suggestions: Inspect the IC693PTM101A monthly. Check for loose input/output connections and wipe dust from the surface with a dry cloth. Monitor the LED power indicator—steady illumination means normal operation; a flickering or off light may indicate a fault. Every three months, use a multimeter to verify output voltages (5V DC and 24V DC) are within tolerance. If voltages are unstable or the module fails, replace it with a new IC693PTM101A to avoid system downtime.
Application fields
The GE IC693PTM101A is widely used in industries relying on stable PLC power:
In manufacturing plants, it powers automation systems controlling assembly lines. For example, it supplies power to the IC693CPU374 (CPU) and IC693MDL740K (digital input module) in automotive factories, ensuring robots and conveyors operate without interruptions.
In water treatment facilities, the IC693PTM101A provides power to PLC modules managing pumps and valves. Its ability to resist humidity and electrical noise ensures reliable operation in damp control rooms, preventing disruptions to water filtration processes.
In food processing facilities, it powers systems regulating mixers, ovens, and packaging machines. Its wide input voltage range adapts to fluctuations in factory power, protecting sensitive equipment from voltage spikes that could damage controls.
In small to medium-sized energy facilities, the module powers PLCs monitoring generator performance. Its durable design withstands vibrations from machinery, ensuring continuous power to modules tracking voltage and current levels.
IC693PTM101A
Product guarantee
Our company offers a one-year quality warranty service for the IC693PTM101A, covering hardware malfunctions not caused by human factors. During the warranty period, if the product shows abnormal performance or functional failure, we will provide replacement services. In addition, for discontinued models or urgent demands, relying on our global supply chain network, we can quickly respond to customers’ procurement needs for scarce spare parts, and provide reliable services to support the continuous and stable operation of industrial systems.
